IQ
+ ST Metal Detector User Guide
Document Number: 814206-3.0-ENG
ORIGINAL INSTRUCTIONS
Copyright © 2015 Loma Systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQ3+ST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Loma IQ3+ST

  • Page 1 + ST Metal Detector User Guide Document Number: 814206-3.0-ENG ORIGINAL INSTRUCTIONS Copyright © 2015 Loma Systems...
  • Page 3: Table Of Contents

    Document Key ............................. 4 Notes and Warnings ........................4 Hyperlinks ............................4 Copyright and Acknowledgements ...................... 5 The Loma Group of Companies ......................6 About Metal Detection ................7 How a Metal Detector Works ....................... 8 General ............................8 Balance Stability ..........................8 General and Foil Wrapped Products ....................
  • Page 4 Table of Contents Safety First ..................... 17 Safety Awareness ..........................18 EC Declaration of Conformity ......................18 Safety Warnings ..........................19 Safety Labels ............................. 20 Safety Guards ............................ 21 Guarding ............................21 Interlock switches ........................... 21 Safety Relay and Circuits....................... 21 Responsibilities and Disclaimer ......................
  • Page 5 Introduction Checking Belt Tracking (PV belt system only) ................48 Setting Up Reject Mechanisms ...................... 48 Remote User Interface ........................48 Installing a Serial Link ........................48 Site Considerations ........................... 48 Electromagnetic Compatibility (EMC) .................... 48 Selection of Frequency Band ......................49 Other EMC considerations ......................
  • Page 6 Table of Contents Lockable Reject Bin and Status Monitor ..................59 Pack Check Photo-eye ........................59 Getting Started ..................61 User Interface ............................ 61 User Access ............................62 Logging In and Out ..........................63 Logging In ............................63 Logging Out ........................... 64 Starting and Stopping ........................
  • Page 7 Coil Current ..........................126 Balance ............................127 EnviroScan ........................... 129 Product ............................133 Service ............................137 Engineer / Loma Service......................139 Search Head Setup ........................140 Conveyor Setup ........................... 143 Service Options ..........................146 GP I/O ............................148 VF Balance ..........................151 VF Drive ............................
  • Page 8 Table of Contents Relative Detectability of Non-Ferrous Metals ................164 Regular In-Line Detector Performance Testing ................165 Handling Rejected Products ......................165 Getting the Results .......................... 165 Frequency Selection ........................166 Operating Instructions ................167 Setting Up the Metal Detector ......................167 Setting the Time and Date ......................
  • Page 9 Introduction Contaminants Log ........................... 210 Purpose ............................210 Screen Contents .......................... 210 Batch Log ............................210 Purpose ............................210 Screen Contents .......................... 211 Configuring a Batch Log ......................211 Shift Log ............................213 Purpose ............................213 Screen Contents .......................... 213 PVS Log ............................
  • Page 10 Table of Contents Maintenance ..................225 Maintenance Warnings ........................225 Cleaning ............................225 Cleaning regime ........................... 225 Cleaning solutions ........................226 Belt conveyor versions ......................... 226 Air Regulator Unit Maintenance ...................... 227 Conveyor Belt Maintenance ......................227 Plastic Modular Belt Section Replacement .................. 227 Setting the Belt Tension and Tracking ..................
  • Page 11: Introduction

    This guide is copyright to Loma Systems. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, or computer language in any form or by any means without the prior written permission of Loma Systems.
  • Page 12: About This Guide

    Introduction About this Guide General This guide explains in plain language and by example how to use the IQ + ST Metal Detector Head and Conveyor. It begins with a conceptual overview of metal detection and then walks through the processes required to install, operate and maintain the machine.
  • Page 13: Organisation

    This guide is organised into the following chapters:  Introduction Guidelines provide an introduction to this guide and some general information, including global contact details for Loma Systems.  About Metal Detection Guidelines provide an introduction to metal detection, including an explanation of the basic principles and good practice guidelines.
  • Page 14: Document Change Control

    Users are actively encouraged to suggest changes or additions to the contents of this guide directly to Loma Systems by sending an email to manuals@loma.com. All document changes are processed in accordance with the standard Loma Systems document management system change process.
  • Page 15: Copyright And Acknowledgements

    Introduction Copyright and Acknowledgements Copyright © 2014 Loma Systems, a division of ITW Ltd. All rights reserved. Loma Systems Summit Avenue Southwood Farnborough Hampshire GU14 0NY England Email: sales@loma.co.uk Web: http://www.loma.com This document is copyright material. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language, or computer language in any form or by any means without the prior written permission of Loma Systems.
  • Page 16: The Loma Group Of Companies

    +48 22 575 70 25 Fax: +55 (0) 11 98455 1356 Fax: +48 22 575 70 01 comercial@brapenta.com.br E-mail: pl.sales@loma.com E-mail: Web: http://www.loma.com http://www.loma.com www.brapenta.com Web: For details of other Loma offices and the worldwide distributor network, please visit www.loma.com.
  • Page 17: About Metal Detection

    About Metal Detection Industrial metal detectors are used in the pharmaceutical, food, beverage, textile, garment, plastics, chemicals, lumber, and packaging industries. Contamination of food by metal shards introduced during the manufacturing process is a major safety issue in the food industry. Metal detectors are widely used and integrated into production lines and play a vital role in preventing contaminated products from reaching customers.
  • Page 18: How A Metal Detector Works

    ‘false triggering’. The robust construction and excellence in electronics and software design of Loma metal detectors provides a stable and reliable product where the likelihood of false triggering is minimised.
  • Page 19: Phasing

    Safety First Phasing The diagram below shows how the magnetic and conductive properties of a product affect the product phase angle. Utilising the ‘Learn’ feature provided in the IQ + ST Metal Detector, an average for the net signal received from a product during inspection is digitally processed to provide a phase angle and amplitude.
  • Page 20: Tracker Feature

    This could result in false triggering and rejection of good products. Loma Systems generally employ the use of fixed plastic guards fitted around both ends of the aperture. This serves a dual purpose in effectively preventing access to those areas and the accidental introduction of any metal contaminants.
  • Page 21 Each value shown is the diameter in millimetres (mm) of a spherical metal contaminant, as contained in Loma test wands. The detection performance figures quoted in the tables below are for indication purposes only and are based on previous experience with similar products and applications.
  • Page 22: Types Of Metal

    About Metal Detection Detector performance is also affected by the position of the contaminant in the aperture. The least sensitive point is located in the geometric centre of the aperture, so this ideally is where to test the detector performance each time if practical, to ensure consistency. As metal gets closer to the sides (coils) of the aperture, the signal generated becomes larger, making it easier to detect.
  • Page 23: Testing Metal Detector Performance

    Once again, if your company is a private label manufacturer, ensure that you agree upon any variation you make to testing procedures, in writing, with your retailer customers. To facilitate effective testing, all of Loma's Metal Detectors have an integral Performance Validation System (PVS) feature.
  • Page 24: Product Test Samples

    ‘Stale’ test packs may produce different product signals. Test Wands Loma Systems metal detectors are supplied with a set of plastic test ‘wands’ which contain spherical pieces of various metals in different sizes. These are convenient and easy to place into your test samples and also make the testing process even more efficient.
  • Page 25: Learn Feature

    Safety First The test log file in .csv format may also be downloaded onto a memory stick via the USB port and then opened for analysis in Microsoft Excel. Manual Testing When testing is carried out manually, the results must be manually recorded and should include the following: ...
  • Page 26: Update Learn

    About Metal Detection Update Learn The Update Learn process again consists of following on-screen instructions to pass a number of product samples through the detector aperture. This process can only be used for products that have already gone through a Full Learn process. A warning dialog will pop-up to inform you that a Full Learn is required if this has not been completed previously.
  • Page 27: Safety First

    This section provides further details.  Noise Levels Loma metal detectors do not emit a level of noise that is hazardous. However, in line with current legislation, the customer should verify that the overall noise levels within the operating environment are within defined limits.
  • Page 28: Safety Awareness

    A signed and dated EC Declaration of Conformity is provided with each metal detector delivered. Any modifications made to any part of the metal detector without the prior written agreement of Loma Systems will invalidate the EC Declaration of Conformity and also product warranty.
  • Page 29: Safety Warnings

    Safety First Safety Warnings Listed below are the safety warnings that are applicable when using a Loma metal detector. It is strongly recommended that personnel who are, or will be, responsible for installing, maintaining or operating the equipment described in this manual should read and understand these warnings.
  • Page 30: Safety Labels

    Hence Loma cannot be held responsible for meeting full requirements of OSHA or OHSA. with regards to any equipment supplied, nor can Loma be held liable for penalty which may be assessed for failure to meet the requirements of the acts as interpreted by an authorised inspector.
  • Page 31: Safety Guards

    Guarding For Loma metal detectors the use of guarding, including covers, panels, curtains and other methods is extremely important in order to restrict operators from accessing areas of the machine that are potentially hazardous whilst the machine is operating or to prevent exposure to potentially hazardous ionising and non-ionising radiation.
  • Page 32: Safety Measures

     Servicing and repair of the metal detector must be carried out by qualified Loma or approved customer personnel to avoid damaging the machine, which could result in the introduction of a safety hazard and the loss of warranty cover.
  • Page 33: Improper Use

    Loma metal detectors do not emit a level of noise that is hazardous. However, in line with current legislation, the customer should verify that the overall noise levels within the operating environment are within defined limits.
  • Page 34: Quality Assurance

    It is recommended that any suspect test wands are destroyed and replaced. Loma can supply a vast range of test wand types / sizes at-stock. Specials can also be made to order. Please email teststicks@loma.com...
  • Page 35: End User Licence Agreement

    + ST Metal Detector is licensed not sold. 1. Grant of Licence: Loma Systems shall at all times have and retain title and full ownership of all software, firmware programming routines, documentation supplied for use with the equipment and of all copies thereof made by Buyer (collectively “software”).
  • Page 36 Safety First THIS PAGE IS INTENTIONALLY LEFT BLANK...
  • Page 37: Technical Specifications

    Technical Specifications IQ3+ ST Metal Detector Head The technical specification for the IQ + ST Metal Detector Head is provided in the table below. Please note that this specification lists the available options in some cases. The exact specification for your metal detector head will depend on the options you have selected.
  • Page 38: European Belt Conveyors

    Technical Specifications European Belt Conveyors The technical specification for all European Belt Conveyors is provided in the table below. Please note that this specification lists the available options in some cases. The exact specification for your machine will depend on the options you have selected. General Each machine is designed to suit a customer's requirements.
  • Page 39: Installation

    This chapter provides generic information covering the installation of the Loma IQ + ST Metal Detector in a logical sequence, both as a head only and as a system with the head fitted to a Loma conveyor. The following sections provide more information: ...
  • Page 40: Warnings

    Receiving and Unpacking Receiving the Detector Head  On receipt of your Loma metal detector head, we recommend that you check the external packing for any signs of damage.  If the external packaging is damaged do not refuse the shipment but make a notation on the carriers delivery receipt and take pictures of the packaging damage.
  • Page 41 Installation  Lift the detector head carefully and move it to the required location.  Lower the detector head and remove the straps. Using a Fork Lift  Position the forks under the pallet and raise it sufficiently to clear of the ground and any obstacles.
  • Page 42: Detector Head Mounting Positions

    Installation Detector Head Mounting Positions This section contains standard mounting positions for Loma Metal Detector heads. When refitting the head control panel cover, the cover fixing screws must be tightened to 4Nm torque to maintain the integrity of the IP69K rating for the head; preventing ingress of...
  • Page 43 Installation...
  • Page 44: Mounting A Detector Head Onto A Conveyor

    Mounting a Detector Head onto a Conveyor Introduction Loma Systems have been manufacturing metal detector systems for many years and our current conveyor design incorporates this wealth of experience. There are a number of integration rules that have to be followed when fitting a new detector head to an existing or third party conveyor to attain optimal performance and avoid nuisance triggering.
  • Page 45 DRY mode. Loma metal detectors are designed to minimise any vibration or shock effects when operating with conductive products. To further enhance this resistance the conveyor must be designed with consideration to the above rules.
  • Page 46 Mounting Horizontal Heads for Use with Conductive Products Loma heads up to 350mm in height are supplied with an adjustable height mounting kit. The purpose of the height adjustment is to enable the centre line of the conductive product to pass through the “centre line”...
  • Page 47 Installation Moving metal excludes concentric rotating rollers. If they are concentric and can be guaranteed to stay that way, then they may be classed as fixed metal. However it is important to reiterate that they must be insulated from the conveyor at one end or it is possible that they will cause false triggering by creating an intermittent eddy current path.
  • Page 48: Connecting The Detector Head Electrical Supplies

    Post Installation Problems  Spurious Triggering The Loma range of detectors is the product of many years experience and development. They are inherently reliable, provided that it is installed and set up correctly. Remember that the detector can detect can detect moving metal anywhere within its metal free zone. This is up to a distance of 3 times the smaller of the aperture dimensions away from the detector.
  • Page 49 Installation To connect an electrical supply, proceed as follows: Remove the six front cover retaining bolts and drop down the cover until it is held against the supports Remove the screw from the top of the metal cover plate and lower it down carefully The Mains Filter is mounted inside the panel housing mounted on the right hand side.
  • Page 50 Input / Output Signal Information To connect to external devices a Relay kit, Loma part number 6120PL500, consisting of a relay module, a cable that connects the relay module to the mini control board and some cable ties, can be supplied.
  • Page 51: Installing A Metal Detector System

    On systems employing variable speed conveyors, special hardware is required to drive the CTB (conveyor time base) input on the micro control card. Conveyor systems supplied by Loma will already have this hardware fitted and commissioned, but when purchasing a detector head only, the following information should be observed when using a variable speed conveyor.
  • Page 52: Warnings

    Following completion of the installation, commissioning of the machine should be carried out by a Loma engineer. An important part of this process is to run an Auto Configuration process through the...
  • Page 53: Receiving And Unpacking

    Receiving and Unpacking Receiving the machine  On receipt of your Loma inspection machine, we recommend that you check the external packing for any signs of damage.  If the external packaging is damaged do not refuse the shipment but make a notation on the carriers delivery receipt and take pictures of the packaging damage.
  • Page 54: Adjusting / Levelling The Conveyor

    Do not start the machine and initiate the use of any compressed air before the Loma commissioning engineer has approved the installation. Except where a metal detector head only is being supplied, all Loma metal detector systems require a clean and dry compressed air supply, primarily to operate the optional automatic reject system.
  • Page 55 Installation  Reject Valve – The Reject Valve is attached to the pneumatic assembly and contains five ports as follows: o Air Supply Input Port – The air supply from the Dump valve is connected to the input. o Air Supply Output Port 1 – The air supply is fed to one side of a reject device. For example when fitted to one side of a double acting air cylinder, the air drives a rod attached to a nylon blade to push product off a conveyor into a reject bin.
  • Page 56: Connecting The Electrical Supplies

    Installation Therefore the only actions required are to connect the air supply to the input side of the air regulator using 10mm O/D tubing and set the air pressure using the regulator. The air pressure should be set to 80psi (5.5 bar) except when being used to supply an air-blast reject device when the pressure should be set to 100psi (6.9 bar).
  • Page 57 Installation To connect an electrical supply, proceed as follows: Unlock and open the Electrical Services Box to access the electrical services. The back of the Isolator Switch is located in the bottom right hand side of the cabinet when viewed from the rear. Beneath it on the bottom of the cabinet is the cable gland access for the power cable.
  • Page 58: Checking Belt Tracking (Pv Belt System Only)

    Installation Do not start the machine and initiate the use of any electrical circuitry before the Loma commissioning engineer has approved the installation. Checking Guards  Check that all guards are securely fastened in place.  On some conveyors that are made to special order, hatches may be fitted to permit access to some areas of the machine.
  • Page 59: Selection Of Frequency Band

    RF emissions if necessary. All Loma metal detectors are designed, and tested, to meet the requirements of the FCC and the new stringent European regulations for RF emissions, both in terms of not emitting excessively and not being subject to undesirable operation in the presence of other equipment whose emissions also meet the standards.
  • Page 60 Installation THIS PAGE IS INTENTIONALLY LEFT BLANK...
  • Page 61: About The Metal Detector Range

    The search head is available separately for fitting to your own conveyor or this can be supplied as a system, already fitted to a Loma conveyor. A Pipeline Metal Detector is also included in the range for inspecting pumped products.
  • Page 62: Metal Detector Search Heads

    Standard Features  Variable Frequency Capability - Loma is the only company in the industry that offers true variable frequency, operating between 40 - 900 kHz. This means that you can configure the same machine for use with a variety of products.
  • Page 63: Optional Features

    Conveyor Belts Loma conveyors are fitted with either flat belts which are suitable for use with lighter products or plastic modular belts which are suitable for use with heavier products in a harsher environment. The belts are positively driven from a central drive sprocket that is secured on a square-section drive shaft.
  • Page 64: Plastic Modular Belts

    The plastic modular belt conveyors use a belt constructed from injected-moulded plastic modules, assembled into an interlocked unit and joined by plastic hinge rods. The following table gives details of the three different plastic modular belt types supplied by Loma: Belt Type...
  • Page 65: Reject Devices

    About the Metal Detector Range Reject Devices Loma Systems offer a range of reject devices for removing contaminated products from your production line, based on a number of factors including the product type, its general dimensions, the general set up of your production line and of course how you wish to handle contaminated products.
  • Page 66: Air Blast

    About the Metal Detector Range Air Blast The Air Blast reject device is suitable for removing contaminated wrapped products from your production line using a high pressure blast of compressed air to push the contaminated product off of the conveyor belt and into a reject bin. Generally a single nozzle is specified but a second nozzle can be fitted when required to provide more control or to reject over or underweight packs into a separate reject bin where the metal detector is being used in combination with a checkweigher.
  • Page 67: Reject Bins

    An air pressure failure switch is fitted if the conveyor is supplied with either a pusher reject or a retracting band reject. The switch is set by Loma to operate if the pressure of the compressed air supply to the reject falls below 40psi (2.8 bar). The conveyor then stops.
  • Page 68: Optional Equipment

    About the Metal Detector Range Optional Equipment The following options are available, depending on the type of reject mechanism fitted: Option Stop On Detect Air Blast Pusher Retracting Band Audible Alarm 'Bin Full' Photo-eye LED Lamp Stack Overhead Electrical Services Product Guides Product Registration Photo-eye PVS Indicator Lamp...
  • Page 69: Overhead Electrical Services

    About the Metal Detector Range Overhead Electrical Services The Electrical Services Box may be mounted overhead instead of at the front of the conveyor as is standard. Product Guides Product guides are useful for centring products through the detector aperture and controlling product presentation to prevent skewing.
  • Page 70 About the Metal Detector Range THIS PAGE IS INTENTIONALLY LEFT BLANK...
  • Page 71: Getting Started

    When the IQ + ST Metal Detector head is supplied fitted to a Loma conveyor, the following switches and buttons are also provided, mounted on the Electrical Services Box:...
  • Page 72: User Access

    During installation and commissioning, the Loma Engineer will set and provide you with passwords for accessing all user levels, which you can then provide to staff as required.
  • Page 73: Logging In And Out

    It also includes access to features and functionality available to the Operator, Supervisor and Quality users. The user can set up data comms, rejects, conveyor settings, user options, search head settings, VF drives, languages and perform LOMA service functions When this access level is selected you will be able to access some screens that cause inspection to stop until you navigate away from the screen.
  • Page 74: Logging Out

    Getting Started Select the Engineer access level option. The User Accounts screen will be displayed containing a list of all user accounts set up at the selected access level. Select your account name in the list to display the Enter Password screen. Then enter your password number using the buttons provided and select the Tick button.
  • Page 75: Starting And Stopping

    This section provides guidance for starting and stopping the IQ + ST Metal Detector, including stopping the machine in an emergency. It is assumed that the search head is mounted on a Loma conveyor. The following procedures should only be carried out once all installation and commissioning activities have been completed and operators trained in the use of the machine.
  • Page 76: Emergency Stop

    Getting Started Emergency Stop To stop the machine in an emergency, proceed as follows: Press the red Emergency Stop button, located on the front of the Electrical Services Box. The conveyor will then automatically stop. Starting the Machine after an Emergency Stop To start the machine after an emergency stop, proceed as follows: Ensure that any issue that caused you to stop the machine has been cleared.
  • Page 77: The User Interface

    The User Interface The user interface, located on the front of the machine control panel, enables you to access all of the features and functionality provided by the IQ + ST Metal Detector. Through the user interface you can setup and manage all parameters required for inspecting products and for the general operation of the machine.
  • Page 78: Selection Options

    The User Interface This is known as the “Go To“ button, and tapping it displays the System Setup screen, providing access to other areas of the system for setting up all aspects of the machine. This is known as the "Back" button and tapping it displays the previous screen.
  • Page 79: Saving Settings

    The User Interface Keyboard When you tap into a field in which you can enter characters and numbers a keyboard will be displayed in a pop-up screen. You can enter characters and numbers by tapping on the keyboard buttons. Then tap on the green OK button to close the screen and save the entry into the selected field.
  • Page 80 The User Interface The screens that you are able to access are subject to the access level selected for your user account when it was set up for you. Main Run Screen The chart below displays the screens that can be accessed from the Main Run screen and the order in which they are available.
  • Page 81: Main Run

    The User Interface Main Run Purpose The purpose of the Main Run screen is to provide you with real time and historical information for the product that you are currently inspecting. This enables you to monitor exactly what is happening at any time and if necessary take some appropriate action.
  • Page 82 The User Interface A number panel displays the total number of products for a batch that have been passed through the machine for inspection and have been found to be free from any contaminants. This feature relies on a Product Registration Photo-eye being fitted to your system to count the total number of products passed through the machine for inspection.
  • Page 83: Select Product To Run

    The User Interface The currently set Threshold signal level is displayed in a number panel opposite the thick 'red' Threshold line on the product signal dial. Products with a signal value above this level will be rejected. Tap on the threshold value to display the Threshold pop-up screen to adjust it, and therefore the sensitivity of the detector: High numbers...
  • Page 84: Select Product To Setup

    The User Interface For each existing product its unique number and product name are displayed. A product may be chosen for inspection by selecting the row containing the product name. Other standard navigation features available in the screen are described in the General Navigation section.
  • Page 85: Product Options

    The User Interface A product may be chosen for inspection by selecting the row containing the product name and then selecting the Run option in the Product Options screen when it is displayed. Other standard navigation features available in the screen are described in the General Navigation section.
  • Page 86: Product Settings

    The User Interface Product Settings Purpose Before a product can be inspected a number of basic details and parameters for the product must be entered into the Product Settings screen which are then used by the metal detector software to control how the product is inspected.
  • Page 87 The User Interface Alternatively select the 'OK' green tick button and scan the product barcode with your barcode reader. Note that this field is only displayed in the screen if you are using a barcode reader and have enabled the 'Barcode reader' option in the Service Options screen. ...
  • Page 88 The User Interface Measure the product diagonally and enter that length to provide some tolerance and avoid the generation of false triggers and nuisance error messages; for example where the external packaging has curled up or packs are presented too close together. Tap in the Pack length field to display the pop-up numeric keypad screen and enter the pack length in millimetres.
  • Page 89 The User Interface o St. Steel test Tap in the S. steel test field to display the pop-up numeric keypad screen and enter the stainless steel (normally 304 annealed) test piece size in mm to be used for PV testing. Leave the field blank if this test piece should not be used as part of the PV test.
  • Page 90: Batch Reset

    The User Interface o Max limit lock Once the Max limit value for the product signal has been entered the value can be locked to prevent an automatic change during a re-Learn process. Tap in the option check box to select it. o Adjustment This field is used to set a percentage by which the product signal threshold may be changed.
  • Page 91: Threshold

    The User Interface Threshold Purpose The currently set product Threshold signal level is displayed in a number panel opposite the thick 'red' Threshold line on the product signal dial in the Main Run screen. Products with a signal value above this level will be rejected.
  • Page 92: Learn Options

    The User Interface Tap on the green tick ‘OK’ button to change the signal threshold value and close the screen. Tap on the red cross ‘Cancel’ button to close the screen without changing the signal threshold value. Learn Options Purpose The Learn Options pop-up screen is displayed by tapping on the current product signal value panel or the Learn icon in the Main Run...
  • Page 93: Update Learn

    The User Interface Screen Contents The screen only has one control which is a red cross ‘Cancel’ button. Tapping on the button cancels the Full Learn process and closes the screen. Alternatively, the screen will also be automatically closed if no activity is detected for a period of time. If the Full Learn is not successful this could be because you have selected the “”Dry”...
  • Page 94: Learn Setup

    The User Interface Learn Setup Purpose The Learn Setup screen contains the Learn parameters used by the detector for the currently selected product. Default values are used before the product has been Learnt but following completion of a Learn process the values are automatically updated based on the results achieved. The screen contains some options that are enabled manually and you may also change other parameter values if required.
  • Page 95 The User Interface Tap in the Max threshold field to display the pop-up numeric keypad screen and enter the value to be used.  Threshold This is the detectors working threshold, set after a completed Learn process. Tap in the Threshold field to display the pop-up numeric keypad screen and enter the value to be used.
  • Page 96 The User Interface Tap in the Head lock option check box to enable it.  Head RF gain This is a specialised setting for use with metallised film or very difficult conductive products. The head RF gain is adjusted through the software by changing the setting in this screen but may also be adjusted manually through the fitting of links onto the Transmitter Board.
  • Page 97: System Faults Log

    The User Interface  Working lock Enabling this option locks the Working mode setting, thus preventing the detector from changing it during a Full Learn process. Tap in the Working lock option check box to enable it. System Faults Log Purpose System faults are classified as serious and require immediate action.
  • Page 98  Problem: +12V out of spec - the +12V rail is less than 11.40V. o Action: – Contact your local Loma service centre for assistance.  Problem – Verdict too late - a pack has arrived at the reject point before the detector has sent a reject decision.
  • Page 99 The User Interface 2. Check the sensor is working correctly.  Problem: Bin full - the reject bin full sensor has been blocked for longer than 5 seconds and the transport system has stopped. The bin will need to be emptied before the transport can be restarted.
  • Page 100: Select Access Level

    The User Interface 1. Perform an update checksum from the tick button found in the Search Head Setup screen. 2. Perform a hardware cold start by moving link JP6 across pins 1-2 from 2-3 on the Control Board, then power on/off This will wipe all system and product setup data from the detector.
  • Page 101: User Accounts

    The User Interface  All other levels Selecting any other access level when logging in displays the User Accounts screen which contains a list of User Accounts that have access to that level. Selecting an account displays a pop-up ‘Enter Password’ numeric keypad so that you can enter the appropriate password for that account.
  • Page 102: System Setup

    The User Interface System Setup Purpose The System Setup screen is displayed by tapping on the "Go To“ button in the Main Run screen. It displays a mimic of the metal detector and contains a number of hotspots which provide quick access to other screens through which all the parameters for setting up and operating the metal detector can be configured.
  • Page 103: System Settings

    The User Interface Tapping within one of the boxes then displays a related screen as described in the table below. Display the System Settings screen through which you can access and manage all system parameters. Displays the Select Product to Setup screen through which you can add, edit and remove products and their settings.
  • Page 104 The User Interface Tap on the Users icon to display the User Accounts Setup screen through which you can add, edit and delete user accounts. Tap on the Display icon to show the Display screen whcih provides access to other screen for setting up the system time and date, the display appearance, the system language and other general settings.
  • Page 105: User Accounts Setup

    The User Interface User Accounts Setup Purpose The User Accounts Setup screen is displayed by tapping on the Users icon in the System Settings screen. Through this screen you can add, edit or delete User Accounts. Screen Contents The screen contains a list of User Accounts showing their access levels and a number of buttons on the right hand side of the screen that are described in the table below.
  • Page 106: User Account Details

    The User Interface User Account Details Purpose The User Account Details screen is displayed by tapping on either the Add User or Edit User button in User Accounts Setup screen. The screen is used to enter the account details for all users. Edit mode Add mode Screen Contents...
  • Page 107: Display

    The User Interface Display Purpose The Display screen is displayed by tapping on the Display icon in the System Settings screen. The purpose of the screen is to provide access to screens that affect how information is displayed in the user interface. Screen Contents The screen contains a number of icons described in the table below which when selected provide access to other screens or start a process.
  • Page 108: Calendar

    The User Interface Calendar Purpose The Calendar screen is displayed by tapping on the Calendar icon in the Display screen. The purpose of the screen is to allow you to change the time and date used by the metal detector, useful where your local time is different to GMT.
  • Page 109 The User Interface Screen Contents The Learn Setup screen contains the following parameters for configuration:  Restore defaults? Tapping on the green tick button resets all of the parameters contained in the screen to their default values.  Dials pointer / hub Tapping on the colour panel displays a pop-up colour palette screen shown below.
  • Page 110 This feature allows you to select your own company image or logo to be used by the metal detector for display on initial start up. Tapping on the default Loma logo displays a standard file browser dialog showing the My Device folder contents on the metal detector Windows operating system. You can copy your image from a connected USB memory stick to the folder.
  • Page 111: Resultant

    500. Note that these are effectively cosmetic settings only and do not affect the operation of the detector. This feature is for advanced users only. Please contact your Loma Service Centre before using this feature.
  • Page 112: Language Setup

    The User Interface The formula for calculating the Resultant value (X ) to be displayed is Slope (a) x X (Product Signal) + Constant (c) or X = aX + c, as shown in the screen title bar.. So if we change the the Resultant value of 55 shown in the screenshot above to 120, we need to add a Slope (a) value of 2 and a Constant (c) value of 10, so that X = 2 x 55 + 10 = 120, as shown in the screenshot below.
  • Page 113: Calibrate

    The User Interface  Edit button If the flag for the required language is not displayed for selection, tapping on the Edit button located on the right hand side of the title bar at the top of the screen, will display other options as shown in the screen shot below, through which additional languages may be selected for inclusion in the Language Setup screen.
  • Page 114: Clean Screen

    The User Interface Clean Screen Purpose You may wish to clean the touch screen from time to time with a damp cloth or sponge but touching the screen whilst it is active could inadvertently change a setting. To resolve this issue the Clean Screen feature disables the touch screen for a defined period of time, shown in a progress bar, during which you can clean the screen without affecting anything.
  • Page 115: Batch Control

    The User Interface  System faults Tapping in this option check box will enable exporting of the System Faults Log.  Setup Tapping in this option check box will enable exporting of the Setup Report.  Learn Tapping in this option check box will enable exporting of the Learn Report.
  • Page 116 The User Interface o Traceability code Tap in the option check box to enable this option which enables you to assign a trace code to each batch. o Code This field is displayed when the Traceability code option is selected. Tap in the field to display a pop-up keyboard and enter the required batch code to be used.
  • Page 117: Shift Control

    The User Interface The keyboard also pops-up for you to enter a new batch code after resetting the batch totals to zero in the Main Run screen. Shift Control Purpose The Shift Control screen is displayed by tapping on the Shift Control icon in the System Settings screen.
  • Page 118: User Options

    The User Interface User Options Purpose The User Options screen is displayed by tapping on the User Options icon in the System Settings screen. The purpose of the screen is to allow you to enable or disable some of the optional features available in the detector.
  • Page 119: Pvs Setup

    The User Interface  Password character Tap on the arrow to the right of the field to display a drop down list of options for setting the format to be used for user passwords. Selecting the “0-9” option means that users will need to enter a numeric password that contains numbers only.
  • Page 120 The User Interface Once a successful inspection of the Fe test wand has been completed, the user is prompted to pass the same test wand through the detector a number of times, set in the Number of passes field in this screen, until they have all passed inspection and the test is complete in the PVS screen as shown below.
  • Page 121 The User Interface o Interval Selecting this option means that the user will be automatically prompted to initiate a PV test after a specified time. A separate PVS dial is displayed on the main Run screen and the pointer will count down the time until a PV test is due. An interval of 6 minutes, which is the minimum time interval you can set, was used for the example screen shot below Once the PV test is due the PVS panel goes red and an error message is displayed.
  • Page 122 The User Interface A Product Registration Photo-eye must be fitted to use the Interval and Batch options.  Interval This option only appears when the Interval Test timing option is selected. It is used to set the time interval in hours and minutes between carrying out PV tests. See the Interval information under Test timing above for further details.
  • Page 123: Software

    The purpose of the screen is to display the currently installed software versions to the user. This is useful information to provide to Loma Service Engineers when reporting an issue as they can then investigate whether the issue can be resolved by carrying out a software upgrade.
  • Page 124: Remote Support

    The User Interface Remote Support Purpose If the metal detector has been connected to a network, tapping on the Remote Support icon in the System Settings screen enables users to connect remotely to the metal detector from their PC using the VNC Viewer.
  • Page 125: Auto-Learn Settings

    LomaOPC application and the reply sent, enter or change the communications Port number that the metal detector will use to communicate with the LomaOPC or Loma TRACS applications and view any diagnostic messages.
  • Page 126 The User Interface If a Product Registration Photo-eye is NOT fitted, selecting this option means that when a Learn process is started, the system requests that you pass packs (product samples) through the detector for a period of 20 seconds. The time remaining to pass packs is displayed on the screen.
  • Page 127 Tap in the field to display a pop-up numeric keypad and enter the value required. The default value is 20.  Learn messages This feature is generally for Loma Service use only. If enabled, additional diagnostic messages will be displayed during the Learn process. The following table lists the messages that may appear during calibration:...
  • Page 128: Lomaenet Capture

    Check that the sample pack is representative of a production pack (eg. for frozen product, the sample pack must be frozen). If in doubt, call your nearest Loma Service Centre. The detector is reducing the Gain to account for the product effect of the +Gain reducing+ product.
  • Page 129 The User Interface  Settings This tab displays the network address details for the metal detector and allows you to enter the IP address and Port number for the server on which the LomaEnet Capture application has been installed so that they can communicate to each other, e.g. the metal detector can send the application a report.
  • Page 130: Lomaopc Server

    The LomaOPC application is typically installed onto a dedicated server. All Loma machines sending reports and live data to LomaOPC will need to be on the same network layer as this server. When LomaOPC is enabled, reports will be saved to a SQL database and live data will be provided across the network via OPC tags.
  • Page 131 The User Interface  Settings This tab displays the network address details for the metal detector and the Port number to be used by the detector to communicate with the LomaOPC application. To change the Port number, tap in the Machine port number field to display a pop-up numeric keypad and enter the required value.
  • Page 132: Serial Comms Setup

    The User Interface Serial Comms Setup Purpose The IQ + ST Metal Detector has built in Ethernet capabilities for LomaEnet and LomaOPC but for transmitting and receiving LomaLink and resultant data, a serial connection is required. The Serial Comms Setup screen is displayed by tapping on the Serial icon in the Advanced Settings screen and its purpose is to allow you to set up a serial connection, selecting what data type is to be transmitted and/or received and the data protocol to be used.
  • Page 133: Diagnostics

    The User Interface o Lomalink Select this option if you wish to create a connection with the LomaLink application for two-way communication and control. LomaLink enables data to be requested from and sent to the metal detector, and enables remote control of the metal detector. o Reports Select this option if you wish to send Reports and Logs over the serial connection either manually or automatically.
  • Page 134: Pq Analysis

    Diagnostics screen. This screen is intended for use by Loma Service Engineers or Customer Engineers only following the replacement of a Control board. It is used to balance out the P and Q channel signals being received from the Receiver board, when the detector is transmitting a signal but not inspecting products, by applying a positive or negative DC offset to each channels analogue to digital convertor on the Control board.
  • Page 135 The User Interface Screen Contents The screen contains the following:  P signal The current P channel quiescent signal value is displayed, along with the average signal value.  Q signal The current Q channel quiescent signal value is displayed, along with the average signal value.
  • Page 136: Coil Current

    Diagnostics screen. This screen is intended for advanced diagnostics use by Loma Service Engineers or Customer Engineers only. It displays the configuration and run current values and can be used to restore the drive for the frequency in use by the currently running product.
  • Page 137: Balance

    The Balance screen is displayed by tapping on the Balance icon in the Diagnostics screen. This screen is intended for advanced diagnostics use by Loma Service Engineers or Customer Engineers only. It displays the balance values for all or individual system frequencies in a graphical format to assist in analysis of the detector operation.
  • Page 138 The User Interface Tapping on the Capture button with the Frequency tab selected starts a process that steps through each of the 70 available frequencies, captures the balance values at each frequency and displays them on a graph which updates in real time ...
  • Page 139: Enviroscan

    This will maximise the performance of the detector. A scan is generally carried out by the Loma Service Engineer when carrying out commissioning of the metal detector before use.
  • Page 140 USB memory stick. On the P v Q graph, up to 10,000 raw P,Q values will also be saved as a CSV file for offline analysis. The saved raw data can be analysed on another computer or alternatively, sent to Loma Service for analysis.
  • Page 141 The User Interface Tapping on the Reset button with the P v Q tab selected starts a process that captures a graphical signal "noise ball" for the system when no product is passing through the head. This can help to identify sources of RF interference or contamination on the belt. By passing uncontaminated product through the metal detector, the full range of expected P,Q values during production can be displayed.
  • Page 142 The User Interface Tapping anywhere within the graph pops up the Frequency screen which displays a list of the 70 available frequencies. Tapping on a frequency selects it and closes the screen. The selected frequency is then used and displayed in the graph. ...
  • Page 143: Product

    If there are values in the Retries, Corruptions, Tx fails or Rx fails fields you are advised to contact Loma Service for assistance. The following items and information are displayed at the bottom of the screen: ...
  • Page 144 The User Interface A standard file browser dialog is displayed. Double-tap on the ‘LomaIQ3’, ‘Diagnostics’ and ‘Product’ folders in turn to display the available data files. Then tap on the required file to select it and tap on the OK button to close the dialog and load the data from the selected file. The data will initially be displayed in the P,Q v T screen but other screens can be selected as normal to display the data using the Screen Selection drop down list at the bottom of the screen.
  • Page 145 The User Interface The information displayed in each of the selectable screens is as follows:  Settings screen The Settings screen is selected by default when the Product screen opens. It displays the detector settings for the currently selected product which are mostly manually entered through Learn Setup screen and automatically selected by the detector as part of the Learn process.
  • Page 146 The User Interface  Phase v T screen The Phase v T screen displays two graphs showing the phase angle and rate of change of the phase angle against time for the product signal. The Min, Max and Mag (combined) angles are also displayed.
  • Page 147: Service

    The Service screen is displayed by tapping on the Service icon in the Advanced Settings screen. The purpose of the screen is to provide Engineers and Loma Service Engineers access to a number of service screens that provide options for setting up the metal detector.
  • Page 148 The screen contains a number of icons described in the table below which when selected provide access to other screens. Tap on the Engineer icon to display the Engineer / Loma Service screen in which you can copy and load product settings using a USB memory stick and carry out advanced actions to debug the system.
  • Page 149: Engineer / Loma Service

    Service screen. The purpose of the screen is to enable Engineers and Loma Service Engineers to copy and load product settings using a USB memory stick, use the detector setting for Product #1 for all products set up in the system and carry out advanced actions to debug the system.
  • Page 150: Search Head Setup

    The User Interface Search Head Setup Purpose The Search Head Setup screen is displayed by tapping on the Head Setup icon in the Service screen. The purpose of the screen is to configure the detector hardware settings required for the detector to work correctly.
  • Page 151 The User Interface  GP I/O The GP I/O board provides additional functionality as described below in the GP I/O screen section. Options of Enabled and Disabled are available for selection. The Enabled option must be selected to use the functionality provided by the board. Tap the arrow to the right of the field to display the drop down list of options and select the option to be used.
  • Page 152 The User Interface o Aperture dimension in the range of 150 - 200mm - depending upon the band selected, use the 300kHz upwards range. o Aperture dimension in the range of 225 - 300mm - depending upon the band selected, use the 203kHz upwards range.
  • Page 153: Conveyor Setup

    The User Interface Tap the arrow to the right of the field to display the drop down list of available lamp type options and select the one to be used.  Noise filter This option allows you to select the type of low-level filter to use to convert raw signals into a resultant signal.
  • Page 154 The User Interface  PEC length To ensure the correct operation of the detector and reject systems it is extremely important to ensure that this setting is correct. The calculation for this entry measured in mm or inches depends on the Units option selected in the Search Head Setup screen.
  • Page 155 The User Interface The value entered is derived from the relationship between the shaft encoder and circumference of the roller to which it is fitted. This parameter is the number of pulses (ticks) per metre/foot of belt travel. To calculate this figure for entry into the CTB constant field, use either the following metric or imperial formula: o Metric systems π...
  • Page 156: Service Options

    The User Interface Service Options Purpose The Service Options screen is displayed by tapping on the Service Options icon in the Service screen. Through this screen you can enable and configure a number of options covering the Learn process, rejects, products and data communications. Screen Content Select or enter the appropriate parameter values in the screen as follows: ...
  • Page 157 Dry products, access should be disabled to avoid incorrect use. Access is generally enabled by a Loma Service Engineer when the Ferrite product needs to be re-learnt following replacement of a a circuit board or upgrading of the detector software..
  • Page 158: Gp I/O

    The User Interface Select this option to activate a handheld serial barcode reader on the detector. A Barcode field is then included in the Product Settings screen so that you may enter the barcode to be used for each product. Barcodes can be used to change the current product automatically. Tap in the option check box to enable or disable it.
  • Page 159 The User Interface Screen Contents The screen is divided into two tabs which are described below.  Settings Tab This tab is displayed by default when the screen opens. It contains the options listed below. The current status of each selected option is then constantly monitored and displayed in the Status Tab.
  • Page 160 The User Interface o Confirm switch Select this option to monitor whether the reject confirmation switch is activated or not.  Status Tab This tab is used to monitor inputs and outputs on the GP I/O board. Outputs can be toggled by tapping on the button alongside the relevant output.
  • Page 161: Vf Balance

    The User Interface o Outputs To test any output, tap the circle for the output to be tested. When this screen is exited, all outputs are returned to their correct state.  PVS required - (output 01) Set when a PV test is due. Typically, this output is used to light a lamp which will alert operators that a PV test is required.
  • Page 162 When the detector has been configured correctly, the measured balance will generally be lower than the balance setpoint. If in doubt contact your local Loma service centre for assistance.  Auto configure Selecting this option starts the AutoBalance process for all operating frequencies. The process commences by resetting the potentiometer positions for the P and Q channels for each frequency to 50.
  • Page 163: Vf Drive

    AutoBalance feature by selecting the Auto configure option which automatically makes any P and Q channel balance adjustments necessary for each of the available frequencies. Manual adjustment is also possible and this is carried out by Loma Service Engineers when required.
  • Page 164 Config current value set. Larger aperture detectors operating at above 600kHz are likely to show a lower value. If in doubt contact your local Loma service centre for assistance.  Auto configure Select this option to start the full setup process for all operating frequencies.
  • Page 165: Rejects Setup

    If only the orange led is illuminated then the transmitter is still in safe mode. In this case, try lowering the on time value a little more and perform another restore drive. If the red LED stays on then contact your local Loma service centre for assistance. Rejects Setup Purpose...
  • Page 166 The User Interface  Mode The following Mode options are provided for selection: o Pulse (only available if a photo-eye is fitted) If this option is selected, when a contaminated package is detected the reject delay time is counted down, in order for the package to travel from the photo-eye to the reject device, where-upon the reject is turned on for a time equal to the reject dwell time.
  • Page 167 The User Interface Tap on the arrow to the right of the field to display the list of Relay options and select the appropriate one.  Timing Two timing options are available for selections as follows: o Product relative If this option is selected, you can set the Reject dwell and delay times to different values for each product in the Product Settings screen.
  • Page 168 The User Interface Tap in the option check box to enable or disable it.  Confirmation Enable this option if a Reject Confirmation Photo-eye is fitted to your system. This photo-eye is fitted across the entrance to the reject bin to confirm that the contaminated product has entered the bin.
  • Page 169 The User Interface  Check delay Set this to compensate for the time it takes for the pack to move from the reject device to the Pack Check Photo-eye. Setting this allows the Check window to be set as accurately as possible.
  • Page 170: Help Manual

    Product Registration Photo-eye has been installed. Tap in the option check box to enable or disable it.  Disable rejects? Tapping this button temporarily disables the reject device. This feature is intended for Loma Service Engineer use only. Help Manual...
  • Page 171 The User Interface Help Manual - Table of Contents Selected File (displayed in a new window) Tapping on the red cross Cancel button in the title bar at the top of the Help screen will close the screen. Tapping on the button in the Help Manual screen will close the screen and display the System Setup screen.
  • Page 173: Using The Metal Detector

    Using the Metal Detector This chapter provides general information about using the metal detector, including some guidance on setting up the detector to provide the best results. The following sections provide more information:  Good Practice This section provides some guidance for maintaining an effective metal detection regime. ...
  • Page 174: Establishing Detector Performance

    Loma Systems can supply a selection of sizes and types of metal test wands for attaching to product samples for testing purposes. There are three types of wands: ferrous (chrome steel), non-ferrous (brass), and 304 stainless steel.
  • Page 175: Regular In-Line Detector Performance Testing

    Using the Metal Detector It is also possible to phase out a particular size of non-ferrous contaminant but be able to detect a smaller or larger size. This is because the metal signal matches the product signal and has been compensated out.
  • Page 176: Frequency Selection

    Using the Metal Detector Frequency Selection This metal detector can run at a choice of seventy different operating frequencies so that the optimum frequency can be chosen for any given product. Generally, dry products run at high frequencies, but more conductive and non-uniform products run at low frequencies. The frequencies are split into 10 bands as shown in the table below.
  • Page 177: Operating Instructions

    Operating Instructions This chapter provides general information about using the metal detector, including some guidance on setting up the detector to provide the best results. The following sections provide more information:  Setting Up the Metal Detector This section provides guidance for setting up some basic features of the metal detector. ...
  • Page 178: Setting The Time And Date

    Operating Instructions Setting the Time and Date It is important that the correct time and date are set on the machine as they are used to time stamp the data in the contaminant, fault and error logs and are shown on the reports. In addition they determine the interval and synchronisation of automatically initiated PV tests.
  • Page 179: Setting The Language

    Operating Instructions To change the time, tap on the hours, minutes and seconds value fields in turn and use the up and down arrows to set the required values. Also see the Calendar screen section for further details. Setting the Language The following procedure provides an example of changing the system language from English to French.
  • Page 180 Operating Instructions From this screen you can select the required language by tapping on the appropriate flag icon to select it. We want to select the French language but a French flag is not displayed Tap on the Edit button in the top right hand corner of the screen. Further options are displayed.
  • Page 181: Setting The Machine Id

    Operating Instructions Tap on the flag to select the language and then tap on the Back button . The Save Settings pop-up screen will be displayed. Note that the text is now displayed in French. Tap on the green tick 'OK' button to save the language change. The text in all screens will now be displayed in French.
  • Page 182 Operating Instructions Then tap on the Service icon to display the Service screen. Tap on the Head Setup icon to display the Search Head Setup screen. Note that the detector will stop inspecting whilst you are in any Service screen, as indicated by the red message Inspecting!displayed at the bottom of the screen.
  • Page 183: Setting User Access Levels And Passwords

    Operating Instructions Setting User Access Levels and Passwords User accounts are used to manage access to the features and functionality available in the metal detector. Four access levels are available which are described in the User Access section. To set a user access level and password, proceed as follows: Tap on the control panel area in the System Setup...
  • Page 184: Configuring The Metal Detector

    Configuring the Metal Detector Wherever possible, configuration of the metal detector will be carried out by Loma Systems before the machine is dispatched, or by a Loma Service Engineer during a commissioning visit. Primarily, the commissioning visit is required as part of the installation process so that the engineer can optimise machine performance in its actual working environment and for the products that are to be inspected.
  • Page 185: Setting Up The Search Head

    Operating Instructions Setting Up the Search Head Setting up of the detector search head is carried out in the Search Head Setup screen which when selected takes the detector out of run mode so that it is not inspecting products. The options and parameters within this screen contain basic set up data that the detector requires before it is able to correctly function.
  • Page 186: Setting Up The Conveyor

    Operating Instructions You can now select the required options and enter the appropriate parameter values to set up the search head. See the Search Head Setup screen section for further details. Once you have finished entering the required details, tap on the Back button to display the Save Settings pop-up screen.
  • Page 187 Operating Instructions In the Advanced Settings screen, tap on the Service ison to display the Service screen. Then tap on the Conveyor icon to display the Conveyor Setup screen. You can now select the required options and enter the appropriate parameter values to set up the conveyor.
  • Page 188: Setting Up The Service Options

    Operating Instructions Setting Up the Service Options Service Options are set up in the Service Options screen through which certain user options and facilities may be turned on and off, as appropriate to your machine application. To set the service options, proceed as follows: In the System Settings screen, Tap on the Advanced icon to display the Advanced Settings...
  • Page 189: Setting Up The Monitoring Services

    Operating Instructions You can now select the required options and enter the appropriate parameter values to set up the service options. See the Service Options screen section for further details. Once you have entered the required details, tap on the Back button to display the Save Settings pop-up screen.
  • Page 190 Operating Instructions Then tap on the Service icon to display the Service screen. Tap on the GP I/O icon to display the GP I/O screen. Note that the detector will stop inspecting whilst you are in any Service screen, as indicated by the red message Inspecting!displayed at the bottom of the screen.
  • Page 191: Setting The Vf Balance

    AutoBalance feature which automatically makes any P and Q channel balance adjustments necessary for each of the available frequencies. Manual adjustment is also possible and this is carried out by Loma Service Engineers when required. To set up the VF balance, proceed as follows:...
  • Page 192: Setting The Vf Drive

    AutoBalance feature which automatically makes any P and Q channel balance adjustments necessary for each of the available frequencies. Manual adjustment is also possible and this is carried out by Loma Service Engineers when required. To set up the VF drive, proceed as follows:...
  • Page 193 Operating Instructions Then tap on the Service icon to display the Service screen. Tap on the VF Drive icon to display the VF Drive screen. Note that the detector will stop inspecting whilst you are in any Service screen, as indicated by the red message Inspecting!displayed at the bottom of the screen.
  • Page 194: Setting Up The User Options

    Operating Instructions Setting Up the User Options User Options are set up in the User Options screen which enables/disables many of the detector functions using a tick box system. If a function is unavailable because perhaps a setting in another menu requires enabling, the tick box is greyed out.
  • Page 195 Operating Instructions To set up a serial link, proceed as follows: In the System Setup screen, tap on the Advanced icon to display the Advanced Settings screen. Then tap on the Serial icon to display the Serial Comms Setup screen. Select the options and enter the appropriate parameter values in the screen.
  • Page 196: Performing A Ferrite Tune

    Operating Instructions Performing a Ferrite Tune A “Ferrite“ product is set up during manufacture of the detector head to provide a baseline configuration for inspecting “Dry“ products which exhibit no product effect during inspection. A part of this process a “Ferrite Wand“, similar to a Test Wand but much larger and containing a sample of pure iron, is used to carry out a Full Learn process.
  • Page 197 Operating Instructions Then tap on the Service icon to display the Service screen. Tap on the Service Options icon to display the Service Options screen. Then select the Access ferrite option. Navigate back to the System Setup screen using the Back button at the bottom of the screen.
  • Page 198 Operating Instructions Then tap on the product area to display a list of products in the Select Product to Setup screen and tap on the FERRITE product. The Product Options screen is displayed. Select the Run option. The Main Run screen is displayed with the FERRITE product selected to run. Tap on the Learn icon to display the Learn Options...
  • Page 199: Setting Up Product Signal Tracking

    Operating Instructions Perform a Full Learn whilst moving the end of the ferrite wand with the sample in and out of the search head; taking care not to put your hand in or get any watches/rings near the search head. On systems fitted with a Product Registration Photo-eye, block the photo-eye to register that packs are present.
  • Page 200 Operating Instructions Enabling the Tracker Feature To enable the tracker feature, proceed as follows: In the System Settings screen, tap on the Advanced icon to display the Advanced Settings screen. Tap on the Service icon to display the Service screen. Then tap on the Conveyor icon to display the Conveyor Setup screen.
  • Page 201 Operating Instructions Tap on the PEC enable option check box to select it. Tap on the Back button to display the Save Settings pop-up screen. Then tap on the green tick 'OK' button to save the changes and close the screen. The Service Screen is displayed.
  • Page 202 Operating Instructions Tap on the Back button to display the Save Settings pop-up screen. Then tap on the green tick 'OK' button to save the changes and close the screen. The Tracker feature is now enabled and can be selected for use with any product Enabling and Configuring Tracker for a Product To enable the tracker feature for a product, proceed as follows: Navigate to the...
  • Page 203 Operating Instructions Tap on the Back button to display the Save Settings pop-up screen. Then tap on the green tick 'OK' button to save the changes and close the screen. The Tracker feature is now enabled fir the selected product. Setting Up the Reject Options Reject options for the reject devices fitted are configured in the Rejects Setup...
  • Page 204: Adding A New Product

    Operating Instructions Adding a New Product This section explains how to add a new product, following which a Full Learn should be carried out to capture and save the metal detector settings for inspecting the product. To add a new product, proceed as follows: Navigate to the Select Product to Setup screen.
  • Page 205: Learning Products

    Learning Products An essential part of inspecting products is to set up the metal detector parameters specifically for each product to optimise the detectors performance for each one. Loma metal detectors provide a Learn feature which automates this process. The Learn process to be followed for both...
  • Page 206: Learning A Product

    Operating Instructions Learning a Product To Learn a product, proceed as follows: From the Select Product to Setup screen, tap in the list on the product that you wish to Learn. The Product Options pop-up screen is displayed. Tap on the Run option to select it to load the product parameters. Once the parameters have been loaded the Main Run screen is displayed.
  • Page 207 Operating Instructions See the Learn Setup screen section for detail of the options and parameters available in the screen. Once you have entered the required details, tap on the Back button to display the Save Settings pop-up screen. Then tap on the green tick 'OK' button to save the changes. Use the Back button to navigate back to the Main Run screen.
  • Page 208: Reverse Learn

    Operating Instructions Reverse Learn This menu option replaces the Full Learn option. It will only appear when the Reverse detection option is enabled in the Service Options screen and the Detection option is set to Reverse in the product Settings screen. Select the Reverse option in the Learn Options screen to initiate a Reverse Learn process for the...
  • Page 209: Using Performance Validation

    Operating Instructions Using Performance Validation This section describes the benefits of the Performance Validation System and explains how to set up the metal detector for PV testing, with information about each of the parameters that need to be specified. Regular checking of the metal detector’s sensitivity should be a normal part of any quality assurance procedure.
  • Page 210: Enabling The Pvs Feature

    Operating Instructions Enabling the PVS Feature To start using PV testing, proceed as follows: In the System Settings screen, tap on the User Options icon to display the User Options screen. Then tap on the PVS option check box to enable the option. Tap on the Back button to display the Save Settings pop-up screen.
  • Page 211: Enabling Pv Testing For A Product

    Operating Instructions You can now enter or select the appropriate test parameters which are listed and described in the PVS Setup screen section. Tap on the Back button to display the Save Settings pop-up screen. Then tap on the green tick 'OK' button to save the changes and close the screen. The Tracker feature is now enabled and can be selected for use with any product Enabling PV Testing for a Product To enable PV testing for a product, proceed as follows:...
  • Page 212 Operating Instructions THIS IS PAGE INTENTIONALLY LEFT BLANK...
  • Page 213: Logs And Reports

    Logs and Reports This chapter provides information about the available logs and reports that are generated from information automatically collected by the IQ + ST Metal Detector. Tapping on the folder area in the System Setup screen displays the Logs/Reports screen which provides a list of available logs and reports for selection.
  • Page 214: Run Errors Log

    Logs and Reports  Diagnostics Log This section describes how to produce the log and an explanation of some example problems that may be included in the log.  Setup Report This section describes how to produce the report, which can be automatically created and sent when changing product or can be manually requested from the Setup Report screen.
  • Page 215: Screen Contents

    Logs and Reports Screen Contents The screen displays a list of errors under the following column headings:  Date – Displays the date that the error occurred.  Time – Displays the time that the error occurred.  Problem – Displays a brief description of the reason why the error has been generated. See Example problems below.
  • Page 216: System Faults Log

    230 - 250mA range if operating at frequencies above 650kHz. If the message persists or the user is in doubt then contact your local Loma Service Centre for assistance. System Faults Log Purpose System faults are classified as serious and require immediate action.
  • Page 217: Screen Contents

     Problem: +12V out of spec - the +12V rail is less than 11.40V. o Action: – Contact your local Loma service centre for assistance.  Problem – Verdict too late - a pack has arrived at the reject point before the detector has sent a reject decision.
  • Page 218 Logs and Reports  Problem: Rej confirm fail - the reject system has attempted to reject a pack but could not confirm that the pack entered the reject bin and was removed from the line, within the specified time. When this fault occurs, the conveyor should be cleared before the transport can be restarted.
  • Page 219 Logs and Reports  Problem: Link corrupted - data corruption has occurred between the detector and LomaLink PC or other controlling device. The operation of the detector is unaffected. o Actions: 1. Check cabling and link connectors from remote device. 2.
  • Page 220: Contaminants Log

    Logs and Reports Contaminants Log Purpose The Contaminants Log contains a complete record of reject activity which is useful for monitoring and analysing the occurrences and levels of contamination for specific products. Select the Contaminants Log option in the Logs/Reports screen to display the Contaminants Log screen.
  • Page 221: Screen Contents

    Logs and Reports Screen Contents The screen displays a list of system faults under the following column headings:  Date – Displays the report date.  Time – Displays the report time.  Trace Code – Displays the Traceability code assigned to the batch, available if this option has been enabled in the Batch Control screen.
  • Page 222 Logs and Reports Use the scroll bar to navigate to and select Batch option. Tap on the Back button to display the Save Settings pop-up screen. Then tap on the green tick 'OK' button to save the changes and close the screen. Tap on the Batch Control icon in the System Settings screen to display the Batch Control screen.
  • Page 223: Shift Log

    Logs and Reports A trace code of up to 15 alphanumeric characters can be manually entered via Code a pop-up keyboard which is displayed when the field is selected. A code can also be entered or edited directly on the Main Run screen.
  • Page 224: Screen Contents

    It is therefore advised that you contact your local Loma Service Centre for assistance in the event any of the messages listed in the Example Messages section below are recorded.
  • Page 225: Screen Contents

    Logs and Reports The Diagnostics Log contains a list of all diagnostic messages generated. Select the Diagnostics Log option in the Logs/Reports screen to display the Diagnostics Log screen. Screen Contents The screen displays a list of system faults under the following column headings: ...
  • Page 226: Setup Report

    Logs and Reports  Unkn command no - the detector has received a command message indicating an unknown command. Not Monitored The following messages are are not monitored and therefore only generated when the Diagnostics Log screen is displayed. If the detector has already failed to function correctly, displaying the log may help in diagnosis should the initial issue be the result of one of the monitored functions.
  • Page 227: Learn Report

    Logs and Reports o Date – Displays the date that the report was generated. o Machine Identification – Displays the machine ID. o Number – Displays the product number. o Product Name – Displays the product name.  Product Settings – This section includes a list of the parameters available in the Product Settings screen and their associated values and selections.
  • Page 228: Status Report

    Logs and Reports Status Report Purpose The Status Report contains accumulated product run data for the currently running product at the time it is sent. It contains similar information to the batch Report. Sending a Status Report does not reset the batch values.
  • Page 229: Screen Contents

    Loma Service Centre if any action is not clear. Configuration Report Purpose The Configuration Report contains a complete record of the detector setup. Saving this report to a USB stick is useful for backing up the setup information and for sending to Loma to support an investigation.
  • Page 230: Screen Contents

    Logs and Reports Select the Configuration Report option in the Logs/Reports screen to display the Configuration Report screen. Screen Contents The report contains information in several sections as described below.  Configuration - This section contains the following general information: o GUI version –...
  • Page 231: Release Notes

    Release Notes contains a copy of the release notes applicable for the installed software versions. It provides details of all changes and patches included in the installed software and are intended for use by Loma service engineers. Select the Release Notes option in the...
  • Page 232: Log And Report Output Options

    Logs and Reports Log and Report Output Options When each log or report screen is displayed a number of options for outputting the report are available. A number of icons are displayed at the bottom of the screen as shown in the example Batch Log screen above, providing options for outputting the Log or Report details format by tapping on them.
  • Page 233 Logs and Reports The folder hierarchy recorded on the USB stick is as follows: For Logs: LomaIQ3/<MACHINE_ID>/Logs/LogName/<files> stored under date/time filenames. For Reports: LomaIQ3/<MACHINE_ID>/Reports/ReportName/<files> stored under date/time filenames. Further files as they are downloaded are added to the existing folder. The log can hold up to 20 records.
  • Page 234: Report Languages

    Logs and Reports This icon is displayed if the LomaEnet Capture application has been installed onto a dedicated networked server and a communication connection configured in the LomaEnet Capture screen. Some reports such as the batch and PVS reports, can be set up to be sent to the server automatically.
  • Page 235: Maintenance

    Maintenance This chapter describes the maintenance procedures for the IQ + ST Metal Detector. Your warranty may be invalidated if you do not follow the maintenance schedule set out within this user guide. This warranty statement is in addition to the terms of sale. The following sections provide more information: ...
  • Page 236: Cleaning Solutions

    Maintenance Never immerse the Pneumatic Actuator as internal corrosion and permanent damage will result. Cleaning solutions Detergents are typically alkaline solutions. Disinfectants typically contain Chlorine or Ammonia. Every 3-4 weeks it is typical to revert to acid based cleaning solution to remove any build up of lime scale on stainless steel parts.
  • Page 237: Air Regulator Unit Maintenance

    Maintenance  For systems with reject confirm and bin full check their correct operation. Bin full will operate if the sensor is blocked for > 5 seconds. Air Regulator Unit Maintenance With the exception of systems fitted with Air Blast or Stop-On-Detect or electrically driven rejects the compressed air supply pressure to the fitted reject device is fed through an air regulator unit.
  • Page 238: Adjusting The Drive Chain Tension

    GUI software version is IQ3_Plus_v1.9.2.10._zip at the time of writing this document. 1. Obtain a copy of the applicable upgrade files for your system from Loma Systems. 2. Insert a USB memory stick into your PC and copy the following files onto it: IQ3_vX.X.X.Xs.hex...
  • Page 239 8. Exit the Loma software on the metal detector using one of the following methods: Method 1: CTRL-TAB and End Task in the Main Run Screen.
  • Page 240 Maintenance THIS PAGE IS INTENTIONALLY LEFT BLANK...
  • Page 241: Glossary

    Glossary Aperture: The area through which product is passed. AutoBalance: A patented detector feature that automatically makes balance adjustments for each of the 70 available frequencies to provide optimum detector performance. Bin Full: Option which uses a PEC to indicate when a reject bin is full and needs to be emptied.
  • Page 242 Glossary Learn: The process of passing sample products through the metal detector so that it can automatically select the optimum detector settings based on the product effect. Metal Free Zone: An area external to the metal detector aperture which must be free of any fixed or moving metal as it generates a signal that will be picked up by the metal detector Noise:...
  • Page 243 Glossary USB: Universal Serial Bus used to transfer data to and from the metal detector using a USB data stick. User: A person who operates the metal detector. Different user access levels are available which are used to manage access to specific features and functionality.
  • Page 244 Glossary THIS PAGE IS INTENTIONALLY LEFT BLANK...
  • Page 245: Index

    Air Regulator Unit Maintenance 225 End of Life Treatment 23 Appearance Settings 98 End User Licence Agreement 25 Auto-Learn Settings 115 Engineer - Loma Service 139 EnviroScan 129 Balance 126 Establishing a Good Product Learn 161 Batch Control 105, 107...
  • Page 246 Index LomaEnet Capture 118 Resultant 101 LomaOPC Server 120 Retracting Band 56 Reverse Learn 196 Maintenance Warnings 223 Run Errors Log 202 Metal Detector Search Heads 52 Metal Free Zone 10 Safety Awareness 18 Mounting a Detector Head onto a Conveyor 34 Safety Guards 21 Moving the Detector Head 30 Safety Labels 20...
  • Page 247 Index User Account Details 96 Technical Specifications 27 User Accounts 91 User Interface 61 Testing Metal Detector Performance 13 The Loma Group of Companies 6 User Options 108 Threshold 81 Tracker Feature 10 VF Balance 151 Types of Metal 12...

Table of Contents

Save PDF
