3.3

Loading Documents

This section describes how to load documents onto the scanner.

■ How to load documents

1. Align the edges of the document.
Align the edges of the document as follows:
1) Straighten the edges of the document.
2) Check the number of the sheets in the document stack.
Before loading the document onto the scanner, fan it as follows:
1) Take out the stack of documents of thickness 5 mm or less.
2) Hold both ends of the document with both hands, and bend the documents into an
3) Firmly holding the document with both hands and bend back the document as fol-
4) Repeat steps 1) to 3) a few times.
5) Turn the document staple 90 degrees, hold the other two sides of the document, and
32
Straighten both edges of the document stack for scanning it correctly.
The standard number of sheets that can be loaded on the scanner is as follows:
-A4-size paper or smaller that makes a document stack or 5mm or less (50 sheets
2
at 64g/m or at 17 lb)
Scanning accuracy increases when
the document is loaded onto the
HINT
scanner so that the leading edges
of the papers form a step-like pat-
tern as shown in the figure.
arch.
lows so that the bent section rises up in the middle of the document.
fan it again.
Step-like
Scanning direction
5mm
