- Page 1 S c a f f o l d S c a f f o l d Designer Surround Installation Guide Exclusively designed to fit these European Home H Series Fireplaces: HVF-42 HVF-60 HVF-72 HVF-42 ST HVF-60 ST HVF-72 ST May 2019 Designer Surround for H Series EuropeanHome.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Information Specifications and Dimensions Pre-Installation Planning Installation Maintenance Warranty Designer Surround for H Series EuropeanHome.com... -
Page 3: Important Information
IMPORTANT INFORMATION PRODUCT INSTALLATION RECORD Installer: Please complete this form. Customer: Please retain this information. Purchased From Date of Purchase Installed By Date of Installation Surround Serial Number Thank you for your purchase of a Designer Surround for H Series! Your Designer Surround for H Series is designed to install, and perform similar to ceramic tile and should be installed by a professional. - Page 4 SCAFFOLD SURROUND PANELS 18” 12” 18” 24” 6” 48” 6” 72” 6” 84” Scaffold Metal Panels 48” Metal 72” Metal 84” Metal 18” Tile 24” Tile 42” Scaffold 60” Scaffold 72” Scaffold Each surround contains Metal and Tile Panels according to the chart, above. All surround panels are 7/16”...
-
Page 5: Specifications And Dimensions
SPECIFICATIONS and DIMENSIONS SPECIFICATIONS and DIMENSIONS 78” Metal (72”) Tile 42” H Series Fireplace Tile 30” Metal (72”) Scaffold 42 100” Metal (84”) 30” 60” H Series Fireplace Tile Tile Metal (84”) Scaffold 60 110” Metal (48”) Metal (48”) 72” H Series Fireplace Tile Tile 30”... -
Page 6: Pre-Installation Planning
PRE-INSTALLATION PLANNING BEFORE YOU BEGIN These surrounds are intended to be installed in the same manor you would use a french cleat system. (See image below) Please read these instructions thoroughly before proceeding. There is information which is important for safe and eff ective installation. -
Page 7: Installation
INSTALLATION LAYING OUT THE PANELS The panels of the Designer Surround for H Series are made to fit against the fireplace opening and each other. First, hold a metal panel up to the lower edge of the fireplace and mark the wall with a light pencil line along the lower edge of the metal panel(s). - Page 8 INSTALLATION: WALL LAYOUT INSTALLATION The metal panels and tile panels should be applied to the wall in the order shown below. 4 (Metal) 2 (Tile) 3 (Tile) 42” H Series Fireplace 1 (Metal) Scaffold 42 4 (Metal) 60” H Series Fireplace 2 (Tile) 3 (Tile) 1 (Metal)
- Page 9 INSTALLATION: WALL LAYOUT + Z-CLIPS NOTE ABOUT Z-CLIPS Z-clips installed on the wall should have the interlocking side facing up. The slotted side of the clips face the wall. The length of the clips is to account for contact with the existing wall stud behind the wall sheet- ing.
- Page 10 INSTALLATION INSTALLATION: WALL LAYOUT Using the starting point and the edges of the fireplace, mark lines on the wall using the measurements appropriate to your model, below. Red lines Represent guidelines for Z-clip; draw these in as guides for mounting. 2 5/16”...
- Page 11 INSTALLATION The areas in gray, below, show where the Z-clips is to be applied to the wall. 2 5/16” 6” 2 5/16” 24” 12” 2 3/16” 6” Align Z-Clips to Red Lines (42”- not to scale) 2 5/16” 6” 2 5/16” 24”...
-
Page 12: Maintenance
MAINTENANCE SURROUND MAINTENANCE Weekly Cleaning Both the metal and tile panels should be wiped with a lint free cloth to remove any dust then wiped with a damp cloth. Designer Surround for H Series EuropeanHome.com... -
Page 13: Warranty
YEAR from the date of original retail purchase. If a defect exists, European Home will, at its option, either (1) provide needed components using new or refurbished replacement parts or (2) exchange the product with one which is new or which has been manu- factured from new or serviceable used parts and is at least functionally equivalent to the original product. - Page 14 EUROPEAN HOME a division of Europa Ja, Inc. 30 Log Bridge Road Building 300 - Suite 303 Middleton, MA 01949 www.europeanhome.com IGHVFSS 1.0 Designer Surround for H Series EuropeanHome.com...
