OWC Envoy Pro
Insert your SSD module into the interposer board connector - it is keyed so it will only
fit one direction. The SSD module plugs straight into the connector and fits snugly.
Make absolutely certain that the SSD module is fully inserted before continuing! Use
the shorter Torx T5 screw to secure the SSD module into the enclosure.
Slide the top cover back onto the bottom, locking it in place.
Turn the OWC Envoy Pro over and use the two Torx T5 screws to secure the case
together. Apply the rubber foot to complete the assembly.
Your OWC Envoy Pro connects using the included USB cable. if your SSD module is
unformated, you will need to format it to be able to use it. Please visit this URL for
http://www.macsales.com/format
instructions on how to do this.
For technical support, pleaes visit:
http://www.macsales.com/support
R5 4/10/13 JD
Copyright ®2012-2013 Other World Computing All Rights Reserved. Other World Computing's Limited Warranty is not transferable and subject to limitations.
Assembly
OWC Envoy Pro
OWCMANENVPROGAM
Owner's Manual & Assembly Guide
for MacBook Pro Retina
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for OWC Envoy Pro
Summary of Contents for OWC Envoy Pro
- Page 1 Torx T5 screw to secure the SSD module into the enclosure. Slide the top cover back onto the bottom, locking it in place. Turn the OWC Envoy Pro over and use the two Torx T5 screws to secure the case together. Apply the rubber foot to complete the assembly.
- Page 2 MacBook Pro Retina Owner’s Manual & Assembly Guide * This Envoy Pro is thermally configured for an original factory, Apple SSD. If you wish to install an OWC Aura Pro SSD, please contact customer support. Removing the top cover will expose the interposer board inside of the OWC Envoy Pro.
