- Page 1 KVM-0850/1650 IP KVM switch LevelOne KVM-0850/1650 8/16-port IP KVM Switch for PS/2 User Manual Ver 1.00-0504...
- Page 2 Cable diagrams ......................... 10 Product Details ......................... 11 3. Hardware installation ......................12 Operation Overview ......................... 12 Connecting KVM-0850/1650 to the host system ..............12 4. Configuration .......................... 15 Initial Configuration ......................... 15 4.1.1 Initial configuration via DHCP server.................. 15 4.1.2...
- Page 3 KVM-0850/1650 IP KVM switch 6.4.2 Keyboard/Mouse ........................57 6.4.3 Video............................. 59 Device Settings ........................59 6.5.1 Network ..........................59 6.5.2 Dynamic DNS ........................62 6.5.3 Security..........................64 6.5.4 Certificate ..........................65 6.5.5 Serial Port ..........................68 6.5.6 Date And Time........................70 6.5.7...
- Page 4 If done so, KVM-0850/1650 may not be able to detect these. You are on the safe side with all standard VESA video modes. Please refer to Appendix C for a list of all known modes.
- Page 5 You will be asked if the values are correct and get a chance to correct them. After confirming, KVM-0850/1650 performs a reset. 2.Use a crossover Ethernet cable to connect KVM-0850/1650 to a subnet where a DHCP server is available. After the DHCP server has assigned an IP address to KVM-0850/1650 you can use the web interface to configure the device.
- Page 6 60 Hz. 2.1 When the server is up and running KVM-0850/1650 gives you a full control over the remote server. The Management Console allows you to access the remote server’s graphics, keyboard and mouse and to send special commands to the server.
- Page 7 KVM-0850/1650 IP KVM switch Type of failure Detected by Hard disk failure Console screen, CMOS set-up information Power cable detached, power Server remains in power on state after power on supply failure command has been given. CPU Controller, main board failure. Power supply is on, but there is no video output.
- Page 8 KVM-0850/1650 IP KVM switch 2.4 Package contents Model No.: 8 port IP KVM Switch- KVM-0850 Base unit- 8 port KVM-0850 1 PC User’s manual 1 PC AC to DC Power Adapter 1 PC Rack Mount Kit 1 SET Daisy Chain Cable...
- Page 9 KVM-0850/1650 IP KVM switch 2.5 Technical specifications Model No. 8 port KVM-0850/1650 16 port KVM-0850/1650 PC Port Console Port PC Port Connector VGA HDDB 15-pin(shared with PS/2 keyboard and Mouse) (All Female Types) USB Type B receptacle Console Port Local Console: PS/2 Keyboard Mini Din 6 pin...
- Page 10 KVM-0850/1650 IP KVM switch 2.6 System requirement Model No. 8 ports KVM-0850 Local console side One VGA Monitor One Keyboard One Mouse Network Side 10/100Mbps Ethernet or Modem Remote Console One computer side Computer side 8 PCs with 8 3-in-one cables (One...
