2.1 ASSEMBLY

NOTE:
OWC Envoy units purchased prior to April 2014 are compatible
original Apple SSD from the MacBook Air 2010 and MacBook Air 2011. These OWC Envoy
NOT
units are compatible with the OWC Aura Pro 6G SSD. If you have an OWC Envoy
purchased earlier than April 2014, installing any OWC or other third-party SSD
damage both the SSD and the OWC Envoy.
1. Use a Torx T5 screwdriver to remove the two screws on the bottom of the OWC Envoy,
as circled in the picture below. The screw on the left is longer than the screw on the
right. Be careful not to use too much force when removing these screws, as it is
possible to strip them if you are not careful.
2. Lift off the bottom cover to reveal the green circuit board, as shown in the picture
below. The circuit board will be slightly loose in the enclosure, as it is held in place by
pegs in the bottom cover when the OWC Envoy is assembled.
OWC ENVOY

SYSTEM SETUP

These are static-sensitive devices. They are susceptible to invisible damage
if not protected during installation.
We recommend proper grounding by using a grounding strap. Make sure
to work in a clean and static-free area, and avoid wearing clothing that
retains static charges.
For more information, please visit:
http://www.macsales.com/static
3
ONLY
with the
will
SYSTEm SETUp
