Operating Your Fan - HAMPTON BAY Springview Owner's Manual

Mounting plate
Screws
Light Kit
Figure 19
Switch housing
Metal Nut
Glass shade
Figure 20
9

Operating your fan

NOTE
WAIT FOR FAN TO STOP BEFORE CHANGING
THE SETTING OF THE SLIDE SWITCH.
Turn on the power and check the operation of
Mounting ring
your fan. There are three pull chains
Screws
available in your fan:
Connection Plugs
1. 3-speed Pull chain-it controls the fan
Reverse switch
spe e d as follows: 1 pull- High, 2 pulls-
Medium, 3 pulls- Low, and 4
Off.
Speed settings for warm or cool weather
depend on factors such as the room size,
ceiling height, number of fans, and so on.
2. Light kit pull chain-it controls the light kit
in "ON" or "OFF".
The slide switch controls directions: forward
(switch left ) or reverse (switch right ).
Wa r m w e a t h e r - ( C o u n t e r - C l o c k w i s e
direction) A downward air flow creates a
cooling effect.(Fig. 21) This allows you to
set your air conditioner on a higher setting
Rubber Washer
without affecting your comfort.
Metal Washer
Metal Cap
Finial
Cool weather - (Clockwise direction) An
upward airflow moves warm air off the
ceiling area. (Fig. 22) This allows you to set
your heating unit on a lower setting without
affecting your comfort.
pulls-
Figure 21
Figure 22
