Southwood Farnborough Hampshire GU14 ONY England Email: sales@loma-cintex.com Web: http://www.loma.com http://www.cintex.com The IQ³ Metal Detector and this documentation are copyright material. No part of this documentation may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, or computer language in any form or by any means without the prior written permission of Spectrum Inspection Systems.
Page 5
IQ³ + User Guide Supplement EC DECLARATION OF INCORPORATION / CONFORMITY We hereby declare that the following machinery is intended to be incorporated into other machinery and must not be put into service until the relevant machinery into which it is to be incorporated has been declared in conformity with the essential health and safety requirements of the Machinery Directive 98/37/EC.
IQ³ + User Guide Supplement Safety warnings Listed below are all the safety warnings that are used in this manual. It is strongly recommended that personnel who are, or will be, responsible for either installing, maintaining or operating the equipment described in this manual should read and understand these warnings. 1.
Page 7
Hence Loma Systems cannot be held responsible for meeting full requirements of OSHA or OHSA with regards to any equipment supplied, nor can Loma be held liable for penalty which may be assessed for failure to meet the requirements of the acts as interpreted by an authorised inspector.
Page 8
IQ³ + User Guide Supplement IQ³ + User Guide Supplement To be used in conjuction with the IQ³ User Manual...
Page 9
IQ³ + User Guide Supplement WARNING The control panel on this machine is fi tted with a USB socket for a mass storage device. In order to gain access to the socket, a waterproof cover must be removed. This cover must be replaced after access to the USB socket to maintain the waterproof rating of the machine.
IQ³ + User Guide Supplement Results Screen When power is applied the machine, it will come up in the Results Screen as shown: This top level screen shows the ongoing operating status of the detector, such as the product name being inspected and the number of rejects.
IQ³ + User Guide Supplement Blue Arrow – this is known as the “Go To“ button, and tapping it gives access to a screen which allows you to “go to“ other areas of the system to setup all aspects of the machine. •...
IQ³ + User Guide Supplement Quick Setup Guide To setup a new product is is necessary to edit, learn and run the new product. To do this, goto the Mimic Screen, then touch on the product. 1. Select the product number you wish to setup from the list. 2.
