Tub Cover

Note: The tub cover can be replaced without
removing the tub.
To remove the tub cover:
1. Remove the front panel. (See
2. Remove the cover/lid assembly. (See
)
Assembly.
3. Disconnect 4 dampening straps from the tub
cover by removing four 5/16" hex-head screws.
Tub Cover
4. Release the cover from the outer tub by lifting
the 8 tabs.
5. Raise the front of the cover to clear the front
cabinet brace and tilt the tub forward.
6. Carefully lift and remove the cover from the tub.
Tab (1 of 8)
Note: The motor can be replaced without removing
the tub. (See
be removed when replacing the spin basket, outer
tub, or certain speed drive components.
Front Panel. )
To remove the tub assembly:
Cover/Lid
1.
2.
3.
4.
5.
6.
7.
8.
Note: When replacing air bell, tighten the 7/16" hex-
head bolt to 90 in. lbs. of torque.
– 23 –

Tub Assembly

Inverter/Motor.
Disconnect power.
Lower the drain hose into a small bucket to
remove any water remaining in the tub.
Remove the front panel. (See
Remove the cover/lid assembly. (See
)
Assembly.
Remove the tub cover. (See
Remove the agitator. (See
Remove the 7/16" hex-head bolt and air bell
coupling from the agitator shaft.
Remove the air bell.
) The tub assembly must
)
Front Panel.
Cover/Lid
.)
Tub Cover
.)
Agitator
(Continued next page)
