Summary of Contents for Kleenmaid ICK60X
-
Page 1: Instructions For Use
Instructions for Use Warranty Details ICK60X - 600mm Induction Cooktop ICK80X - 800mm Induction Cooktop REF CONSTRUCTEUR 214 9962 9201 05/03... - Page 2 99629201_GB_A.qxd 27/05/03 08:41 Page 2 ongratulations on the purchase of your new appliance. This appliance has been designed and manufactured to give you years of reliable performance. For best results, carefully read the instructions on how to install your new appliance. Correct installation will avoid delays and unnecessary service calls.
-
Page 4: Table Of Contents
99629201_GB_A.qxd 27/05/03 08:42 Page 3 List of contents Using your hob in complete safety.......4 Installing your hob in complete safety......6 Containers..............8 Using your hob in all simplicity........9 Preserving and maintaining your hob......11 Minor troubleshooting..........12 Cooking..............13-14 In this Manual, displays safety instructions, displays tips and hints We have designed this hob for domestic use only. -
Page 5: Using Your Hob In Complete Safety
99629201_GB_A.qxd 27/05/03 08:42 Page 4 Using your hob in complete safety utomatic-Stop HOB safety Automatic-stop is a safety function for your hob. It A sensor continuously monitors the • starts up automatically if ever you forget to turn off temperature of the components of your hob. after cooking : The power output by the hob will automatically be reduced if this temperature becomes... - Page 6 99629201_GB_A.qxd 27/05/03 08:42 Page 5 Using your hob in complete safety he principles of induction Induced currents When your induction hob is switched on and a heating power has been selected, the electronic circuits produce induced currents that instantaneously heat the bottom of the pan that transfers this heat to the food.
-
Page 7: Installing Your Hob In Complete Safety
99629201_GB_A.qxd 27/05/03 08:42 Page 6 Installing your hob in complete safety Always ensure that the air vents beneath the hob are kept clear. Your induction hob must always be adequately ventilated. Above a cupboard or drawer unit Above an oven 40mm minimum Induction Hob Bench Top... - Page 8 CEI 60083 or an all-pole cut-out unit with contacts that open by at least 3mm. If the cable is damaged, it must be replaced by an authorised Kleenmaid Service Agent or similarly qualified person for avoiding any possible risk of accident.
-
Page 9: Containers
99629201_GB_A.qxd 27/05/03 08:42 Page 8 Containers • aluminium pans with special base. You probably already have some suitable pans. pans which do not have a flat base may be Your induction hob is able to recognise suitable, however they must not be deformed most types of pans. -
Page 10: Using Your Hob In All Simplicity
99629201_GB_A.qxd 27/05/03 08:42 Page 9 Using your hob in all simplicity Ø 18 cm Ø 21 cm 50 W - 2800 W 50 W - 3000 W ICK 60 Ø 16 cm Ø 18 cm 50 W - 2000 W 50 W - 2800 W Ø... - Page 11 99629201_GB_A.qxd 27/05/03 08:42 Page 10 Using your hob in all simplicity tart/Stop A flashing 0 show that the zone concerned has been turned on. You can then choose the desired power. If you do not set the power, the cooking zone will turn itself off automatically.
-
Page 12: Preserving And Maintaining Your Hob
99629201_GB_A.qxd 27/05/03 08:42 Page 11 Preserving and maintaining your hob Avoid banging pots and pans down on the sible to use, are not included in the guaran- hob: tee conditions. The glass surface is very tough but not unbrea- kable Avoid rubbing with any abrasive cleaners Do not leave metal cooking utensils, or with base of pans etc. -
Page 13: Minor Troubleshooting
99629201_GB_A.qxd 27/05/03 08:42 Page 12 Minor troubleshooting You have doubts about whether your hob is working correctly ..this does not necessarily mean there is a breakdown. Nevertheless, check the following points IF YOU REALISE POSSIBLE WHAT SHOULD THAT CAUSES YOU DO? NOTHING: see chapter Remarks on... -
Page 14: Cooking
99629201_GB_A.qxd 27/05/03 08:43 Page 13 ICK 80 maximum power is reserved for frying and quick boiling. slow cooking boil with cover fast cooking add food boil or fry... -
Page 15: Cooking
99629201_GB_A.qxd 27/05/03 08:43 Page 14 ICK 60 maximum power is reserved for frying and quick boiling. slow cooking boil with cover fast cooking add food boil or fry... - Page 16 99629201_GB_A.qxd 27/05/03 08:43 Page 15...
-
Page 17: Warranty Registration
Kleenmaid appliance, we guarantee that any fault caused by faulty material or workmanship becoming apparent, will be rectified free of charge for parts and labour, provided that all service is performed during normal working hours by Kleenmaid or their designated Agents. - Page 18 Other products available in the Kleenmaid Range of appliances Washers Dryers Dishwashers Ovens Cooktops Outdoor Cooking Centres Built In Espresso Coffee Machines Rangehoods Freestanding Ranges Sinks Waste Disposals Taps Cookware Refrigerators Freezers Wine Cellars Vacuum Cleaners For sales information on the full range of quality appliances...
