IN CEILING SPEAKER INSTALLATION AND INSTRUCTION MANUAL
Congratulations on your purchase of an RBH loudspeaker system! Your speakers are the result of many years
of research and development dedicated to producing high quality products for home audio and audio/video
systems. This manual is designed to give you, the installer or owner, basic information as to the speakers
installation and operation.
F
EATURES
All RBH in-ceiling speakers use a swing out dog leg mounting system with pre-started screws for fast and
easy installation. RBH in-ceiling speakers feature directional swivel tweeters* used to direct the sound to the
main listening area. The TK-615, MC-615 and MC-815 feature polyswitch protection circuitry that is designed
to protect the tweeter from being overdirven. This circuit will automatically reset itself once the volume is
turned down or the problem causing the circuit to activate is removed.
Steep acoustic slope crossovers are used to integrate drivers. The use of steep crossover slopes allows high
power handling, minimizes driver interaction anomalies, and maximizes the clarity with which each driver is
able to produce its respective frequency band.
I
NSTALLATION
RBH in-ceiling speakers have been designed to make installation as easy as possible. Upon opening the
speaker boxes you will notice that the screws are prestarted into the dog legs. As shown in the diagram
below, installing RBH inwall speakers is easy and quick.
If using a New Construction Bracket (NCR-R) for the size of speaker being installed, cutting the drywall should
not be necessary. To install, attach speaker wire observing polarity, then position all dog legs in toward the
speaker magnet. Slide the speaker into the drywall, then tighten the screws. The dog legs will automatically
swing out and tighten (pinch) themselves against the New Construction Bracket (NCB-R) and the drywall
with the turning of the screw and will hold the speaker solidly in place. If using a drill/driver, set clutch to
a low setting to prevent overtightening and possible damage to the frame or dog legs. If using hand tools,
tighten just until firm.
When not using an New Construction Bracket (NCB-R), a cutout template is supplied with the speaker for your
convenience in cutting the drywall. After the hole in the drywall is made, install the speaker using the same
method described above. RBH inwall speakers can be installed into either the wall or the ceiling.
P
AINTING
RBH inwall speakers and grilles can be painted any color to match any decor. A plastic paint shield is sup-
This plastic paint shield must
plied to protect the speaker from becoming damaged during painting.
be removed before operation of the speaker begins.
*Except A-504D, A-505R, A-506
