- Page 1 MODEL: Quattro Product id:QUATTRO13FH Quattro OWNER’S MANUAL...
-
Page 2: Table Of Contents
Introduction We thank you for purchasing our amplifiers. Your decision to be part of something different is what we strive for. Our products reflects who we are, going to the extent to deliver you our finest comes natural. Our amplifiers are engineered to accomondate a variety of applications. Whether it is SPL or SQ, the sound provided will be clean &... -
Page 3: Design Features
300 W x 2 Description of Specifications Stable impedance load of the Quattro is 2 Ohm stereo & 4 Ohm bridged. Operation below minimum impedance will stress the amplifier & void the warranty. Excessive heat will also appear at a faster rate and the and the amplifier will go into thermal protection. -
Page 4: Panel Layout
Panel layout Quattro SWEET LIKE DANISH FULL TLA 0.2V 0.2V CH1/2 REMOTE (CH 3 + 4) FRONT REAR RCA signal input for CH 1 & 2. RCA signal input for CH 3 & 4. GAIN GAIN Adjusts signal input voltage from the source Adjusts signal input voltage from the source to match the amplifiers input stage. -
Page 5: Panel Layout
Panel layout Head unit Quattro GROUND BATTERY SPEAKER OUTPUT FUSES Connection to the speakers leads. The amplifier is fused with 3 x 25A. Ensure polarity & corresponding channels are correct. Remember fusing has to be done at NB! Note the minimum bridged load. -
Page 6: Installation
Connect the power cables to the power terminal labeled as +12V. The Quattro is equipped with fuses, but the power cable still has to be fused at the battery. Connect one end of the fuse holder to the power cable and the other end of the fuse holder to the positive battery terminal within 20 cm / 8’’... -
Page 7: Wiring Layout
Wiring layout Quattro SWEET LIKE DANISH FULL TLA 0.2V 0.2V CH1/2 REMOTE (CH 3 + 4) Remote control (optional) Head unit Speaker connection 4 ch stereo Speaker impedance 2 ~ 8 Ohm... -
Page 8: Speaker Connection
Speaker connection 2 ch stereo + 1 ch mono Speaker impedance 2 ~ 8 Ohm Speaker impedance 4 ~ 8 Ohm Speaker connection Speaker impedance 4 ~ 8 Ohm 2 ch bridged Speaker impedance 4 ~ 8 Ohm... - Page 9 Wiring layout Active Mode (tla) SWEET LIKE DANISH FULL TLA 0.2V 0.2V CH1/2 REMOTE (CH 3 + 4) ACTIVE MODE (TLA) CH1 & CH2 RCA input only. CH3 & CH4 RCA Low Pass signal routed from CH1 & CH2. Low Pass signal routed is dependant of HPF setting of CH1 & CH2. GAIN of CH1 &...
-
Page 10: Troubleshooting
Troubleshooting The protection circuits of the amplifier prevents severe damages from faulty conditions & improper use. The protection indicatior will switch on due to short circuit connection & speaker overload, thus the amplifier will be turned off. Prior to inspecting the occurred problem, turn all levels down & all power off, then carefully check the installation for wiring mistakes, shorts or faulty ground (GND). - Page 11 Items not installed by authorized dealers will be warrantied for 30 days from the original purchase. Original sales receips must be accompanied with all returns.The warranty applies to the original purchaser of the product & it being sold by authorized B2 audio dealers.
