Icom IC-F4001 Service Manual page 24

SECTION 7.
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6910021491 ANT CONNECTOR 106-1
SP1 2510001560 045P01202-02
W1 8900009640 OPC-963
EP1 0910065992 B-7262B
MP1 8010021710 3285 CHASSIS
MP2 8210026010 3285 FRONT PANEL (Incl. MP3–9)
MP3 8210025830 3285 PTT PANEL
MP4 8930080110 3285 PTT BUTTON
MP5 8930080130 3285 PTT RUBBER
MP6 8930079890 3285 LOCK PLATE
MP7 8210025800 3285 BOTTOM PANEL
MP8 8930080380 3285 SHAFT
MP9 8930080180 SP NET (F)
MP10 8930080170 3285 NAME SHEET
MP11 8930080120 3285 LENS
MP12 8930080620 O-RING (CF)
MP13 8930080630 3285 SP PLATE
MP14 8930042350 1922 MIC SHEET
MP15 8930080410 3285 MIC SPONGE
MP16 8930079900 3285 TERMINAL HOLDER
MP17 8930080100 3285 PLUS TERMINAL
MP18 8930080400 3285 MINUS TERMINAL
MP19 8930069710 THERMALLY SHEET (BC)
MP20 8830003390 VR NUT (AB)
MP21 8930080090 3285 SIDE PLATE
MP22 8930080150 3285 SIDE SEAL
MP23 8930080140 3285 TOP SEAL
MP24 8830003440 3285 ANT NUT
MP25 8610014180 KNOB N-389 (Incl. MP26)
MP26 8610007510 KNOB SPRING NO.7800
MP27 8610014190 KNOB N-390
MP28 8610007920 KNOB SPRING NO.1500
MP31 8810008761 SCREW BT B0 2X8 NI-ZC3 (BT)
MP32 8810009511 SCREW BT B0 2X4 NI-ZC3 (BT)
MP33 8810009511 SCREW BT B0 2X4 NI-ZC3 (BT)
MP34 8810009181 0TAP 1FLAT WASHER B0 2X5 NI-ZC3 (BT)
[MAIN-A UNIT]
REF ORDER
NO. NO.
J51 6450000131 HSJ1102-018540
J52 6450002250 HSJ1456-010320
J53* 6510021901 BM02B-ASRS-TF (LF) (SN)
MC51 7700002920 EM9745P-38-G-01
S51 2260001900 SW-149 (SKHLLD)
S52* 2260002800 SW-167 (SKQT)
S53* 2260002800 SW-167 (SKQT)
S54 2250000670 TP70TF5169-15.9F-3285
MP2 8510016461 2775 VCO COVER-1
MP3* 8510016471 2775 VCO CASE-1
MP4* 6910014760 OG-503040
MP5* 6910014760 OG-503040
MP6 8930080760 SPONGE (KT)
MP7 8930080770 INSULATION SHEET (MQ)
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[ACCESSORIES]
REF ORDER
QTY.
NO. NO.
1 EP1 (Optional) FA-SC57U-1
EP2 (Optional) BP-264 EXP
1
1
1 (Optional) BP-265
1
EP3 (Optional) BC-191 EXP
1
1
1 (Optional) BC-192 EXP
1
(Optional) BC-193 EXP
1
1
1
1 EP4 (Optional) BC-123SA (L)
1
1 (Optional) BC-147SA
1 (Optional) BC-123SE (L)
1
(Optional) BC-123SV (L)
1
1 (Optional) BC-147SV
1
1 MP1 (Optional) MB-124
1 MP2 8210025840 3285 JACK PANEL
1 MP3 8810004861 SCREW PH M2X6 ZK3
2
1
1
1
EP2
1
1
1
1
1
2
9
1
2
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
7 - 1
DESCRIPTION
[USA-11], [USA-12], [EUR-21], [EUR-22], [UK-01],
[UK-02], [EXP-11], [EXP-12], [EXP-21], [EXP-22],
[EXP-01], [AUS-21], [AUS-22], [RUS-21], [RUS-22]
[USA-13], [EUR-23], [UK-03], [EXP-13],
[EXP-23], [EXP-03], [AUS-23], [RUS-23]
[USA-11], [EUR-21], [UK-01], [EXP-11],
[EXP-21], [AUS-21], [RUS-21]
[USA-12], [EUR-22], [UK-02], [EXP-12],
[EXP-22], [AUS-22], [RUS-22]
[USA-13], [EUR-23], [UK-03], [EXP-13],
[EXP-23], [AUS-23], [RUS-23]
[USA-11], [USA-13], [EUR-22],
[EXP-11], [EXP-13], [EXP-22], [RUS-22]
[USA-12], [EXP-12]
[EUR-21], [EUR-23], [EXP-21],
[EXP-23], [RUS-21], [RUS-23]
[AUS-21], [AUS-23],
EP1
EP3
MP1
MP2
QTY.
1
1
1
1
1
1
1
1
1
1
[AUS-22] 1
1
1
2
EP4
MP3
