- Page 1 Ultra Series Soundbar/ On-wall LCR Speakers O W N E R ’ S M A N U A L...
-
Page 3: Break-In Period
Care and Cleaning The unique grille for the Ultra Series has been designed to be as lightweight and acoustically transparent as possible and is held in place by magnets imbedded in the frame of the cabinet. - Page 4 1-inch aluminum tweeters with textured phase plugs make the thin cabinet yet big sound possible. Our ez-wire terminals and fast mounting, including direct-from-front screw-through mount holes (hidden until needed), make the Ultra Series speakers easier to install. The Ultra Series speakers provide effortless, quick, brilliant sound.
-
Page 5: On-Wall Installation
On-wall Installation To mount your Ultra Series speakers on a wall, determine a suitable location and complete all wiring to the speaker location before mounting the speaker to the wall. Be sure to check for wiring and drywall screws behind planned pilot hole locations. Do not ceiling-mount. - Page 6 On-wall Installation (continued) Pilot Hole Location Pilot Hole Location Keyhole Bracket Pilot Hole Location Pilot Hole Location Terminal Port Back diagram for the Ultra-1 on-wall speaker showing the keyhole braclets, pilot holes and terminal port. To use the “screw-through ez-mount” method, (allows for tighter fit to edge of TV). a.
- Page 7 In order to obtain the best possible sound from your speaker system, it is important to determine where the Ultra Series speakers will sound best in your listening room. Room reflections from the floor, ceiling and side walls influence the balance, imaging and overall sonic quality at the listening position.
-
Page 8: Specifications
Specifications Model Ultra-3 Ultra-1 Speaker Type: On-wall/LCR Soundbar Speaker On-wall/Surround Speaker Frequency Response: 100Hz-20kHz ±3dB 100Hz-20kHz ±3dB Sensitivity 84db 84db (2.38V @ 1M) (2.38V @ 1M) Recommended Power: 20-120 Watts 20-120 Watts Woofer: (6) 4” (102mm) Proprietary Inverted (2) 4” (102mm) Proprietary Inverted Aluminum Cone Woofers Aluminum Cone Woofers Tweeter:... -
Page 9: Troubleshooting
Warranty Your RBH Sound Ultra-3 soundbar speaker is covered by a limited warranty against defects in materials and workmanship for a period of 5 years from the original date of purchase.* This warranty is provided by the authorized RBH Sound dealer where the speaker was purchased. - Page 10 THIS PAGE WAS LEFT BLANK INTENTIONALLY...
- Page 12 382 Marshall Way, Layton, Utah • USA • 84041 Toll Free: (800) 543-2205 • Fax: (801) 543-3300 rbhsound.com It is RBH Sound policy to continuously incorporate improvements into our products; all specifications © are subject to change without notice. Copyright...
