- Page 1 IN-WALL SPEAKERS I n s t a l l a t i o n a n d I n s t r u c t i o n M a n u a l...
-
Page 3: Break-In Period
Introduction Congratulations on your purchase of RBH Sound in-wall speakers! Your speakers are the result of many years of research and development dedicated to producing high quality products for home audio and audio/video systems. This manual is designed to give you, the installer or owner, basic information as to the speaker’s installation and operation. - Page 4 Room Setup Suggestions With nearly endless placement options, careful consideration for placement of the in-wall speaker needs to be considered, as installation requires cutting a hole in your wall! When using the speaker in home theater applications follow the guidelines illustrated below.
-
Page 5: Speaker Installation
However, using an RBH Sound back can will most likely improve the tightness and control the bass response. RBH Sound in-wall speakers have also been designed to make installation as easy as possible. -
Page 6: Finishing The Installation
Speaker Installation (continued) NOTE: The frame will overlap the cutting edge by about a 1/4-inch which will mask any minor cutting inaccuracies. 5. Confirm the speaker easily fits into the hole, without any gaps. Connecting the Speaker: 6. Pull the speaker wire out of the hole and connect the speaker. -
Page 7: Speaker Accessories
New Construction Brackets eliminate the time and need to locate Blank Plates and cut drywall before speaker installation. For more information on RBH Sound in-wall speaker accessories go to www.rbhsound.com. New Construction Bracket... -
Page 8: Specifications
Specifications Model: A-610 A-414 MC-414 Series: Architectural Architectural System Type: In-wall 2-way Speaker In-wall 2-way Speaker In-wall 2-way Speaker Frequency Response: 55Hz-20kHz (±3dB) 60Hz-20kHz (±3dB) 55Hz-20kHz (±3dB) Sensitivity: 90dB 90dB 91dB (2.83V @ 1 Meter) (2.83V @ 1 Meter) (2.83V @ 1 Meter) - Page 9 Specifications (continued) MC-6 MC-6DB MC-616 Model: Series: In-wall 2-way Speaker In-wall 2-way Surround Speaker In-wall 2-way Speaker System Type: 50Hz-20kHz (±3dB) 50Hz-20kHz (±3dB) 50Hz-20kHz (±3dB) Frequency Response: 86dB 88dB 91dB Sensitivity:* (2.83V @ 1 Meter) (2.83V @ 1 Meter) (2.83V @ 1 Meter) 15-120 Watts 15-120 Watts 15-180 Watts...
- Page 10 Specifications (continued) MC-553 MCS-88 TK-6 Model: Series: In-wall/LCR Dual 2-way Speaker In-wall Subwoofer In-wall 2-way Speaker System Type: 55Hz-20kHz (±3dB) 35Hz-100Hz (±3dB) 50Hz-20kHz (±3dB) Frequency Response: 88dB Main, 87dB Center, and 90dB 88dB Sensitivity: (2.83V @ 1 Meter) (2.83V @ 1 Meter) 90dB Combined (2.83V @ 1 Meter) 15-150 Watts Main, 15-100...
- Page 11 Discontinued Product–Specifications A-810 A-616 A-509 Model: Architectural Architectural Architectural Series: System Type: In-ceiling 2-way Speaker In-wall 2-way Speaker In-wall 2-way Speaker 50Hz-20kHz (±3dB) 55Hz-20kHz (±3dB) 60Hz-20kHz (±3dB) Frequency Response: 90dB 91dB 88dB Sensitivity: (2.83V @ 1 Meter) (2.83V @ 1 Meter) (2.83V @ 1 Meter) 10-110 Watts 50-160 Watts...
- Page 12 Discontinued Product–Specifications (continued) Model: MC-884 MC-83 MC-8 Series: System Type: In-wall 3-way Speaker In-wall 3-way Speaker In-wall 2-way Speaker Frequency Response: 40Hz-20kHz (±3dB) 45Hz-20kHz (±3dB) 50Hz-20kHz (±3dB) Sensitivity: 89dB (2.83V @ 1 Meter) 86dB (2.83V @ 1 Meter) 86dB (2.83V @ 1 Meter) Recommended/Rated Power: 15-200 Watts 15-150 Watts...
- Page 13 Discontinued Product–Specifications (continued) Model: TK-8 Series: System Type: In-wall Frequency Response: 50Hz-20kHz (±3dB) Sensitivity: 90dB (2.83V @ 1 Meter) Recommended/Rated Power: 15-110 Watts Woofer(s): (1) 8” (203mm) Fiberglass Matrix Cone Tweeter(s): (1) 1” (25mm) Aluminum Swivel Tweeter(s) Tweeter Protection: Crossover Frequency: 2,500 Hz Crossover Slope: 12dB/Octave...
-
Page 14: Troubleshooting
Warranty Your RBH Sound in-wall speaker is covered by a limited warranty against defects in materials and workmanship for a period of 25 years. This warranty is provided by the authorized RBH Sound dealer where the speaker was purchased. Warranty repair will be performed only when your purchase receipt is presented as proof of ownership and date of purchase. - Page 16 382 Marshall Way, Layton, Utah • USA • 84041 Toll Free: (800) 543-2205 • Fax: (801) 543-3300 www.rbhsound.com It is RBH Sound policy to continuously incorporate improvements into products; all specifications are subject to change without notice. Copyright © 2010 RBH Sound. All Rights Reserved. 08/03/2010.
