Care of Your Fan Troubleshooting
Here are some suggestions to help you
maintain your fan.
Because of the fan's natural movement, some
1.
connections may become loose. Check the
support connections, brackets, and blade
attachments twice a year. Make sure they are
secure. (It is not necessary to remove fan from
ceiling.)
Clean your fan periodically to help maintain
2.
its new appearance over the years. Do not use
water when cleaning. Use only a soft brush or
lint-free cloth to avoid scratching the finish.
The plating is sealed with a lacquer to
minimize discoloration or tarnishing. Do not
use water when cleaning. This could damage
the motor, or the wood, or possibly cause an
electrical shock.
You can apply a light coat of furniture polish
3.
to the wood blades for additional protection
and enhanced beauty. Cover small scratches
with a light application of shoe polish.
4. There is no need to oil your fan. The motor has
permanently lubricated sealed ball
bearings.1.2.3.4.
For any additional information on your
Hampton Bay Ceiling Fan, please write to:
THE HAMPTON BAY FAN & LIGHTING CO.
P. O. Box 395
Norco, CA 92860
CALL TOLL FREE 1-800-527-0998
PROBLEM SOLUTION
Check main and branch circuit fuses or breakers.
Fan will not start 1.
Check line wire connections to the fan and switch wire
2.
connections in the switch housing.
3. Check to make sure the dip switches from the transmitter and
receiver are set to the same frequency.
Make sure all motor housing screws are snug.
1.
Fan sounds noisy
Make sure the screws that attach the fan blade bracket to the
2.
motor hub is tight.
Make sure wire nut connections are not rattling against each
3.
other or the interior wall of the switch housing.
Allow a 24-hour "breaking-in" period. Most noises associated
4.
with a new fan disappear during this time.
5.
If using ceiling fan light kit, make sure the screws securing the
glassware are tight. Check that the light bulb is also secure.
6.
Make sure there is a short distance from the ceiling to the
canopy. It should not touch the ceiling.
7.
Make sure your ceiling box is secure and rubber isolator pads
are used between mounting bracket and outlet box.
Lights shut off and 1. This unit is equipped with a wattage limiting device. Lamping
will not come back in excess of 190 watts will disable your ceiling fan's light kit. To
on.
reset your light kit you must turn the power off and relamp,
keeping the wattage under 190 watts. Restore power to your
ceiling fan and continue normal operation.
1.
Do not connect the fan with a wall mounted variable speed
Remote control
control(s).
2.
Make sure the dip switches are set correctly.
WARNING
MAKE SURE THE POWER IS OFF AT THE ELECTRICAL PANEL BOX
BEFORE YOU ATTEMPY ANY REPAIRS. REFER TO THE SECTION,
"MAKING ELECTRICAL CONNECTIONS".
10
