Océ Operation Guide
Education Services
1.1.1.
English version
Océ PP20D
Operation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP20D and is the answer not in the manual?

Questions and answers

Related Manuals for Oce PP20D

Summary of Contents for Oce PP20D

  • Page 1 Océ Operation Guide Education Services 1.1.1. English version Océ PP20D Operation Guide...
  • Page 2 Caution NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION. Notice on Software SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER’S EMULATION MODE. The printer is factory-set to emulate the PCL. The emulation mode can be changed by following the procedures described in Chapter 1 Notice The information in this manual is subject to change without notification.

  • Page 3: Limited Warranty

    IBM PROGRAM LICENSE AGREEMENT THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE SOFTWARE PROGRAMS (“PROGRAMS”) WHICH BELONG TO INTERNATIONAL BUSINESS MACHINES CORPORATION (“IBM”). THIS DOCUMENT DEFINES THE TERMS AND CON- DITIONS UNDER WHICH THE SOFTWARE IS BEING LICENSED TO YOU BY IBM. IF YOU DO NOT AGREE WITH THE TERMS AND CONDITIONS OF THIS LICENSE, THEN WITHIN 14 DAYS AFTER YOUR ACQUISITION OF THE DEVICE YOU MAY RETURN THE DEVICE FOR A FULL REFUND.
  • Page 4 Typeface Trademark Acknowledgement All resident fonts in this printer are licensed from Agfa Corporation. Helvetica, Palatino and Times are registered trademarks of Linotype-Hell AG. ITC Avant Garde Gothic, ITC Bookman, ITC ZapfChancery and ITC Zapf Dingbats are registered trademarks of International Type- face Corporation.

  • Page 5: Table Of Contents

    Contents Introduction ....................vii Guide to the Manuals ........................... viii Guide to the Operation Guide........................ix Basic Operations ..............1-1 Chapter 1 1.1 Operator Panel ............................1-2 1.1.1 Indicators............................1-3 1.1.2 Keys............................... 1-3 Maintenance ................2-1 Chapter 2 2.1 Toner Container Replacement ......................2-2 2.1.1 Toner Container Replacement Interval ..................
  • Page 6 Contents Paper Selection............... 4-1 Chapter 4 4.1 General Guidelines ..........................4-2 4.1.1 Paper Availability......................... 4-2 4.1.2 Paper Specifications ........................4-2 4.2 Selecting the Right Paper........................4-3 4.3 Special Paper............................4-7 4.3.1 Transparency (overhead projection film) ..................4-7 4.3.2 Adhesive-Backed Labels ......................4-8 4.4 Paper Type ............................
  • Page 7 Contents Printer Specifications ............. C-1 Appendix C C.1 Printer Specifications........................... C-2 Glossary..................Glossary-1 Index ....................Index-1...

  • Page 8: Introduction

    Introduction The Kyocera Mita page printer has many desirable features, such as the duplex printing mode which lets you print onto both sides of the paper and an Auto Media Type Selection function that automatically selects the media before printing. This section explains the following topics: •Guide to the Manuals •Guide to the Operation Guide...

  • Page 9: Guide To The Manuals

    Guide to the Manuals Item Description Installation Guide Describes procedures from printer setup to printing a (paper manual) test page. KX Printer Driver Describes the procedure to install the printer Installation Guide driver software. (paper manual) Operation Guide Guides you through topics concerning the operations (this manual) and maintenance of the printer.

  • Page 10: Guide To The Operation Guide

    Guide to the Operation Guide This Operation Guide guides you through the following topics: Chapter 1 Basic Operations This chapter describes the names and functions of the keys and indicators on top of the printer. Chapter 2 Maintenance This chapter explains how to replace the toner container and how to care for your printer.

  • Page 11: Chapter 1 Basic Operations

    Basic Operations Chapter 1 This chapter explains the following topic: • Operator Panel...

  • Page 12: Operator Panel

    Operator Panel Operator Panel The operator panel on top of the printer consists of four indicators and two keys. The four indicators light, flash, and go off in combination, indicating the printer’s status. The keys perform operations, such as canceling data, switching the printer mode between online and offline status, and printing status pages.

  • Page 13: Indicators

    Operator Panel 1.1.1 Indicators Refer to the following table for the name and description of each indicator. The same indicator can have a variety of meanings, depending on the speed at which it is flashing. For details, see Chapter Reference Name Status Meaning...

  • Page 14: Understanding The Status Page

    Operator Panel Understanding the Status Page The following is the printout of a typical standard status page. Its contents are explained in detail on the next page. FS-1020D Page Printer STATUS PAGE Firmware Version: Released: Hardware Information Memory Page Information Installed Options Network Status Emulation...
  • Page 15 Operator Panel 1 — Software Version This information shows the software (firmware) version and date of issue of the printer. 2 — Hardware Information This information shows the currently selected paper source (indicated by an asterisk), paper size, and various other printer settings. 3 —...
  • Page 16 Operator Panel 10 — Interface Information This information shows all interfaces installed in the printer and the currently selected interface (marked with an asterisk). The Font section shows the font that is automatically selected when the printer starts up (default font). It is possible to set different default fonts for each interface.

  • Page 17: Chapter 2 Maintenance

    Maintenance Chapter 2 This chapter explains how to replace the toner container and how to clean parts such as the registration roller and charger wire. This chapter explains the following topics: • Toner Container Replacement • Cleaning the Printer...

  • Page 18: Toner Container Replacement

    Toner Container Replacement Toner Container Replacement When the printer runs low on toner, the (toner) indicator flashes on the operator panel. Be sure to promptly replace the toner container and clean the inside of the printer when this message appears. If the printer stops printing while the (toner) indicator is lit, replace the toner container to continue printing.

  • Page 19: Replenishing Toner

    Toner Container Replacement 2.1.2 Replenishing Toner Open the printer’s top cover. Top Cover Figure 2-1 Pull lock lever #1 to the release (UNLOCK) position, then pull lock lever #2 to the release (right) position. Lock Lever #2 Lock Lever #1 Figure 2-2 Gently remove the old toner container.
  • Page 20 Toner Container Replacement Take the new toner container from the bag. Hold it with the protective seal (orange-colored) facing up. Shake the toner container horizontally at least 5 times. This ensures that the toner is evenly distributed inside. New Toner Container Figure 2-4 Carefully remove the protective seal (orange-colored).
  • Page 21 Toner Container Replacement Install the new toner container in the printer. Push firmly on the top of the container at the positions marked PUSH HERE until you hear it click in place. Figure 2-6 While pushing down on the toner container, push lock lever #1 to the lock (LOCK) position.

  • Page 22: Cleaning The Printer

    Cleaning the Printer Cleaning the Printer To avoid print quality problems, the interior of the printer must be cleaned with every toner container replacement. Cleaning should be done from time to time to avoid print quality problems. 2.2.1 Printer Interior To avoid print quality problems due to paper dust and debris, clean the interior of the printer in the following manner.
  • Page 23 Cleaning the Printer Never stand the process unit on end. Figure 2-10 Use the supplied wiper cloth to clean dust and dirt away from the registration roller (metal). Transfer Roller Registration Roller Figure 2-11 While cleaning, be careful to avoid touching the transfer roller (the black roller).
  • Page 24 Cleaning the Printer Slide the charger cleaner knob (green-colored) back and forth 2 to 3 times, then return it to its CLEANER HOME POSITION Charger Cleaner Knob Figure 2-12 After cleaning, make sure you restore the charger cleaner to its home position.
  • Page 25 Cleaning the Printer Close the front cover. Front Cover Figure 2-14 Close the top cover by pressing down on the front left and right corners of the top cover. Top Cover Figure 2-15...

  • Page 26: Chapter 3 Troubleshooting

    Troubleshooting Chapter 3 This chapter explains how to handle printer problems that may occur. If a problem cannot be corrected, contact your Kyocera Mita dealer. This chapter explains the following topics: • General Guide for Troubleshooting • Print Quality Problems •...

  • Page 27: General Guide For Troubleshooting

    General Guide for Troubleshooting General Guide for Troubleshooting There are quite a few printer problems which may be corrected by the user. If some kind of printer problem should occur, check the following before concluding the printer is broken. This section explains how to correct these problems. Symptom Check Items Corrective Action...

  • Page 28: Print Quality Problems

    Print Quality Problems Print Quality Problems As the following table shows, there are many possible causes of print quality problems, such as blank output as. The troubleshooting procedure for each type of problem is explained below. If you still can not solve the problem, contact your Kyocera Mita dealer.
  • Page 29 Print Quality Problems Printed Results Corrective Action Faint or blurred printing Check the EcoPrint setting. When this setting is On, switch it to Off on the KM-NET for Clients. (See the KM-NET for Clients Operation Guide.) Confirm the (toner) indicator. If the (toner) indicator flashes, install a new toner kit.
  • Page 30 Print Quality Problems Printed Results Corrective Action Characters out of position. Check the file or program. Check whether the problem is being caused by a PRESCRIBE command error. If the problem occurs only with a specific file or program, the most likely cause is an error in a parameter to a command or command syntax.

  • Page 31: Indicators

    Indicators Indicators There are four indicators on the printer’s operator panel. These light, flash, and turn off in combination to indicate the printer’s current status. This section explains the indicators on the operator panel and the appropriate corrective action to take in each case. Indicator displays can be classified into three categories: maintenance, errors, and normal.

  • Page 32: Maintenance Messages

    Indicators 3.3.1 Maintenance Messages The following table lists error messages that can be dealt with by the user. Read the explanations carefully. Indicator KM-NET for Clients display Corrective Action The paper has run out. Add paper to the Add paper <paper source> paper cassette (1 or 2) or MP tray.
  • Page 33 Indicators Indicator KM-NET for Clients display Corrective Action There is no cassette in the feeder, or the Paper path error cassette is not inserted properly. After reinserting the paper cassette, you should be able to print. There is no more toner in the toner container. Replace toner The printer has stopped because there is no more toner.

  • Page 34: Errors Requiring Service Personnel Attention

    Indicators 3.3.2 Errors Requiring Service Personnel Attention When the following errors occur, turn off your printer, remove the plug from the AC outlet, and contact your Kyocera Mita dealer. The indicators are shown in two different states, according to the way they alternate. Indicator Corrective Action Main motor error (2000error)
  • Page 35 Indicators Indicator Corrective Action Fuser error (6000 error) Contact your Kyocera Mita dealer. The waste toner reservoir is full (7980 error) Turn off the printer’s power and remove the process unit from the printer. Gently shake the process unit horizontally a few times, then reinstall it into the printer. Turn on the printer’s power.
  • Page 36 Indicators Indicator Corrective Action Controller system error (F030 error) Contact your Kyocera Mita dealer. Communication error (F040 error) Contact your Kyocera Mita dealer. Engine ROM check sum error (F050 error) Contact your Kyocera Mita dealer. Table 3-4 (Continued) 3-11...

  • Page 37: Error Messages

    Indicators 3.3.3 Error Messages With the following errors, printing continues when you press the printer’s key. You can confirm these errors by printing a status page. (See pages and 1-5.) Indicator KM-NET for Corrective Action Clients display The specified file is not found. File not found Press the key to resume printing.
  • Page 38 Indicators Indicator KM-NET for Corrective Action Clients display The printer has halted because you attempted to insert/ None remove a memory card into/from the printer slot while the printer power is on. Turn the power switch off and then on to restart the printer. Make sure to turn the printer power off before inserting/ removing a memory card.

  • Page 39: Normal Indicator Display

    Indicators 3.3.4 Normal Indicator Display The following displays appear during normal printer operation. Indicator KM-NET for Clients display Description Data inside the printer is being canceled. Cancelling data The indicators light in sequence from the top, then go off in sequence from the bottom. This process is repeated twice.

  • Page 40: Paper Jam Removal

    Paper Jam Removal Paper Jam Removal This section describes how to remove paper when it jams in the printer. The printer will stop whenever paper jams in the printer or paper is not fed from a paper cassette. The printer will go offline and (paper jam) indicator will light in the operator panel.

  • Page 41: Jam At The Paper Cassette

    Paper Jam Removal 3.4.2 Jam at the Paper Cassette Pull out the paper cassette and remove any partially fed paper, then re- close the paper cassette. Open and close the printer’s top cover to clear the error. The printer then automatically warms up and resumes printing. Follow the same steps for clearing the jammed paper at the option paper feeder’s paper cassette.
  • Page 42 Paper Jam Removal Pull the paper cassette all the way out of the printer. Paper Cassette Figure 3-4 Open the duplexer’s rear cover and remove any jammed paper. Duplexer’s Rear Cover Figure 3-5 Open the duplexer’s front cover and remove any jammed paper. Duplexer’s Front Cover Figure 3-6 Insert the paper cassette into the slot in the printer.

  • Page 43: Jam Inside The Printer

    Paper Jam Removal 3.4.4 Jam Inside the Printer When a paper jam occurs inside the printer, clear it using the following procedure. Open the printer’s top and front covers. Top Cover Front Cover Figure 3-7 Remove the process unit from the printer as shown in the figure. Process Unit Figure 3-8 Remove the jammed paper from the printer as shown in the figure.

  • Page 44: Jam At The Mp Tray

    Paper Jam Removal When the jammed paper appears to be pinched by rollers, pull it along the normal paper running direction. After you have removed the jammed paper, put the process unit back into the printer. Close the printer’s front cover and top cover. The printer then automatically warms up and resumes printing.
  • Page 45 Paper Jam Removal Open the printer’s top and front covers. Top Cover Front Cover Figure 3-12 Remove the process unit from the printer as shown in the figure. Process Unit Figure 3-13 3-20...
  • Page 46 Paper Jam Removal Use the following procedure that corresponds to the status of the jammed paper, in order to remove that paper. (A) If the leading edge of the jammed paper has been fed further into the printer than the metal registration roller, remove the jammed paper by its leading edge.

  • Page 47: Chapter 4 Paper Selection

    Paper Selection Chapter 4 This chapter explains the following topics: • General Guidelines • Selecting the Right Paper • Special Paper • Paper Type...

  • Page 48: General Guidelines

    General Guidelines General Guidelines The printer is designed to print on high-quality copier bond paper (the kind used in ordinary dry copier machines), but it can also accept a variety of other types of paper within the limits specified below. The manufacturer assumes no liability for problems that occur when paper not satisfying these requirements is used.

  • Page 49: Selecting The Right Paper

    Selecting the Right Paper Selecting the Right Paper Laser printing is a process involving laser light, electrostatic discharge, toner, and heat. In addition, as the paper passes through the printer it undergoes considerable sliding, bending, and twisting motions. A high- quality printing paper matching the printer’s requirements withstands all these stresses, enabling the printer to turn out clean, crisp printed copies consistently.

  • Page 50: Paper Size

    Selecting the Right Paper Paper Size Cassettes and an MP tray are available for the paper sizes listed in Table 4-2. The dimensional tolerances are ±0.7 mm (±0.0276 inches) for the length and width. The angle at the corners must be 90° ±0.2°. Multi-Purpose tray Size Cassette or multi-purpose tray...

  • Page 51: Moisture Content

    Selecting the Right Paper Thickness (Caliper) Thick paper is referred to as high-caliper paper and thin paper as low- caliper paper. The paper used with the printer should be neither extremely thick nor extremely thin. If you are having problems with paper jams, multiple feeds, and faint printing, the paper you are using may be too thin.
  • Page 52 Selecting the Right Paper Other Paper Properties Porosity: Refers to the density of the paper structure; that is, to how openly or compactly the fibers are bonded. Stiffness: Limp paper can buckle inside the printer, while paper that is too stiff may bind.

  • Page 53: Special Paper

    Special Paper Special Paper The following types of special paper can be used: • Transparency (overhead projection film) • Adhesive-backed label paper • Envelopes • Colored paper • Preprinted paper • Recycled paper Use paper that is sold specifically for use with copiers (heat-fusing type). Transparency, label paper, and envelopes should not be placed in the paper cassette;...

  • Page 54: Adhesive-Backed Labels

    Special Paper 4.3.2 Adhesive-Backed Labels The basic rule for printing on adhesive labels is that the adhesive must never come into contact with any part of the printer. Adhesive paper sticking to the drum or rollers will damage the printer. Label paper must be manually fed.
  • Page 55 Special Paper Postcards Fan the stack of postcards and align the edges before loading them in the MP tray. Make sure the postcards you are going to set are not curled. Feeding curled postcards may cause paper jams. Some postcards have rough edges on the back (those are created when the paper is cut).

  • Page 56: Thick Paper

    Special Paper Thick Paper Fan the stack of paper and align the edges before loading them in the MP tray. Some types of paper have rough edges on the back (those are created when the paper is cut). In this case, put the paper on a flat place and rub the edges once or twice with, for example, a ruler to smooth them in the same way as described in Postcards...

  • Page 57: Paper Type

    Paper Type Paper Type The printer is capable of printing under the optimum setting for the type of paper being used. Setting the paper type for the paper source by using the KM-NET for Clients utility will cause the printer to automatically select the paper source and print in the mode best suited to that type of paper.

  • Page 58: Chapter 5 Fonts

    Fonts Chapter 5 This chapter describes the types of fonts installed with the printer. • Internal Fonts • List of Fonts...

  • Page 59: Internal Fonts

    Internal Fonts Internal Fonts A font is a set of characters of a particular design. The design is referred to as a typeface. Several characteristics identify a font. These include the code Technical Reference set (for details on code sets, please read the provided on the CD-ROM supplied with the printer), spacing, pitch, height, style, stroke weight, and typeface family.

  • Page 60: List Of Fonts

    List of Fonts List of Fonts This section contains a full list of the printer’s internal fonts. 5.2.1 Internal Scalable and Bitmap Fonts and KPDL Fonts Font number Font samples...
  • Page 61 List of Fonts Font number Font samples...
  • Page 62 List of Fonts Font number Font samples...
  • Page 63 List of Fonts Font KPDL Fonts ( 1 )
  • Page 64 List of Fonts Font KPDL Fonts ( 2 )

  • Page 65: Appendix A Options

    Options Appendix A This appendix explains available options, how to expand the printer’s memory, and also how to install the memory card and the network interface card. • Available Options • Expansion Memory Installation • Memory (CompactFlash) Card • Network Interface Card...

  • Page 66: Available Options

    Available Options Available Options The following options are available for the printer: Either the network interface card or the serial interface board can be installed in the printer. PF-17 Paper Feeder Figure A-1 IB-11 Serial Interface Board Kit Figure A-2 IB-20/21E/22 Network Interface Card Figure A-3 Memory (CompactFlash) Card...

  • Page 67: Expansion Memory Installation

    Expansion Memory Installation Expansion Memory Installation This appendix begins by explaining how to install a DIMM (dual in-line memory module) on the main circuit board. The FS-1020D comes supplied with 16 MB of memory installed. A slot is provided for expanding the memory in your printer so that more complex printing can be done, as well as increasing the printing speed.
  • Page 68 Expansion Memory Installation DIMM to be used Contact your Kyocera Mita dealer for information on purchasing the DIMM that are best suited for use with this printer. Either an 8 MB, 16 MB, 32 MB, 64 MB, 128 MB, or 256 MB DIMM can be used for memory expansion.
  • Page 69 Expansion Memory Installation After removing the side cover, you can see the DIMM socket on top of the main circuit board. DIMM socket Figure A-8 Remove the DIMM from its package. Open the clips on both ends of the DIMM socket. Clips Figure A-9 Insert the DIMM into the DIMM socket so that the notches on the...
  • Page 70 Expansion Memory Installation Close the clips on the DIMM slot to secure the DIMM. Figure A-11 When you have finished installing the DIMM, replace the side cover and fasten it with the screw. To remove a DIMM: Remove the side cover as shown in steps 1 to 3 on page A-4, then carefully pull the end clips outwards and pull the DIMM out of the socket.

  • Page 71: Setting The Printer Driver

    Expansion Memory Installation Setting the Printer Driver After you install the additional memory to the printer, follow the instructions below to set the printer driver so that the printer can use the memories efficiently. Click the Windows Start button, and then click Printers and Faxes. Right click the Kyocera Mita FS-1020D KX icon, and click Properties.

  • Page 72: Memory (Compactflash) Card

    Memory (CompactFlash) Card Memory (CompactFlash) Card Insert the memory (CF) card into the card slot located on the rear of the printer. A memory card is a microchip card that may contain option fonts, macros, forms, etc. The printer reads the contents of the card into its internal memory when printer is turned on.
  • Page 73 Memory (CompactFlash) Card If the Network Interface Card or the Serial Interface Board is installed Remove the two screws from the network interface card or the serial interface board and remove it. Network Interface Card (or Serial Interface Board) Screws Figure A-13 Insert the memory card in the slot.

  • Page 74: Network Interface Card

    Network Interface Card Network Interface Card If the serial interface board kit is installed, remove it to use the network interface card. Insert the option network interface card into the option interface slot at the rear of the printer. The network interface card enables the printer to be used in a network.

  • Page 75: Appendix B Host Computer Interface

    Host Computer Appendix B Interface This appendix describes the signals used in the laser printer’s parallel, USB, and serial (option) interfaces. It also lists pin assignments, signal functions, timings, connector specifications, and voltage levels. For details on the network interface, refer to the IB-21E/IB-22 User’s Manual contained on the CD-ROM that is supplied with the printer.

  • Page 76: Parallel Interface

    Parallel Interface B.1 Parallel Interface B.1.1 Parallel Interface Communication Modes The printer features fast data transmission on the parallel interface. The parallel interface mode can be activated from the KM-NET for Clients utility contained on the Kyocera Mita Software Library CD-ROM supplied with the printer as follows: Use a parallel printer cable that complies with the IEEE1284 standard.
  • Page 77 Parallel Interface In/out Description Strobe* [nStrobe] Data 0 [Data 1] Data 1 [Data 2] Data 2 [Data 3] Data 3 [Data 4] Data 4 [Data 5] Data 5 [Data 6] Data 6 [Data 7] Data 7 [Data 8] Acknowledge* [nAck] Busy [Busy] Paper Empty [PError] Online (Select) [Select]...
  • Page 78 Parallel Interface Detailed descriptions of the signals follow. Strobe* [nStrobe] (Pin 1) A negative-going Strobe* pulse causes the printer to read and latch the data on the Data 0 [1] to Data 7 [8] signal lines. Data 0 [1] to Data 7 [8] (Pins 2 to 9) These eight signals form the data byte sent from the host computer to the printer.
  • Page 79 Parallel Interface Select In [nSelectIn] (Pin 36) This signal is used in some versions of the Centronics interface to enable the computer to force the printer online. The Paper Empty, Online, and Error signals are not used unless enabled by the FRPO command (O2 parameter).

  • Page 80: Usb Interface

    USB Interface B.2 USB Interface This printer supports the Full-Speed USB (Universal Serial Bus) 2.0. USB interface specifications and interface signals are as follows. B.2.1 Specifications Basic specification Complies with the Full-Speed USB 2.0. Connectors Printer: B-type receptacle (female) with upstream port Cable: B-type plug (male) Cable Use shielded cable that complies with the Full-Speed USB 2.0 standards...

  • Page 81: Serial Interface (Option

    Serial Interface (Option) B.3 Serial Interface (Option) Installing the optional serial interface board kit (IB-11) in the printer enables connection to a computer with an RS-232C standard serial interface. B.3.1 RS-232C Interface Interface Signals The pins of the printer’s RS-232C interface connector carry the signals listed in Table B-3.
  • Page 82 Serial Interface (Option) SG - Signal Ground - (Pin 7) All signals can transmit between the printer and the host computer to send each signal with a signal ground. DTR - Data Terminal Ready - (Pin 20) This output is used as a buffer nearly-full handshake line. It is held high (above 3 volts) when the buffer can accept more data.

  • Page 83: Rs-232C Protocol

    RS-232C Protocol B.4 RS-232C Protocol A protocol is a set of rules the computer follows in sending data to the printer. The RS-232C parameters are stored in battery backed-up memory. They are indicated on the status printout. They can be changed by the FRPO (firmware reprogram) command described in the Technical Reference...

  • Page 84: Prescribe Frpo D0 Command

    RS-232C Protocol H5: Protocol logic Parameter value Meaning Combination of 1 and 3 below DTR/DSR, positive logic DTR/DSR, negative logic XON/XOFF ETX/ACK XON/XOFF recognized only as protocol The factory setting is 0. H6: Buffer nearly-full threshold This is a percentage from 0 to 99. The factory setting is 90. H7: Buffer nearly-empty threshold This is a percentage from 0 to 99.

  • Page 85: Rs-232C Cable Connection

    RS-232C Cable Connection B.5 RS-232C Cable Connection B.5.1 Obtain a Suitable RS-232C Cable Make sure that the RS-232C cable is wired correctly. The cable must be a null modem cable; that is, one in which pin 2 on either end of the cable is connected to pin 3 on the other end.
  • Page 86 RS-232C Cable Connection With Windows XP , proceed as follows: Click on the Start button in the Windows XP task bar and align the cursor with Settings, then click on Control Panel from among the items displayed. The Control Panel window opens. Double click on System. System Properties window opens.
  • Page 87 RS-232C Cable Connection In DOS, enter the following commands: C:\>MODE COM1:96,N,8,1,P C:\>MODE LPT1:=COM1 To test the interface, enter the following: CTRL P C:\>DIR CTRL P The software settings made using the above procedures are temporary. On most computers, permanent settings must be made with DIP switches. B-13...

  • Page 88: Appendix C Printer Specifications

    Printer Specifications Appendix C...

  • Page 89: Printer Specifications

    Printer Specifications C.1 Printer Specifications Item Description Printing method Electrophotography, laser scan Printing speed Simplex printing : 20 pages/minute (A4 size/Plain) 21 pages/minute ( Letter size/Plain) Duplex printing : 10 pages/minute (A4/Letter size/Plain) When printing multiple copies of the same page Resolution Fast 1200 mode 600 dpi (vertical and horizontal) with KIR (Kyocera Image...
  • Page 90 Printer Specifications Item Description Ambient conditions Temperature: 10 to 32.5°C Humidity: 20 to 80% RH Optimum conditions: 23°C (73.4°F), 60% RH Altitude: Max. 2000 m (6500 feet) Illumination: Max. 1500 lux Power requirements 110 V , 60 Hz, max. 6.5 A 120 V , 60 Hz, max.

  • Page 91: Glossary

    Glossary Glossary Glossary-1...

  • Page 92: Cassette Mode

    Glossary Cassette mode IEEE1284 This is an operation mode for the MP tray. When This is a standard used when connecting a this mode is used, approximately 50 sheets of printer to a computer, and was established by the plain paper can be fed continuously, the same as Institute of Electrical and Electronic Engineers for the cassette.

  • Page 93: Prescribe Commands

    Glossary MP tray Parallel interface This is an abbreviation for Multi-Purpose tray. With this interface, data transfer between the The MP tray is used instead of the cassette when printer and the computer takes place on 8-bit printing on envelopes, postcards, transparency chunks.

  • Page 94: Sleep Mode

    Glossary Sleep mode This mode is activated after a specified amount of time elapses. The printer goes into economy mode and a minimum amount of power is consumed. You can change the amount of time before the printer goes into sleep mode from the KM-NET for Clients.

  • Page 95: Index

    Index Index-1...
  • Page 96 Index KM-NET VIEWER Glossary-2 Paper cassette 3-7, 3-16 KPDL Glossary-2 Paper feeder (PF-17) A-2 Kyocera Mita Document Library Paper jam 3-7, 3-15 Adhesive label 4-8 viii Paper size 4-4 Paper type 4-11 Parallel interface B-2, Glossary-3 Charger wire 3-3, 3-4 communication modes B-2 Label 4-8 Cleaner home position 2-8...
  • Page 97 Index wiper cloth 2-7 Top cover 2-3, 3-7 Transfer roller 2-7, 3-4 Transparency 4-7 Troubleshooting error messages 3-12 guidelines 3-2 indicators 3-6 interface 3-2 maintenance messages 3-7 quality problems 3-3 Typeface 5-2 USB interface B-6, Glossary-4 Windows B-12 Index-3...
