Model(s):
SF-WM36-WH
SF-WM36-BK
• Important operating
a n d m a i n t e n a n c e
instructions included.
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions
before using heater.
INSTALLER: DO NOT DISCARD THIS MANUAL -
LEAVE FOR HOMEOWNER - SAVE THESE INSTRUCTIONS
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
1
Advertisement
Table of Contents
Related Manuals for SimpliFire SF-WM36-WH
Summary of Contents for SimpliFire SF-WM36-WH
- Page 1 WARNING: To reduce risk of fire, electrical shock, or personal injury, read all instructions before using heater. INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER - SAVE THESE INSTRUCTIONS SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13...
-
Page 2: Important Instructions
No. • Do not use outdoors. 14 AWG minimum size and rated to not less than 1875 watts. SAVE THESE INSTRUCTIONS SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 3: Congratulations
Your new SimpliFire electric fireplace will give you years of durable use and trouble-free enjoyment. Welcome to the As the owner of a new fireplace, you’ll want to read and... -
Page 4: Table Of Contents
E. Contact Information ......17 SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 5: Limited Lifetime Warranty
Consider- ation must be given to appliance location and configuration, environmental conditions, insulation and air tightness of the structure. SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... - Page 6 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13...
-
Page 7: General Information
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 8: Getting Started
Bolt Anchor Anchor 5 x 10 4 x 8 C. Appliance Note: Side view dimensions include mounting bracket. 36-1/4 in 5-5/8 in 6 in. Front View Side View Figure 3.1 Appliance Dimensions SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 9: Location
3 ft. (0.9 m) from the front of the electric fireplace, and away from the sides or rear. 200mm CEILING 8 in. 200mm 8 in. 200mm 8 in. 350mm 13-3/4 in. FLOOR Figure 3.2 Clearance to Combustibles SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 10: Installation
Wall Masonry Anchors Figure 4.2 Masonry Anchor Placement WARNING! Risk of Damage or Personal Injury! Do not use supplied masonry anchors on hollow walls, sheathed with wood, sheetrock, drywall or other materi- Figure 4.1 Mounting Bracket als. Mounting Hooks Point Up Figure 4.3 Bracket Attachment SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 11: Appliance Installation
WARNING! Risk of Damage or Personal Injury! Al- lowable pull-out and shear strength are 25% of ultimate values or less, as required by building authorities. Secure with screw on each side of appliance. Figure 4.7 Attaching Fireplace to Bracket Figure 4.5 Toggle Bolt Installation through Mounting Bracket SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 12: Faux Stone Installation
WARNING! Risk of Fire! Do not plug in or operate this product with hot air vents touching the ground. Always hang on wall with supplied bracket before use. Figure 4.5 Attaching Fireplace to Bracket WARNING! Risk of Fire, Electrical Shock, and Injury. Ensure the power cord is not installed so that it is pinched or against a sharp edge and ensure that the power cord is stored or secure to avoid tripping and snagging. SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 13: Operating Instructions
Note: To use both remote and manual function, the main power switch must in “ON” position. FLAME BUTTON HEATER BUTTON THERMAL CONTROL KNOB MANUAL ON/OFF MAIN POWER SWITCH Figure 5.1 Manual Operating Switches SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 14: Operating By Remote Control
Pressing the button turns the firebox backlight through three BACKLIGHT lighting effects. Press once to turn heater on low. Press again to turn heater off. Press once to turn heater on high. Press again to turn HIGH heater off. SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 15: Maintenance
WARNING! Risk of Fire! To reduce risk of fire, do not any other servicing. store or use gasoline or any other flammable vapors or liquids in the vicinity of the heater. WARNING! Risk of Electrical Shock! Any other servic- ing needed must be performed by an authorized service representative. Do not attempt to service the unit your- self. SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 16: Service Parts
Rock Kit, Contains both White and Clear Rock Hardware Bag HRDW-WM Includes: Masonry Anchors, Screw (ST5 x 40), Bolt (M4 x 8), Bolt (M5 x 10), 3/16 Toggle anchor 2040-902 Installation Manual 2/13 SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 17: Replacement Instructions
Figure 6.1 Power Input Cord and Strain Relief Bracket on 6. Install new cord on appliance and installed metal Lower Right of Appliance strain relief bracket with one screw. See Figure 6.1. 7. Plug cord into wall receptacle. SimpliFire • SF-WM36 • 2040-902 Rev. C • 2/13... -
Page 18: Contact Information
SimpliFire, a brand of Hearth & Home Technologies 7571 215 Street West, Lakeville, MN 55044 www.hearthnhome.com Please contact your SimpliFire dealer with any questions or concerns. For the location of your nearest SimpliFire dealer, please visit www.hearthnhome.com. - NOTES -...
