H S E R I E S

Vent · Free · Gas · Fireplaces

WARNING: If the information in these

instructions is not followed exactly, a fire

or explosion may result causing property

damage, personal injury or loss of life.

-- Do not store or use gasoline or other

flammable vapors and liquids in the vicinity of

this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

•

Do not try to light any appliance.

•

Do not touch any electrical switch; do

not use any phone in your building.

•

Immediately call your gas supplier from

a neighbor's phone. Follow the gas sup-

plier's instructions.

•

If you cannot reach your gas supplier,

call the fire department.

-- Installation and service must be performed

by a qualified installer, service agency or the

gas supplier.

H Series Vent Free Gas Fireplace

This is an unvented gas-fired heater. It

uses air (oxygen) from the room in which

it is installed. Provisions for adequate

combustion and ventilating air must be

provided. Refer to page 6.

This appliance may be installed in an

aftermarket, permanently located,

manufactured (mobile) home, where not

prohibited by local codes.

This appliance is only for use with the type

of gas indicated on the rating plate. This

appliance is not convertible for use with

other gases.

INSTALLER: Leave this manual with the

appliance.

CONSUMER: Retain this manual for future

reference.

Report #0284GF007S

Installation,

Operation,

Owner's Manual

HVF-42-P

HVF-60-P

HVF-72-P

EuropeanHome.com

Oct. 2018

Table of Contents

Need help?

Do you have a question about the HVF-60-P and is the answer not in the manual?

Questions and answers

Summary of Contents for European Home HVF-60-P

Page 1 Operation, & Owner’s Manual H S E R I E S HVF-42-P HVF-60-P Vent · Free · Gas · Fireplaces HVF-72-P This is an unvented gas-fired heater. It WARNING: If the information in these uses air (oxygen) from the room in which instructions is not followed exactly, a fire it is installed.
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information ..............3 Room Volume for Vent Free Fireplaces ............ 6 Specifications and Dimensions ..............8 Pre-installation Planning ................11 Rough Installation ..................15 Electric Installation ..................18 Gas Installation ....................19 Trim and Finish ....................20 Installing the Optional Screens ............25 Installing the Optional Panel ..............26 Operating the Fireplace ................26 Maintenance ....................28...
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION IMPORTANT SAFETY INFORMATION Read these instructions carefully before installing or trying to operate this Vent Free gas heater. Read these instructions carefully before installing or trying to operate this Vent Free gas heater. IMPORTANT SAFETY INFORMATION PRODUCT INSTALLATION RECORD Installer: Please complete this form.
Page 4 IMPORTANT SAFETY INFORMATION Read these instructions carefully before installing or trying to operate this Vent Free gas heater. 5. Any safety screen or guard removed for servicing an appliance, must be replaced prior to operating the heater. 6. Installation and repair should be done by a qualified service person. The heater should be inspected before use and at least annually by a professional service person.
Page 5 IMPORTANT SAFETY INFORMATION Read these instructions carefully before installing or trying to operate this Vent Free gas heater. 17. Unvented gas heaters emit moisture into the living area. In most homes of average construction, this does not pose a problem. In houses of extremely tight construction, additional mechanical ventilation is recommended.
Page 6: Room Volume For Vent Free Fireplaces
ROOM VOLUME for VENT FREE ROOM VOLUME for VENT FREE ROOM VOLUME FOR VENT FREE FIREPLACES CODES Adhere to all local codes or, in their absence, the latest edition of THE NATIONAL FUEL GAS CODE ANSI Z223.1 or NFPA54 which can be obtained from…...
Page 7 Maximum BTU/hr. my space will support (use formula above) a) __________________ BTU/hr. of European Home H Series Vent Free Gas Fireplace b) ____37,500________ If the answer to a) is greater than b) then your space will support the installation of the H Series Vent Free Gas Fireplace; if a) is less than b) then your space will not support an H Series Vent Free Gas Fireplace.
Page 8: Specifications And Dimensions
SPECIFICATIONS and DIMENSIONS Nailing Flanges 2” 2” 2” 281/8” 5” 18” HVF-42-P Fireplace 18” 5” Dimension HVF-42-P HVF-60-P HVF-72-P 47” 65” 77” 441/2” 623/4” 741/2” 38” 49” 59” 3” 91/4” 101/4” Flame Width 37.5” 37.5” 37.5” H Series Burner Dimensions by Model...
Page 9 SPECIFICATIONS and DIMENSIONS Nailing Flanges 5” 18” 2” 281/8” 18” 5” HVF-60-P Fireplace 18” Nailing Flanges 2” 5” 2” 5” 281/8” 18” HVF-72-P Fireplace 18” H Series Vent Free Gas Fireplace EuropeanHome.com...
Page 10 Apply loose material per instruction manual. DO NOT apply extra material or material Removal of this marking will void compliance of this heater with ANSI Z21.11.2. not supplied with the heater. Replace only with European Home Fire Media approved manufactured by: for H Series VENT FREE Fireplaces.
Page 11: Pre-Installation Planning
PRE-INSTALLATION PLANNING WHEN ENCLOSING YOUR FIREPLACE THE USE OF NON-COMBUSTIBLE BUILDING MATERIALS IS REQUIRED. PLEASE READ AND UNDERSTAND THE FOLLOWING. COMBUSTIBLE MATERIALS Materials that can catch fire and burn are considered combustible. Any material that is made of, or faced with, wood, wood pulp, paper, plastic or any other material that can catch fire and burn is considered combustible.
Page 12 PRE-INSTALLATION PLANNING BEFORE YOU BEGIN Thank you for purchasing an H Series Vent Free Gas Fireplace. Please read this manual thoroughly before beginning the installation of your fireplace. It has information which is important for safe installation and operation. Please inspect your shipment for completeness and any damage. Contact your retailer if any damage is found. Do not install your fireplace with any damaged or substituted parts.
Page 13 PRE-INSTALLATION PLANNING 36” min. 36” min. 36” min. 36” min. 6” min. 36” min. 36” min. Possible Fireplace Locations (drawing not to scale) LOCATING THE FIREPLACE Several issues must be addressed when selecting a suitable location for the H Series Vent Free Gas Fireplace. Observing the required clearances to combustible materials, the accessibility of the gas supply as well as the room into which it will be installed must all be considered.
Page 14 Must maintain adequate clearances for servicing and proper operation. HVF-42-P MINIMUM CLEARANCES TO COMBUSTIBLE MATERIALS HVF-60-P HVF-72-P Clearance to Top Cabinet Standoffs 0”...
Page 15: Rough Installation
ROUGH INSTALLATION ROUGH OPENING Dimension HVF-42-P HVF-60-P HVF-72-P A (Width) 481/2” 663/4” 781/2” B (Height) 281/8” 281/8” 281/8” C (Depth) 18” 18” 18” Rough Opening Dimensions by Model ROUGH INSTALLATION The H Series fireplaces must be installed on a sturdy and level surface. It may be placed on the floor or a raised platform made ONLY of wood or non-combustible materials - do not place the fireplace on carpet or vinyl.
Page 16 ROUGH INSTALLATION DO NOT ALLOW THE FIREPLACE TO BEAR ANY WEIGHT The entire weight of the walls must be borne by a structure other than the fireplace. Dimensions A, B, and C must be equal throughout the installation at 18 inches each. H Series Vent Free Gas Fireplace EuropeanHome.com...
Page 17: Electric Installation
ELECTRIC INSTALLATION Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. This appliance must be electrically grounded in accordance with local codes, or, in the absence of local codes, with either the National Electrical Code ANSI/NFPA 70. Electrical work should only be performed by a qualified, licensed electrician.
Page 18 ELECTRIC INSTALLATION Pilot Burner with ODS Gas Valve Back-up Battery Case Control Module Power Plug Electrical Connection Diagram Electric Installation Building codes do not permit the installation of a gas fireplace in a plenum (a chase designed for air flow) but your enclosure may have local air movement within it.
Page 19: Gas Installation
Commonwealth of Massachusetts. INSTALL THE GAS SUPPLY On the closed end of the HVF-42-P, HVF-60-P, HVF-72-P fireplaces are two knockouts; a 3” x 3” knockout for the gas supply and a larger, 51/8” x 31/2”, knockout for the air shutter, if required.
Page 20: Trim And Finish
Dimension The wall above any open side of the fireplace WITHOUT a mantel MUST have 36” HVF-42-P 45” 4” 18” NON-COMBUSTIBLE facing to the limits HVF-60-P 63” 4” 18” (minimum) shown at left. HVF-72-P 75” 4” 18” Combustible Enclosing Ceiling* * With this type of enclosure, it may be easier to wrap the entire upper portion with non-combustible material.
Page 21 The wall above any open side of the fireplace with a COMBUSTIBLE mantel 36” MUST have NON-COMBUSTIBLE facing to HVF-42-P 45” 4” 18” the limits shown at left and mantel limits HVF-60-P 63” 4” 18” (minimum) as shown below. HVF-72-P 75” 4” 18” COMBUSTIBLE Combustible...
Page 22 COMBUSTIBLE mantel 36” MUST have NON-COMBUSTIBLE facing to HVF-42-P 45” 11” 18” (minimum) the limits shown at left and mantel limits HVF-60-P 63” 11” 18” as shown below. HVF-72-P 75” 11” 18” Combustible Enclosing 11” Minimum Ceiling...
Page 23 The fire media must be installed per these instructions. This heater must use only the fire media provided by European Home. An excess amount of fire media may adversely affect the performance of the heater. WARNING: All previously applied loose material must be removed prior to reapplication.
Page 24: Installing The Optional Screens
TRIM and FINISH INSTALLING THE OPTIONAL SCREENS Your H Series Vent Free Gas Fireplace is compatible with optional safety screens. This includes three screens, magnets and metal tabs. 1. Approximately 12 inches from the left side of the front long opening, insert a metal tab between the hearth panel and fireplace frame leaving half of the tab exposed.
Page 25: Installing The Optional Panel
TRIM and FINISH INSTALLING THE OPTIONAL PANEL Parts included: • Panel • Self-tapping screw • Clip (to secure panel) 1. Make sure that the hearth tray is pushed back tight against the rear wall. The panel will sit on top of the hearth tray and will press flat against the wall.
Page 26: Operating The Fireplace
OPERATING the FIREPLACE OPERATING THE FIREPLACE BEFORE THE FIRST FIRE 1. Make sure all construction materials have been removed from inside and around the fireplace. 2. Confirm that the electrical wiring is properly connected. 3. Check the gas supply for correct pressure and any leaks. 4.
Page 27 OPERATING the FIREPLACE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater is equipped with an ignition device which automatically lights the pilot. Do NOT try to light the pilot by hand.
Page 28: Maintenance
MAINTENANCE MAINTENANCE OF YOUR FIREPLACE SYSTEM A qualified service agency should conduct an annual inspection and maintenance of your H Series Vent Free Gas Fireplace to keep it running safely. The following procedures should be performed only by a qualified service person.
Page 29 MAINTENANCE Normal Flame Pattern Make a periodic visual inspection of the pilot and main burner flames. The main burner flames should look similar to those above (single-sided version with concrete panels.) The pilot burner flame should look like the image to the left. Normal Pilot Flame Pattern H Series Vent Free Gas Fireplace EuropeanHome.com...
Page 30 SIT Proflame Remote Control HVF-GS-TX-01 Control Module Repl-HVF-GS-CM-01 Carrara Pebbles Fire Media 1 set HVF-FM-WHTP 1/2” Black Glass Fire Media 1 set FM-CG-BLACK For replacement parts and customer service, contact: EUROPEAN HOME +1 (781) 324-8383 H Series Vent Free Gas Fireplace EuropeanHome.com...
Page 31: Warranty
H Series Vent Free Gas Fireplace European Home warrants the H Series Vent Free Gas Fireplace burners against defects in materials and workmanship for a period of TWO (2) YEARS from the date of original retail purchase. We warrant the H Series Vent Free cabinet against defects in materials and workmanship for a period of FIVE (5) YEARS from the date of original retail purchase.
Page 32: Troubleshooting
APPENDIX ONE TROUBLESHOOTING - Remote/Receiver Not Synchronized BEGIN Press the red SW1 button on the control module. You should Ensure electrical power is ON. Attempt learn hear 3 fast beeps indicating the receiver box is ready to learn sequence again. If no sound/LED, replace control the remote code.
Page 33 APPENDIX ONE TROUBLESHOOTING - Fireplace Doesn’t Work BEGIN 1. Verify proper power supply throughout system. (System is powered by 120V AC) Is the 2. Make sure power is ON Does the piezo 3. Verify wires are properly connected to control module pilot light? sparking? 4.
Page 34 APPENDIX ONE TROUBLESHOOTING - Fireplace Doesn’t Work (cont.) 1. Verify transmitter is not powered on or in thermostat mode calling for heat. Display should say OFF next to thermometer Burner image on display for thermometer o . lights when 2. Ensure all electrical connections are secure based on the wiring only pilot diagram.
Page 35 APPENDIX ONE TROUBLESHOOTING - Fireplace Doesn’t Work (cont.) 1. Thermostat in home automation mode will not modulate ame height. 2. Check in/out pressure readings according to owner’s manual. Burner 3. Check electrical connections and inspect wiring for damage. 4. Inspect main burner ori ce for blockage and correct size. modulates 5.
Page 36: Connecting A Home Automation System
APPENDIX TWO CONNECTING TO A HOME AUTOMATION SYSTEM Pilot Burner Gas Valve Back-up Battery Case Connects Here (see text) Control Module Power Plug WIRING to a HOME AUTOMATION SWITCH (OPTIONAL) External control of your H Series Vent Free Gas Fireplace can be done with a home automation switch (not included) or the remote control (included).
Page 37: Installing The Air Shutter Kit
APPENDIX THREE INSTALLING THE AIR SHUTTER KIT Some building code jurisdictions require that outside or “make-up” air be provided when installing a fireplace of this type. An Air Shutter Kit (HVF-SA-ASK-01) is included with the H Series Vent Free Gas Fireplace, the installation of which may be required by your local building code.
Page 38 EUROPEAN HOME a division of Europa Ja, Inc. 30 Log Bridge Road Building 300 - Suite 303 Middleton, MA 01949 www.europeanhome.com IGHVFPEN-181003 H Series Vent Free Gas Fireplace EuropeanHome.com...
