Installing a Processor (Part 2)
FIGURE 4-19

▼ To Install an XOption Processor

To install an XOption processor.
1. Prepare the server for service.
a. Power off the server.
b. Disconnect the power cord (or cords) from the power supply (or supplies).
c. Slide the server out of the rack.
d. Attach an antistatic wrist strap.
e. Remove the top cover.
2. Remove the shipping cover from socket.
3. Clean the top of the processor with the provided alcohol wipe.
See Section 2.4, "Powering Off the Server" on page
See Section 2.4, "Powering Off the Server" on page
See Section 2.5, "Extending the Server to the Maintenance Position" on
page 2-5.
See Section 2.7, "Performing Electrostatic Discharge and Antistatic Prevention
Measures" on page 2-8.
See Section 2.8, "Removing the Top Cover" on page
2-3.
2-3.
2-10.
Chapter 4 Servicing Motherboard Components 4-33
