Atlona AT-HDMI-210 Specifications

2x10 Atlona HDMI Switch/Splitter
Features:
• High Resolution up to 1080p.
• Splits 2 HDMI sources up to 10 outputs without signal loss.
• Separate Digital Audio Switching (via Toslink)
• HDCP Compliant
• Can be cascaded for more outputs
• Each of the buffered outputs can run up to 60ft @ 1080p
• Built-in EDID simulator and HDCP keyset allows each output to work independently
when connected to a HDMI display.
• Supports a wide range of PC and HDTV resolutions from VGA to UXGA and 480p to 1080p.
Maximum resolution bandwidth is 165MHz.
• Provides multi-channel I2S digital audio output, with sampling rate up to 192KHz.
• Support both compressed and uncompressed multi-channel audio.
• Remote control
• RS232 Port (for integration with home automation, security, and control systems)
Technical Specifications:
• Bandwidth: 1.65Gbps
• Resolutions: up to 1080p
• RS232 port: 9-pin
• Outputs Type: Mirrored
• Power Supply: 5V (universal 110/220v)
• Dimensions: 17.17(W) x 4.5(D) x 1.73(H) - (inch)
• Weight: 6LB
Atlona
2151 O'toole Ave Unit D
San Jose, CA 95131
Tel: 408-954-8782
Fax: 408-954-8792
toll free: 1-877-536-3976
Compatible with:
www.AtlonA.com
Weight 6.00 lbs
SKU# AT-HDMI-210
Rear View
IPackage Includes:
• One AT-HDMI-210
• One Power Supply
• One IR Remote Control
• One User manual
Inputs/Outputs:
• Inputs: 2 x HDMI, 2 x Optical
• Outputs: 10 x HDMI, 2 x Optical
Warranty:
3 year manufacture warranty (parts and labor)
AdoPtEr
