Installation, Operation and Owner's Manual
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
VISION GAS FIREPLACE
Report #284-F-01-5
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance. Installation
and service must be performed by a qualified
installer, service agency or the gas supplier.
Ce manual est disponsible en Français sur de-
mande.
1
July 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISION GAS FIREPLACE and is the answer not in the manual?

Questions and answers

Related Manuals for European Home VISION GAS FIREPLACE

Summary of Contents for European Home VISION GAS FIREPLACE

  • Page 1 VISION GAS FIREPLACE Installation, Operation and Owner’s Manual WARNING: If the information in these WHAT TO DO IF YOU SMELL GAS instructions is not followed exactly, a fire • Do not try to light any appliance. or explosion may result causing property •...

  • Page 2: Table Of Contents

    Combustion Air Supply Framing Installing the Fireplace Gas Supply Venting Facing Installing the Burner Module Panel Installation Stone Configuration Surrounds Lighting Instructions Maintenance VBM Troubleshooting 24VBM Troubleshooting Parts List Warranty Third-Party Connections Appendix A Power Venting the Vision Gas Fireplace Appendix B...

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION 1. The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 or the Canadian Installation Code, CAN/CGA B149.1. 2. The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½...
  • Page 4 AVERTISSEMENT: Assurez-vous de bien suivre les instructions données dans cette notice pour réduire au minimum le risque d’incindie ou d’explosion ou pour éviter tout dommage matériel, toute blessure ou la mort. Ne pas entreposer ni utilizer d’essence ni d’autres vapeurs ou liquides inflammables dans le voisi- nage de cet appareil ou de tout autre appareil.
  • Page 5 Installations in the Commonwealth of Massachusetts must observe the following: 5.08: Modifications to NFPA-54, Chapter 10 Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...
  • Page 6 2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or structure used in whole or in part for residential purposes. (c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the instructions provided by the manufacturer for installation of the equipment and the venting system shall include:...

  • Page 7: Before You Begin

    You have ordered your Vision Gas Fireplace with one of two available burners; a VBM or a 24VBM. The VBM burner has an adjustable flame height and the 24VBM burner has a fixed flame height.

  • Page 8: Specifications And Dimensions

    SPECIFICATIONS and DIMENSIONS Natural Gas Propane (LP) Manifold Pressure: 4.0” (1.0 kPa) 10.0” ( 2.5 kPa) Maximum Supply Pressure: 7.0” (1.7 kPa) 13.0” (3.2 kPa) Minimum Supply Pressure: 4.0” (1.0 kPa) 11.0” (2.7 kPa) Orifice Size: 6 Port #55 DMS #48 DMS Canadian Efficiency P.4: Input:...
  • Page 9 These burner modules are certified by OMNI-Test Laboratories to “ANSI Z21.50b-2005, CSA 2.22b-2005 and CGA 2.17-M91 Vented Gas Fireplaces” when installed in the Vision Gas Fireplace (Report #284-F-01-5) and “ANSI Z21.60b-2004, CSA 2.28b-2004 and CGA 2.17-M91 Decorative Gas Appliances for Installation in Solid Fuel Burning Fireplaces” when installed in the Gas Stones with Fusion Basket (Report #284-L-02c-5).
  • Page 10 Vision Gas Fireplace Listing Label for 24VBM Burner...

  • Page 11: Electrical Requirements

    ELECTRICAL REQUIREMENTS VBM Burner The Vision Gas Fireplace with a VBM burner uses a receiver and remote control for its burner opera- tion. The remote control comes with a 9V battery and the receiver is powered by a 120V AC wall adapter.

  • Page 12: Installation Clearances

    INSTALLATION CLEARANCES Several issues must be addressed when selecting a suitable location for the Vision Gas Fireplace. Observing the required clearances to combustible materials, the accessibility of the gas supply and the routing of the gas vent must all be considered.
  • Page 13 10.0” wall facing 8.0” Top of Vision Gas Fireplace opening Vision Gas Fireplace opening Figure 3a Combustible mantels may be placed no closer to the Vision Gas Fireplace opening than the distances shown in the Figure 3a side view, above.
  • Page 14 The fireplace may be raised off the floor provided the top of the fireplace is no closer to the top of the 351/2” chase, or ceiling, than 35½ inches as shown in Figure Figure 3b The optional surrounds have an air slot in the 54”...

  • Page 15: Combustion Air Supply

    In addition to the air that moves through the firebox opening, combustion air MUST also be provided to the base of the flame in the Vision Gas Fireplace using either one of two methods: Method 1- When using a European Home Surround With this method, a minimum twenty square inch opening is cut in the wall face as shown in Figure 5.
  • Page 16 Any materials such as insulation which will impede this free flow of air must be removed. If a combustion air supply is not implemented correctly, the life of Vision Gas Fireplace components will be shortened. CAUTION Do not bring either outside air or air from another room or building level into the wall cavity.
  • Page 17 The final determination of the suitability of any particular kit must be made by the installer. If an outside air supply is desired it should be added to the room in which the Vision Gas Fireplace is installed, not to the chase enclosing the Vision Gas Fireplace.

  • Page 18: Framing

    FRAMING When wooden framing is used around the Vision Gas Fireplace opening it must be 2x4 framing ONLY. Figure 7 shows the minimum chase opening of 33” wide, 461/4” high and 16” deep. Figures 8, 9a and 9b show typical framing construction.

  • Page 19: Installing The Fireplace

    INSTALLING THE FIREPLACE Header heat shield flange After the framing has been completed, the fireplace can be installed. Place the header heat shield extension on the center of the header heat shield flange as shown in Figure 10. Figure 10 GAS SUPPLY Route the gas supply into the fireplace cabinet.

  • Page 20: Venting

    VENTING The Vision Gas Fireplace must be vented vertically with a listed Type “B” gas vent that is nominally 8 inches in diameter. Any offsets must allow a minimum stack draft of -0.05” w.c. to be maintained. The minimum vent run is 10 vertical feet from the flue outlet. Vertical runs as high as fifty feet are in compliance.

  • Page 21: Facing

    FACING After the gas supply has been routed and the venting has been installed, the front wall or face can be finished. Non-combustible material must be used in the gray area shown in Figure 14. Conventional drywall may be used OUTSIDE of this area.
  • Page 22 When enclosing your fireplace, the use of non-combustible building materials is required. Please read and understand the following. COMBUSTIBLE MATERIALS Materials that can catch fire and burn are considered combustible. Any material that is made of, or faced with, wood, wood pulp, paper, plastic or any other material that can catch fire and burn is considered combustible.

  • Page 23: Installing The Burner Module

    INSTALLING THE BURNER MODULE Either a VBM burner module or a 24VBM burner module may be installed into your Vision Gas Fireplace. Except for the electrical connections, both burner modules install identically. Where installation differences exist they are noted. VBM Burner Module – This burner module requires two connections; each end of the blocked flue sensor wiring harness must be connected to the VBM burner module.
  • Page 24 Place the burner module into the fireplace burner well and locate the two holes in the front of the module base onto the two studs on the bottom of the fireplace. Fasten with the two nuts and washers provided. See Figure 18. Tighten Here Tighten Here Figure 18...
  • Page 25 24VBM Burner ONLY Refer to Figure 20, Figure 21 and Appendix A for detailed views. 1. Cut the ring terminal off of the red wire of the blocked flue sensor harness leaving as much wire remaining as possible. Strip 1/4” of the insulation from the cut end and crimp the enclosed male push terminal onto this stripped end.
  • Page 26 Figure 21 Connect the flexible gas line from the valve to the gas supply pipe. After the gas supply has been connected, open the main supply and apply a leak detection fluid (or gas detector) to all the fittings to check for gas leaks.

  • Page 27: Panel Installation

    PANEL INSTALLATION Carefully unpack and lay out the four panels. Remove all plastic coating from the panels. Remove the side panel clips shown in Figure 23. Figure 23 Side Panel Clip Remove the rear panel clips and place the rear panel at the back of the fireplace. Reinstall the rear panel clips.

  • Page 28: Stone Configuration

    STONE CONFIGURATION The Vision Gas Fireplace can be operated with, or without, the decorative stones and/or embers. The following is the recommended stone/ember configuration. Slight differences in the placements are acceptable. When using the stones and embers, begin by placing one layer of the embers evenly over the entire burner top as shown in Figure 25.
  • Page 29 Figure 27 Next, place two large stones and three small stones on the burner as shown in Figure 27. Then place two medium and four small stones along the front edge of the burner as shown in Figure 28. Figure 28...

  • Page 30: Surrounds

    Finally, place the remaining two large, one medium and three small stones on top as shown in Figure SURROUNDS There are several optional surrounds available for the Vision Gas Fireplace. Ensure that the surround model is correct for the fireplace installation so the combustion air is not blocked.

  • Page 31: Lighting Instructions

    A. This appliance is equipped with an ignition device which automatically lights the pilot. Do not try to light the pilot by hand unless supervised by European Home Technical Support. B. BEFORE LIGHTING, smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.
  • Page 32 VBM Burner Only The VBM burner module has two safety features which affect the operation: 1) two-button child safety ignition 2) 45 second safety timer The safety ignition requires that two buttons be depressed to begin the ignition sequence and the timer requires that 45 seconds elapse between start attempts.
  • Page 33 24VBM Burner Only LIGHTING THE FIRE 1. STOP! Read the safety information on page 31. 2. This appliance is equipped with an ignition device which automatically lights the pilot. Do not try to light the pilot by hand. 3. Set the Flame Switch to OFF. 4.

  • Page 34: Maintenance

    Resetting the VBM System The Vision Gas Fireplace with a VBM burner should need to be reset only once, prior to initial use. This is done as follows: 1. Press and hold the receiver reset button until you hear the second of two beeps.
  • Page 35 Figure 31 Replacing the Batteries If your Vision Gas Fireplace operates on batteries and NOT a wall adapter, follow these yearly replacement instructions. With all parts of the fireplace at room temperature, remove the stones. Lift out the bottom liner panel from the fireplace.

  • Page 36: Vbm Troubleshooting

    VBM TROUBLESHOOTING OBSERVED PROBLEM: POSSIBLE CAUSE: REMEDY: A. No transmission (motor does not 1. Receiver must learn new code. 1. Reset system as above. turn) 2. Dead batteries. 2. Replace batteries. 3. The receiver is surrounded by 3. Change the position of the antenna. metal, reducing the transmission range.
  • Page 37 OBSERVED PROBLEM: POSSIBLE CAUSE: REMEDY: D. No pilot flame and control contin- 4. Over tightened thermocouple. 4. Replace valve and thermocouple inter- ues to spark rupter. 5. Receiver 5. Replace receiver and reprogram code as above. E. Pilot is lit and control continues 1.

  • Page 38: 24Vbm Troubleshooting

    Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Any repair and troubleshooting of the Vision Gas Fireplace must be done by a qualified technician only. Since the LED on the control module is hard to see after the Fireplace has been installed, the following assumes that the 24VBM Burner Assembly has been safely connected to a test bench and that all appropriate safety precautions are being observed.

  • Page 39: Parts List

    Large Stainless Surround VLSS-01 Small Stone Surround VSST-01 Large Stone Surround VLST-01 For replacement parts and customer service, contact: EUROPEAN HOME a division of Europa Ja, Inc. 376 Washington St. Suite 203 Malden, MA 02148 tel: 781/324-8383 fax: 781/324-8384 www.europeanhome.com...

  • Page 40: Warranty

    PRODUCT INSTALLATION RECORD Installer: Please complete this form. Customer: Please retain this information. Purchased From Date of Purchase Installed By Date of Installation Fireplace Serial Number Fuel Type...

  • Page 41: Third-Party Connections

    MUST be performed. Step 1. Re-terminate Harness The Vision Gas Fireplace cabinet comes with a blocked flue sensor and attached wiring harness. The harness runs down from the sensor and lays at the bottom of the cabinet. The ring terminal on the red wire must be replaced with the included 1/4”...
  • Page 42 Red Sensor Wire Violet Sensor Wire Cut, strip and Connect to TR crimp here Figure A-1. Sensor Harness to blocked flue sensor Red Sensor Wire connects here Figure A-2. Control Module Connections...
  • Page 43 Figure A-3. Transformer Connections...

  • Page 44: Power Venting The Vision Gas Fireplace

    APPENDIX B Power Venting the Vision Gas Fireplace The EUROPEAN HOME Vision Gas Fireplace is approved for use with either one of two Enervex brand power vent models; the RS-009 or the RSIF-146. These power vents are manufactured by Enervex Inc.
  • Page 46 The attached schematic is based on information in the ADC100 installation manual. When in doubt, follow the ADC100 installation manual. • Ensure that make-up air is available in the room in which the Vision Gas fireplace is installed. Your project HVAC engineer should be consulted prior to this installation. INSTALLATION •...
  • Page 47 (draft). Once the power vent has generated enough draft to reach the draft set-point, the Vision Gas Fireplace control circuit is closed and the Vision Gas Fireplace will light. When the Flame Switch is turned OFF the draft set-point will not be reached causing the ADC100 to open the control circuit and turning off the Vision Gas Fireplace.
  • Page 48 EUROPEAN HOME a division of Europa Ja, Inc. 376 Washington Street Suite 203 Malden, MA 02148 www.europeanhome.com rev.141113...
