Intelix DIGI-HDMI-4X4 Installation Manual
6
Product
DIGI-HDMI-HR-R
DIGI-HDMI-IR-R
6. Connect the included 5 VDC power supply to the DIGI-HDMI-4X4.
7. If controlling remotely, connect RS232, Ethernet, or IR control cables.
8. Power-on the DIGI-HDMI-4X4.
9. Power-on the source and destination audio and video devices.
www.intelix.com
1080i Max Distance
1080p Max Distance
150 feet
150 feet
IR
60 feet
No
100 feet
Yes
