G S E R I E S
L i n e a r · H e a r t h · B u r n e r
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
-- Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
G Series Linear Hearth Burner
This is an unvented gas-fired heater. It uses
air (oxygen) from the room in which it is
installed. Provisions for adequate combustion
and ventilating air must be provided. Refer to
page 6.
This appliance may be installed in an aftermarket,
permanently located, manufactured (mobile)
home, where not prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is not convertible for use with other gases.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
Report #284-F-08-4
1
Installation,
Operation
and
Owner's Manual
GVF-42
GVF-60
GVF-72
EuropeanHome.com
January 6, 2016
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for European Home GVF-42
Summary of Contents for European Home GVF-42
- Page 1 Installation, Operation Owner’s Manual G S E R I E S GVF-42 GVF-60 L i n e a r · H e a r t h · B u r n e r GVF-72 WARNING: If the information in these...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information Room Volume for Vent Free Specifications and Dimensions Listing Label Pre-installation Planning Electric Installation Gas Installation Installing the Burner Operating the Burner Maintenance Parts List Warranty Appendix A Product Installation Record Appendix B Troubleshooting Appendix C EuropeanHome.com G Series Linear Hearth Burner... - Page 3 IMPORTANT SAFETY INFORMATION Read these instructions carefully before installing or trying to operate this Vent Free gas heater. • Any change to this heater or its controls can be dangerous. • Improper installation or use of the heater can cause serious injury or death from fire, burns, explosion or carbon monoxide poisoning.
- Page 4 IMPORTANT SAFETY INFORMATION Read these instructions carefully before installing or trying to operate this Vent Free gas heater. 11. Correct installation of the fire media, proper location of the heater, and annual cleaning are necessary to avoid potential problems with sooting. Sooting, resulting from improper installation or operation, can settle on surfaces outside the fireplace.
-
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION Read these instructions carefully before installing or trying to operate this Vent Free gas heater. 20. The appliance must be isolated from the gas supply piping system by closing its equipment shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa). -
Page 6: Room Volume For Vent Free
ROOM VOLUME for VENT FREE CODES Adhere to all local codes or, in their absence, the latest edition of THE NATIONAL FUEL GAS CODE ANSI Z223.1 or NFPA54 which can be obtained from… American National Standards Institute, Inc. 1430 Broadway New York, NY 10018 National Fire Protection Association, Inc. - Page 7 Maximum BTU/hr. my space will support (use formula above) a) __________________ BTU/hr. of European Home G Series Linear Hearth Burner b) ____37,500________ If the answer to a) is greater than b) then your space will support the installation of the G Series Linear Hearth Burner; if a) is less than b) then your space will not support an G Series Linear Hearth Burner.
- Page 8 SPECIFICATIONS and DIMENSIONS SPECIFICATIONS G Series Linear Hearth Burner (all sizes) Fuel Natural Gas ONLY Manifold Pressure 3.5” (0.87 kPa) Minimum Supply 4.0” (1.0 kPa) Pressure Maximum Supply 7.0” (1.7 kPa) Pressure Orifice Size #47 DMS Input (High, BTU/hr.) 37,500 Input (Low, BTU/hr.) 25,000 Electrical...
- Page 9 SPECIFICATIONS and DIMENSIONS 5” 387/16” 53/16” GVF-42 Burner 375/16” 61/2” 5” 491/4” 53/16” GVF-60 Burner 375/16” 61/2” 5” 595/16” 53/16” GVF-72 Burner 375/16” 61/2” EuropeanHome.com G Series Linear Hearth Burner...
-
Page 10: Specifications And Dimensions
*(open in rear) 55/16” 60” 163/16” Optional GVF-60 Burner Cover *(open in rear) 55/16” 72” 163/16” Optional GVF-72 Burner Cover * For see through and peninsula installations, please contact European Home for special order burner cover. EuropeanHome.com G Series Linear Hearth Burner... -
Page 11: Listing Label
SPECIFICATIONS and DIMENSIONS CERTIFICATION OMNI-Test Laboratories, Inc. has certified that the G Series Linear Hearth Burners meet the ANSI Z21.11.2b-2011 ANSI Z.21.60-2012/CSA 2.26-2012 standards. G Series Linear Hearth Burner Listing Label EuropeanHome.com G Series Linear Hearth Burner... - Page 12 SPECIFICATIONS and DIMENSIONS GVF-42 GVF-60 GVF-72 433/8” 491/8” 591/4” (Opening Width without Cover) 47” 65” 77” (Opening Width with Cover) 18” 18” 18” (Distance to Lintel) 153/4” 153/4” 153/4” (Fireplace Depth) (Flue Opening) sq. in. sq. in. sq. in. Minimum Fireplace Dimensions Required by Model...
- Page 13 PRE-INSTALLATION PLANNING BEFORE YOU BEGIN Thank you for purchasing an G Series Linear Hearth Burner by European Home. This product has been designed to provide you with safe, trouble-free operation. Please read this manual thoroughly before beginning the installation. It has information which is important for safe installation and operation.
-
Page 14: Pre-Installation Planning
PRE-INSTALLATION PLANNING APPROVED INSTALLATIONS Your G Series Linear Hearth Burner is to be installed in a solid-fuel burning fireplace or a prefabricated fireplace listed to UL-127 or in a listed ventless firebox enclosure. When installed your linear hearth burner must sit fully inside the fireplace, behind the fireplace lintel. WARNING: Before installing in a solid-fuel burning fireplace, the chimney flue and firebox must be cleaned of soot, creosote, ashes and loose paint by a qualified chimney cleaner. - Page 15 PRE-INSTALLATION PLANNING MANTEL CLEARANCES 12.0” maximum Combustible mantel 11.0” minimum Top of existing fireplace opening Existing fireplace opening Combustible mantels may be no closer to the fireplace opening than 11.0” or deeper than 12.0”. EuropeanHome.com G Series Linear Hearth Burner...
- Page 16 ELECTRIC INSTALLATION WARNING When servicing controls label all wires prior to disconnection. Wiring errors can cause improper and dangerous operation. This appliance must be electrically grounded in accordance with local codes, or, in the absence of local codes, with either the National Electrical Code ANSI/NFPA 70.
-
Page 17: Electric Installation
ELECTRIC INSTALLATION G SERIES BURNER ELECTRICAL SCHEMATIC AC Adapter Jack EuropeanHome.com G Series Linear Hearth Burner... -
Page 18: Gas Installation
GAS INSTALLATION Note The installation of this product must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 This product is shipped from the factory for use with natural gas ONLY. Conversion to another fuel is NOT permitted. This product must be installed by a licensed plumber or gasfitter when installed within the Commonwealth of Massachusetts. - Page 19 INSTALLING the BURNER Place the burner in the center of the fireplace and connect the gas supply to the flexible connector attached to the burner. After the gas supply has been connected, open the main supply and check all of the fittings for gas leaks. Never use a flame to test for leaks.
-
Page 20: Installing The Burner
Although the fibers have a long life, they will eventually deteriorate. If this becomes apparent, replacement Embaglow can be purchased from your local fireplace retailer or European Home. BEFORE THE FIRST FIRE 1. - Page 21 OPERATING the BURNER RESETTING THE SYSTEM (Pairing the Remote and Receiver) The G Series Linear Hearth Burner should need to be reset only once, prior to initial use. This is done as follows: 1. Press and hold the receiver reset button (shown below) until you hear the second of two beeps. 2.
-
Page 22: Operating The Burner
OPERATING the BURNER FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition device which automatically lights the pilot. Do not try to light the pilot by hand. - Page 23 OPERATING the BURNER USING THE REMOTE CONTROL ELECTRONIC IGNITION SYSTEM Setting °C/24 Hour or °F/12 Hour Clock. Press OFF and SMALL FLAME to toggle between °F/12 hr and °C/24 hr clock. Setting the Time. Simultaneously press the SMALL FLAME and LARGE FLAME buttons, the display now flashes. Press LARGE FLAME to set the hour and SMALL FLAME to set the minute.
- Page 24 OPERATING the BURNER Setting the Temperature. Select either the Temp mode or the Temp mode by briefly pressing the SET button. Hold the SET button until the TEMP display flashes. Set the desired temperature with SMALL FLAME or LARGE FLAME . Press OFF to complete the program.
-
Page 25: Maintenance
MAINTENANCE A qualified service agency should conduct an annual inspection and maintenance of your G Series Linear Hearth Burner to keep it running safely. The following procedures should be performed only by a qualified service person. The gas supply should be turned off whenever a maintenance procedure is performed. All parts of the fireplace that are removed for servicing must be replaced prior to operation. -
Page 26: Parts List
MAINTENANCE Make a periodic visual inspection of the pilot and main burner flames. The burner flames should look similar to those shown above. The pilot flame should look similar to that shown at left. G SERIES LINEAR HEARTH BURNER PARTS LIST REPL-GS-G6R-R3AM Receiver REPL-GS-G6R-H3T5... - Page 27 The G Series Linear Hearth Burners European Home warrants the gas controls and burner of the G Series Linear Hearth Burner against defects in materials and workmanship for a period of ONE (1) YEAR from the date of original retail purchase.
- Page 28 APPENDIX B PRODUCT INSTALLATION RECORD Installer: Please complete this form. Customer: Please retain this information. Purchased From Date of Purchase Installed By Date of Installation Serial Number Fuel Type NATURAL GAS EuropeanHome.com G Series Linear Hearth Burner...
- Page 29 APPENDIX C FUNCTION POSSIBLE CAUSE REMEDY Replace transmitter batteries. Quality 9V Transmitter batteries low. alkaline recommended. Press UP and OFF buttons Replace transmitter batteries. Quality 1.5V to start ignition sequence. Receiver batteries low. AA alkaline recommended. Beep will occur each second.
- Page 30 APPENDIX C FUNCTION POSSIBLE CAUSE REMEDY Check cable connection between receiver TC- and SW-cable reversed. and interrupter block. Pilot lit. Magnet unit not operating properly. Replace gas valve. Short between interrupter and SW cable. Check interrupter block connection. No gas (magnet unit drops after 30 second Check gas supply.
- Page 31 NOTES...
- Page 32 EUROPEAN HOME www.europeanhome.com IGGVF02-160106 EuropeanHome.com G Series Linear Hearth Burner...
