Congratulations!
Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fi replaces.
The SimpliFire electric fi replace you have selected is designed to provide the utmost in safety, reliability, and effi ciency.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fi re, electrical shock, or personal injury, read all instructions
before using appliance.
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Please contact your SimpliFire dealer or customer/technical support
(877-320-0730) with any questions or concerns.
For the location of your nearest SimpliFire dealer,
please visit www.hearthnhome.com.
Printed in China - Copyright 2014
SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14
NOTICE
• Leave this manual with
party responsible for use
and operation.
Owner's Manual
Installation and Operation
1
Advertisement
Table of Contents
Related Manuals for SimpliFire SF-WM58-WH
Summary of Contents for SimpliFire SF-WM58-WH
- Page 1 Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood & gas burning fi replaces. The SimpliFire electric fi replace you have selected is designed to provide the utmost in safety, reliability, and effi ciency. READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN THIS PRODUCT.
-
Page 2: Important Instructions
Return appliance to authorized service facility for examination, electrical or mechanical adjustment or repair. • Do not use outdoors. SAVE THESE INSTRUCTIONS SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 3: Table Of Contents
D. Service Parts List ....... 16 SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 4: Warranty
Fire fireplace within one year following the date of original purchase, that the SimpliFire fireplace will be free from defects in materials and workmanship at the time of manufacture. If a SimpliFire fireplace is found to be defective in materials or workmanship during the applicable warranty period, HHT will, at its option, repair or replace the SimpliFire fireplace. -
Page 5: General Information
We recommend that you record the following pertinent information about your fi replace. Model Name: ___________________________________________ Date purchased/installed: __________________ Serial Number: __________________________________________ Location on fi replace: _____________________ Dealership purchased from: _______________________________ Dealer Phone: __________________________ Notes: _______________________________________________________________________________________ SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 6: Getting Started
Note: Side view dimensions include mounting bracket. 6 in 58 1/4 in. - SF-WM58 70 1/4 in. - SF-WM70 6 1/4 in. 93 11/16 in. - SF-WM94 Side View Front View Figure 3.1 Appliance Dimensions SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 7: Location
Figure 3.3 Electrical Outlet Locaton from the front of the electric fi replace, and away from the sides or rear. CEILING 350 mm 13-3/4 in. FLOOR Figure 3.2 Clearance to Combustibles SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 8: Installation
Note: For non-masonry walls, at least two mounting points (screws 5x40) must align with a structural framing member. 16 in. 16 in. Figure 4.2 Mounting Bracket Figure 4.1 SF-WM58 Mounting Bracket SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 9: Installing Wall Mount Bracket
WARNING! Risk of Damage or Personal Injury! Al- lowable pull-out and shear strength are 25% of ultimate values or less, as required by building authorities. SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... - Page 10 Note: For non-masonry walls, at least two mounting points (screws 5x40) must align with Masonry Anchors structural framing member. Figure 4.7 (SF-WM58) Masonry Anchor Placement Figure 4.10 (SF-WM58) Bracket Attachment SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14...
-
Page 11: Appliance Installation
Place clear stones over LED bulbs and fi ll remaining gaps with white stones. Note: Extra stones are provided and may be distributed based on consumer preference. Not all stones need to be used. SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 12: Glass Front Installation
Ensure the power cord is not installed so that it is pinched or against a sharp edge and ensure that the power cord is stored or secure to avoid tripping and snagging. Figure 4.14 Attaching Front to Appliance SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 13: Operating Instructions
Note: To use both remote and manual function, the main power switch must in “ON” position. FLAME BUTTON HEATER BUTTON MANUAL ON/OFF MAIN POWER SWITCH Figure 5.1 Manual Operating Switches SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 14: Operating By Remote Control
Pressing the Light button changes the glass fascia LIGHT No indicator. backlight colors (14 colors available), and turns it on/off. SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 15: Maintenance
WARNING! Risk of Electrical Shock! Any other servic- ing needed must be performed by an authorized service representative. Do not attempt to service the unit your- self. SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 16: Service Parts List
Rock Kit, Contains both White and Clear Rock ROCKS-WM58/36 Hardware Bag HRDW-WM Includes: Masonry Anchors, Screw (ST5 x 40), Bolt (M4 x 8), Bolt (M5 x 10), 3/16 Toggle anchor 2040-903 Installation Manual 1/14 SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... -
Page 17: Service Parts
Rock Kit, Contains both White and Clear Rock ROCKS-WM70/94 HRDW-WM70/94 Hardware Bag Includes: Masonry Anchors, Screw (ST5 x 40), Bolt (M4 x 8), Bolt (M5 x 10), 3/16 Toggle anchor Installation Manual 2040-903 1/14 SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14... - Page 18 Rock Kit, Contains both White and Clear Rock Hardware Bag HRDW-WM70/94 Includes: Masonry Anchors, Screw (ST5 x 40), Bolt (M4 x 8), Bolt (M5 x 10), 3/16 Toggle anchor 2040-903 Installation Manual 1/14 SimpliFire • SF-WM58, SF-WM70, SF-WM94 • 2040-903 Rev. G • 1/14...
