2. Functions in each area
 LAN connector [LAN] (RJ-45) (10/100 Base-TX)
 For details on how to connect this connector, refer to "6. External interfaces".
 EDITOR connector [EDITOR] (RS-422, D-sub 9-pin, female, inch screw)
 COM connector [COM] (RS-422, D-sub 9-pin, female, inch screw)
 For details on how to connect this connector, refer to "6. External interfaces".
 TALLY/GPI input/output connector [TALLY/GPI] (D-sub 50-pin, female, inch screw)
 For details on how to connect this connector, refer to "6. External interfaces".
 Ground connector [SIGNAL GND]
Connect to the system's earth ground.
 AC power input socket [
Connect one end of the supplied power cable to this socket and the other end to the AC outlet.
The supplied power cable comes with a 3-pin power plug. Be absolutely sure to plug it into a 3-point power
outlet as the power source in order to earth the unit securely.
If a 3-point power outlet is not available for this connection, be absolutely sure to consult your dealer.
 Cooling fan
IN1] [ IN2] (AC 220 V to 240 V, 50/60 Hz)
