3. Basic operations

3-12. SD memory cards

The unit's frame memory data and setup data can be stored on SD memory cards.
Conversely, this data can be loaded from the SD memory cards to the unit.
Frame memory data (still image data):
The unit supports 24-bit (uncompressed) BMP (bitmap) and JPEG (baseline) is the only file formats.
JPEG format files can be loaded, but they become BMP format files when they are stored from the unit to the
SD memory card.
This unit cannot resize the images so resize them appropriately using another device such as a personal
computer before saving them on the SD memory card.
<Applicable sizes>
HD/1080i: 19201080, HD/1080psf: 19201080, HD/720p: 1280720,
SD/NTSC: 720487, SD/PAL: 720576
BMP files:
If the sizes are different, the centre of the images will be lined up.
If the image is large, it will be cropped.
If the image is small, the area around it will be filled in with a black border.
JPEG files:
Images in the sizes listed in "Applicable sizes" above can be loaded.
The pixels of images in SD format are not square, so the aspect ratio will be different when the images are
displayed on the computer and when they are imported into frame memory (with NTSC format, they will be
vertically long).
To keep the images true to their actual proportions, make sure the original size is 720
images are in NTSC format, use images shrunk to 720
images enlarged to 720
Setup data:
The "setup data" refers to all the data stored in the unit with the exception of the date, time and network settings
and of the still image data. The extension used for the setup data files is "h45".
SD memory card handling precautions
 Do NOT eject the SD memory card while the SD memory card access LED is lit.
When an SD memory card is ejected while the SD memory card access LED is lit, the transition may be
temporarily suspended.
In addition, the data stored on the SD memory card may be lost.
 The data stored on SD memory cards may be lost as a result of misplacing the cards or performing erroneous
operations, for instance. It is recommended that valuable data be stored on a personal computer or other
device.

576 pixels.

487 pixels. If the images are in PAL format, use
92

540 pixels. If the
