MONITOR UNIT
MU-190/231
English
Controls
MENU
DISP
PIP
MU-190
Opens/Closes the menu.
MENU
- Select the menu and
Light sensor
(Automatically detects
menu items.
the ambient brightness.)
- Adjust settings.
- Move the PIP window.
Operator's Guide
MU-231
- Power On/Off.
(Available when the slide switch at the bottom rear is OFF.)
Selects the signal to display.
- Displays the brilliance adjustment window.
PIP
DISP
Displays/Hides
the PIP window.
The purpose of this guide is to provide the
basic operation for this equipment. For more
detailed information, see the Operator's
Manual.
All brand and product names are trademarks,
registered trademarks or service marks of their
respective holders.
Power LED
(Lights when power is on.)
(Green): The signal is input.
(Red): No signal.
