On Screen Display (OSD) Control Adjustment Cont.
3.3
The OSD main menu is displayed on screen
when MENU key is pressed. The OSD menu
is a combination of graphic and text display.
The first line always shows the current
selected or active menu item. The bottom line
of main menu shows information of the input
image.
The UP and DOWN keys are used to scroll
through items within the menu. The selected
item is highlighted as the scrolling move along.
The SELECT key is used to activate the
highlighted item. During this state, the MENU
key is used to close the OSD menu from the
screen.
OSD - On Screen Display
Icon
Function
BRIGHTNESS
CONTRAST
PRESET
RED (user mode)
GREEN (user mode)
BLUE (user mode)
VERTICAL POSITION
HORIZONTAL POSITION Moves the image left and right.
INPUT
INFORMATION
1024x768
Description
Adjusts the brightness of the screen.
Adjusts the contrast of the screen.
COLOR 9300K / 6500K
• 9300K: Default to 9300K color temp
• 6500K: Default to 6500K color temp
• User Mode: Used to adjust RGB
Adjusts the gain of red channel in ADC.
Adjusts the gain of green channel in ADC.
Adjusts the gain of blue channel in ADC.
Moves the image up and down.
Selects the applicable input source, analog
input (D-SUB), or Digital input (DVI-D)
Provides the user with detailed information
regarding the current input format and
version.
10
70Hz
