H S E R I E S
Vent · Free · Gas · Fireplaces
Installation,
Owner's Manual
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
If you cannot reach your gas supplier,
call the fire department.
-- Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
H Series Vent Free Gas Fireplace
Operation
and
This is an unvented gas-fired heater. It
uses air (oxygen) from the room in which
it is installed. Provisions for adequate
combustion and ventilating air must be
provided. Refer to page 6.
This appliance may be installed in an
aftermarket, permanently located,
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
Report #284-F-07-5
1
Models:
HVF-42
HVF-60
HVF-72
February 2014
EuropeanHome.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HVF-42 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for European Home HVF-42

  • Page 1 H S E R I E S Vent · Free · Gas · Fireplaces Installation, Models: Operation HVF-42 HVF-60 HVF-72 Owner’s Manual This is an unvented gas-fired heater. It WARNING: If the information in these uses air (oxygen) from the room in which instructions is not followed exactly, a fire it is installed.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Information Room Volume for Vent Free Specifications and Dimensions Pre-installation Planning Rough Installation Electric Installation Gas Installation Trim and Finish Operating the Fireplace Maintenance Parts List Warranty Troubleshooting Appendix One H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 3: Important Safety Information

    3. Young children should be carefully supervised when they are in the same room with the heater. 4. Do not place clothing or other flammable material on or near the heater. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 4 (scents) may be reburned in the vent free heater which can produce odors. It is recommended to minimize the use of candles, incense, etc. while the vent free heater is in operation. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 5 25. When this heater is installed directly on carpeting, tile or other combustible material, other than wood flooring, the heater shall be installed on a metal or wood panel extending the full width and depth of the heater. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 6: Room Volume For Vent Free

    This heater shall not be installed in a room or space unless the required volume of indoor combustion air is provided by the method described in the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the International Fuel Gas Code, or applicable local codes. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 7 If an outside air supply is desired it should be added to the room in which the H Series Vent Free Gas Fireplace is installed, not to the chase enclosing the fireplace. If outside air is introduced into the chase, competing air pressures could compromise the operation of the fireplace. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 8: Specifications And Dimensions

    SPECIFICATIONS and DIMENSIONS 2” 151/2” 261/8” 18” Hearth Panel (lifts off for service, all models) 5” 5” Figure 1. HVF-42, HVF-60, HVF-72 Fireplaces 18” Dimension HVF-42 HVF-60 HVF-72 47” 65” 77” 42” 60” 72” 38” 49” 59” Table 1. Dimensions by Model...
  • Page 9 Examiners of Plumbers and Gas Fitters has issued approval number G1-0513-436 for these appliances. CAUTION H Series VENT FREE GAS FIREPLACE Hot while in operation. Do not touch. Model: HVF-42 HVF-60 HVF-72 Severe burns may result. Keep children, clothing, furniture, gasoline and other liquids having flammable vapors away.
  • Page 10: Pre-Installation Planning

    2,000 feet. Consult with your local gas supplier to determine the proper orifice size. ELECTRICAL CODE The H Series Gas Fireplace, when installed, must be electrically grounded in accordance with local codes, or, in the absence of local codes, with the National Electrical Code ANSI/NFPA 70. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 11 • Plumb line and level gas detector • Tape measure and framing square • Appropriate electrical supply wiring parts • Electric drill and assortment of drill bits • Appropriate gas supply line parts H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 12 36" 36" (depends on model) and maintenance. 90cm 90cm Do not put furniture or other objects in this space in front of the fireplace. Figure 4. Clearances to Objects H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 13 Figure 5. Mantel, Ceiling and Enclosure Clearances (right side view, not to scale) Combustible Room Ceiling Enclosing Ceiling 12” Top Line of Fireplace NON-COMBUSTIBLE Opening 11” Wall Face 4” 36” 263/4” Fireplace Opening 231/8” H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 14 When the fireplace is to be installed directly on carpeting, vinyl tile or combustible material other than wood flooring, it must be installed on a metal or wood panel extending the full width and depth of the fireplace cabinet. HVF-42 MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS HVF-60...
  • Page 15: Rough Installation

    181/2” Table 4. Rough Opening Dimensions by Model Figure 6. Rough Opening for HVF-42, HVF-60, HVF-72 INSTALLING THE FIREPLACE The H Series fireplaces must be placed on a sturdy and level surface. It can be placed on the floor or a raised platform made ONLY of wood or non-combustible materials - do not place the fireplace on carpet or vinyl tile.
  • Page 16: Electric Installation

    Remove the battery case cover and insert four AA batteries as shown in Figure 7. Figure 7. Battery Case with Batteries (shown with cover removed) H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 17 ELECTRIC INSTALLATION Pilot Burner Gas Valve IFC Control Module Power Plug Figure 8. Connection Diagram H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 18: Gas Installation

    Commonwealth of Massachusetts. INSTALL THE GAS SUPPLY For the HVF-42, HVF-60 and HVF-72 models, a 45/8” x 7” opening in the lower left side is provided for the gas supply. The gas supply piping should have a separate gas shutoff valve and a capped, 1/8” pipe tapping upstream of the valve for the purpose of reading pressure.
  • Page 19: Trim And Finish

    4” 4” Table 5. NON-Combustible Facing Dimensions All of the following limits MUST be maintained for installations of the HVF-42, HVF-60 and HVF-72: • The bottom of the cabinet may be no closer to the room ceiling than 36”. •...
  • Page 20 Although the fibers have a long life, they will eventually deteriorate. If this becomes apparent, replacement Embaglow can be purchased from your local fireplace retailer or European Home. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 21: Operating The Fireplace

    Since it is a metal fireplace, the heat-up and cool-down cycles may produce some noises caused by the expansion and contraction of these metals. The premium materials and build quality of your H Series Vent Free Gas Fireplace will keep these sounds to a minimum. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 22 5. Use the ARROW KEY to adjust the flame height up and down. TO TURN OFF THE HEATER 1. With the fireplace on, press the ON/OFF button. A single beep from the fireplace will confirm the button press and the fireplace will turn off. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 23: Maintenance

    Figure 11. Burner Close-up Primary Air Openings Burner Inlet Tubes Failure to keep the primary air opening of the burner clean may result in sooting and property damage. H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 24: Parts List

    E4-STC4 1/2” Black Glass Fire Media FM-CG-BLK Fire Pebbles Fire Media FM-PG-DB Embaglow Fire Media EMBAGLOW-1G Black Embers Fire Media EMBERS For replacement parts and customer service, contact: EUROPEAN HOME +1 (781) 324-8383 H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 25: Warranty

    WARRANTY H Series Vent Free Gas Fireplace EuropeanHome.com...
  • Page 26 APPENDIX ONE Remote/Receiver Not Synchronized Remote Not Learning to Receiver Begin Confirm 120V AC connections Verify proper 120VAC power supply A. Remove the batteries from battery back up. B. Attempt to light continuous pilot from switch. If pilot lights or if spark is present we know power is supplied and we can proceed.
  • Page 27: Troubleshooting

    APPENDIX ONE Troubleshooting 1. Verify proper power supply throughout system Begin - See page 154for multimeter images 2. Make sure power switch is in the ON position 3. Verify wires are properly connected to IFC module 4. Make sure system is properly grounded Is the Does the 5.
  • Page 28 APPENDIX ONE Troubleshooting 1. Verify transmitter is not powered on or in thermostat mode calling for heat. Display should say OFF next to thermometer image on display for thermo off. 2. Verify receiver switch is not in ON position 3. Ensure all electrical connections are secure based on the wiring Burner diagram lights when...
  • Page 29 APPENDIX ONE Troubleshooting 1. Thermostat in SMART mode will not modulate flame height 2. Check in/out pressure readings according to owner’s manual 3. Check electrical connections and inspect wiring for damage 4. Inspect main burner orifice for blockage and correct size 5.
  • Page 30 EUROPEAN HOME a division of Europa Ja, Inc. 376 Washington St. Suite 203 Malden, MA 02148 tel: 781/324-8383 fax: 781/324-8384 www.europeanhome.com IGHVF10-140205u H Series Vent Free Gas Fireplace EuropeanHome.com...
