Atlona AT-HD30SR Quick Manual

Powerless HDMI Extender
over CAT5e/6 Cable
Introduction:
The AT-HD30SR is designed to replace long runs of HDMI
cable with CAT5E/6 cable( also called Ethernet, or LAN ca-
ble). (Atlona recommends using CAT6 cable for all extender
products) This product is capable of extending 1080p signal
from any HDMI or DVI source up to 30 Meters (99 ft.) with no
signal degradation. LED indicator lights on the AT-HD30SR
activate when the unit is connected properly.
KEY FEATURES:
· Simple connection. No additional HDMI cables required.
· Transfers HDMI Signal ( Digital Video and Audio ) over
CAT5E/6 cable up to 30 meters (99ft) at Full 1080P v1.3.
· Auto feedback, equalization and amplification adjustment
regardless of cable length.
· Compact size.
· Signaling rates up to 2.25Gbits
· Supports HDMI or DVI inputs.
· HDCP and IEEE-568B compliant.
PACKAGE CONTENTS
1) Sender unit AT-HD30S
2) Receiver unit AT-HD30R
3) Manual
4) 8.5" pig tail
SKU: AT-HD30SR
Safeguards
· To reduce the risk of electric shock, do not expose this
product to rain, water or moisture.
Precautions
· FCC Regulations state that any unauthorized
modifications to this equipment could void the user's
authority to operate this equipment.
· Use only accessories recommended by ATLONA to
avoid fire, shock or other hazards.
· Unplug the product before cleaning. Use a damp cloth for
cleaning. Do not use cleaning fluid or aerosols
· Never open or remove unit panels or make any
adjustments not described in this manual. Attempting to
do so could expose you to dangerous electrical shock or
other hazards. It may also cause damage to your
AT-HD30SR. Opening the product will void the warranty.
· Do not attempt to service the unit. Instead disconnect it
and contact your Authorized ATLONA reseller or contact
ATLONA directly
For additional help or trouble shooting with this product
please visit: www.atlona.com
Atlona
2151 O'toole Ave Unit D
San Jose, CA 95131
Tel: 408-954-8782
Fax: 408-954-8792
toll free: 1-877-536-3976
1
