2.6 System requirement

Model No.
Local console side
Network Side
Remote Console
side
Computer side
Model No.
Console side
Network Side
Remote Console
side
Computer side

2.7 Cable diagrams

PS/2 Cable:
Mini Din 6 pin Male to Male
VGA Cable:
HDB15 pin Male to Male
USB 2.0 Cable:
USB A-B cable
8 ports KVM-0850
One VGA Monitor
One Keyboard
One Mouse
10/100Mbps Ethernet
or Modem
One computer
8 PCs with 8 3-in-one cables (One
HDDB 15-pin male to one HDDB 15-pin
and two Mini Din 6-pin PS/2 cables)
16 ports KVM-1650
One VGA Monitor
One Keyboard
One Mouse
10/100Mbps Ethernet
or Modem
One computer
16 PCs with 16 3-in-one cables (One
HDDB 15-pin male to one HDDB 15-pin
and two Mini Din 6-pin PS/2 cables)
10
KVM-0850/1650 IP KVM switch
