H S E R I E S
Vent · Free · Gas · Fireplaces
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
If you cannot reach your gas supplier,
call the fire department.
-- Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
This is an unvented gas-fired heater. It
uses air (oxygen) from the room in which
it is installed. Provisions for adequate
combustion and ventilating air must be
provided. Refer to page 6.
This appliance may be installed in an
aftermarket, permanently located,
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
Report #0284GF007S
Installation,
Operation,
&
Owner's Manual
HVF-42-ST
HVF-60-ST
HVF-72-ST
December 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for European Home H Series

  • Page 1 Installation, Operation, & Owner’s Manual H S E R I E S HVF-42-ST HVF-60-ST Vent · Free · Gas · Fireplaces HVF-72-ST This is an unvented gas-fired heater. It WARNING: If the information in these uses air (oxygen) from the room in which instructions is not followed exactly, a fire it is installed.
  • Page 3: Table Of Contents

    Maintenance Parts List Warranty Troubleshooting Appendix One Connecting a Home Automation System Appendix Two Installing The Air Shutter Kit Appendix Three Optional Fireplace Screen Appendix Four Installing the Heat Deflector Appendix Five H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 4: Important Safety Information

    3. Young children should be carefully supervised when they are in the same room with the heater. 4. Do not place clothing or other flammable material on or near the heater. H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 5 (scents) may be reburned in the vent free heater which can produce odors. It is recommended to minimize the use of candles, incense, etc. while the vent free heater is in operation. H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 6 26. When this heater is installed directly on carpeting, tile or other combustible material, other than wood flooring, the heater shall be installed on a metal or wood panel extending the full width and depth of the heater. H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 7: Room Volume For Vent Free

    This heater shall not be installed in a room or space unless the required volume of indoor combustion air is provided by the method described in the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the International Fuel Gas Code, or applicable local codes. H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 8 ____37,500________ If the answer to a) is greater than b) then your space will support the installation of the H Series Vent Free Gas Fireplace; if a) is less than b) then your space will not support an H Series Vent Free Gas Fireplace.
  • Page 9: Specifications And Dimensions

    This information is for reference only. Please consult the Installation Manual for all details prior to making any design decisions. Conversions from millimeters are rounded to the nearest fraction. A DWG file is available at www.europeanhome.com H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 10 SPECIFICATIONS and DIMENSIONS CERTIFICATION OMNI-Test Laboratories, Inc. has certified that the H Series Vent Free Gas Fireplace meets the ANSI Z21.11.2- 2016 standard “Gas-fired Room Heaters, Volume II, Unvented Room Heaters”. These appliances are approved for installation in the Commonwealth of Massachusetts. The Board of State Examiners of Plumbers and Gas Fitters has issued approval number G1-1115-175 for these appliances.
  • Page 11: Pre-Installation Planning

    2,000 feet. Consult with your local gas supplier to determine the proper orifice size. ELECTRICAL CODE The H Series Vent Free Gas Fireplace, when installed, must be electrically grounded in accordance with local codes, or, in the absence of local codes, with the National Electrical Code ANSI/NFPA 70.
  • Page 12 PRE-INSTALLATION PLANNING BEFORE YOU BEGIN Thank you for purchasing an H Series Vent Free Gas Fireplace. This fireplace has been designed to provide you with safe, trouble-free operation. Please read this manual thoroughly before beginning the installation of your fireplace. It has information which is important for safe installation and operation.
  • Page 13 Possible Fireplace Locations LOCATING THE FIREPLACE Several issues must be addressed when selecting a suitable location for the H Series Vent Free Gas Fireplace. Observing the required clearances to combustible materials, the accessibility of the gas supply as well as the room into which it will be installed must all be considered.
  • Page 14 Top Line of Fireplace NON-COMBUSTIBLE Opening 11” 11” (minimum) Wall Face (minimum) 4” 4” 36” 36” Fireplace Fireplace Opening 263/4” Opening 231/8” 231/8” Mantel, Ceiling and Enclosure Clearances (side view, not to scale) H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 15 NON-COMBUSTIBLE MATERIALS section. MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS When installing the H Series Vent Free Gas Fireplace, the clearances shown in the table below must be observed. If the required clearances are not maintained a fire may result thereby causing property damage, personal injury or loss of life.
  • Page 16: Rough Installation

    INSTALLING THE FIREPLACE The H Series Vent Free Gas Fireplace must be placed on a sturdy and level surface. It can be placed on the floor or a raised platform made ONLY of wood or non-combustible materials - do not place the fireplace on carpet or vinyl tile.
  • Page 17: Electric Installation

    Verify proper operation after servicing. ELECTRICAL ASSEMBLY The H Series Vent Free Gas Fireplace requires the internal receptacle (supplied) to be wired to a 120V AC branch circuit according to all applicable codes. The neutral, line and ground wires to the receptacle are available at the lower left corner of the fireplace cabinet.
  • Page 18 ELECTRIC INSTALLATION Pilot Burner with ODS Gas Valve Back-up Battery Case Control Module Power Plug Electrical Connection Diagram H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 19: Gas Installation

    The installation of this fireplace must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1. The H Series Vent Free Gas Fireplace is shipped from the factory for use with natural gas ONLY. Conversion to another fuel is NOT permitted.
  • Page 20: Trim And Finish

    The minimum interior height of an enclosing chase is 263/4”. • The combustible facing limits for the H Series Vent Free Gas Fireplaces are listed in the table above. Combustible wall facing is NOT permitted inside this limit. Dimension “B” is measured up from the top of the fireplace opening and the “A”...
  • Page 21 INSTALLING THE FIRE MEDIA Two types of fire media are available for your H Series Vent Free Gas Fireplace; Fireglass or Carrara Pebbles. The Fire Media The entire contents of the bag of fire media should be spread to an even depth across the entire burner top.
  • Page 22: Operating The Fireplace

    THE FIRST FIRE The first time you light your H Series Vent Free Gas Fireplace an odor may be given off by the unit. This is normal and is a result of the ‘burn off’ of the lubricants and sealants used when manufacturing the fireplace.
  • Page 23 1. With the fireplace on, press the THERMOSTAT button. The display will read ON next to the thermostat icon. 2. Use the ARROW keys to adjust the LCD to the desired temperature. H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 24: Maintenance

    MAINTENANCE A qualified service agency should conduct an annual inspection and maintenance of your H Series Vent Free Gas Fireplace to keep it running safely. The following procedures should be performed only by a qualified service person. The gas supply should be turned off whenever a maintenance procedure is performed. All parts of the fireplace that are removed for servicing must be replaced prior to operation.
  • Page 25 Carrara Pebbles Fire Media HVF-FM-WHTP 1/2” Black Glass Fire Media FM-CG-BLACK HVF-42 Fireplace Screen HVF-42-SA-SDS-IM-01 HVF-60 Fireplace Screen HVF-60-SA-SDS-IM-01 HVF-72 Fireplace Screen HVF-72-SA-SDS-IM-01 For replacement parts and customer service: Contact your local Dealer H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 26: Warranty

    European Home warrants the H Series Vent Free Gas Fireplace burners against defects in materials and workmanship for a period of TWO (2) YEARS from the date of original retail purchase. We warrant the H Series Vent Free cabinet against defects in materials and workmanship for a period of FIVE (5) YEARS from the date of original retail purchase.
  • Page 27 Did you hear the beep? Proceed to next troubleshooting Remote is learned to the receiver and should operate the fireplace. tree to verify there is not another problem H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 28: Troubleshooting

    Fireplaces are only sold as Natural Gas. sensor? 2. Verify the knockouts on the sides or back of the unit have been sealed after installation with insulation or aluminum tape to prevent air leakage into the unit. H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 29 5. Verify gas pressure on full capacity is according to manual 6. Check for voltage at the main burner connection (EV2 green) - If voltage is present when drops out, replace gas valve - If no voltage, replace IFC board H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 30 6. Check continuity of step motor. Resistance between yellow/ modulates orange and black/brown wires should be 25 ohms. -If no continuity or step motor is not regulating out pressure, replace step motor. System functioning properly H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 31 WIRING to a HOME AUTOMATION SWITCH (OPTIONAL) External control of your H Series Vent Free Gas Fireplace can be done with a home automation switch (not included) or the remote control (included). The home automation system cannot adjust the flame height; it can turn the fireplace on or off (no flame adjustment).
  • Page 32: Installing The Air Shutter Kit

    Some building code jurisdictions require that outside or “make-up” air be provided when installing a fireplace of this type. An Air Shutter Kit (HVF-SA-ASK-01) is available for the H Series Vent Free Gas Fireplace, the installation of which may be required by your local building code. Confirm the installation requirements with your local inspector prior to ordering and installing the Air Shutter Kit.
  • Page 33: Appendix Four

    3) The bottom of the screen will sit on the fireplace base and rest up against the tabs and the magnets. Push the top of the screen into place so that the top of the metal screen frame attaches to the ceiling mag- nets. H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 34: Appendix Five

    Screw the deflector up to the underside using the (4) included screws, starting at either end first to align the deflector then the middle screws. In the end the unit should look like the below image. H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
  • Page 36 EUROPEAN HOME a division of Europa Ja, Inc. 30 Log Bridge Road Building 300 - Suite 303 Middleton, MA 01949 www.europeanhome.com IGHVFT11-180815 H Series Vent Free Fireplace Rev #12042020 EuropeanHome.com...
