GREENSTAR CAMRAY KITCHEN
12/18, 18/25, 25/32
FLOOR STANDING OIL FIRED CONDENSING BOILER
CONVENTIONAL FLUE & ROOM SEALED FLUE
FOR FULLY PUMPED OPEN VENT OR SEALED CENTRAL HEATING SYSTEMS AND DOMESTIC
HOT WATER CYLINDERS
THE APPLIANCE IS FOR USE WITH 28 SECOND KEROSENE
ONLY
INSTRUCTION MANUAL
INSTALLATION COMMISSIONING
& SERVICING
GB

Advertisement

Table of Contents
loading

Related Manuals for Worcester GREENSTAR CAMRAY KITCHEN 12/18

Summary of Contents for Worcester GREENSTAR CAMRAY KITCHEN 12/18

  • Page 1 GREENSTAR CAMRAY KITCHEN 12/18, 18/25, 25/32 FLOOR STANDING OIL FIRED CONDENSING BOILER CONVENTIONAL FLUE & ROOM SEALED FLUE FOR FULLY PUMPED OPEN VENT OR SEALED CENTRAL HEATING SYSTEMS AND DOMESTIC HOT WATER CYLINDERS THE APPLIANCE IS FOR USE WITH 28 SECOND KEROSENE...
  • Page 2 LABC will then arrange regular inspection visits during the work to ensure that the installation Cold water main supply complies with the regulations. IF YOU ARE IN ANY DOUBT CONTACT THE WORCESTER TECHNICAL HELPLINE. DISTANCE LEARNING AND TRAINING COURSES ARE AVAILABLE FROM WORCESTER. Electricity supply...

  • Page 3: Table Of Contents

    FAULT FINDING & DIAGNOSIS FAULT FINDING 47-48 FAULT FINDING LOGIC FOR 535 SE/LD RDB CONTROL BOX COMBUSTION RECORD SERVICE INTERVAL RECORD BAFFLE ARRANGEMENT DIAGRAM BACK PAGE INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 CONTENTS 8 716 113 000a (01/07)

  • Page 4: Installation Regulations

    The Control of Pollution (Oil) Regulations. OFTEC Standards. Where no specific instruction is given, reference should be made to the relevant codes of practice. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 SAFETY PRECAUTIONS 8 716 113 000a (01/07) & INSTALLATION REGULATIONS...

  • Page 5: General Information

    Greenstar Camray Kitchen Installation/Servicing Instructions....1 Users Instructions ..................1 Fascia Information Card.................1 Warranty Return Envelope ................1 Guarantee Registration Card................1 Condensate Trap Kit..................1 Return Pipe Kit....................1 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 GENERAL INFORMATION 8 716 113 000a (01/07)

  • Page 6: Technical Data

    Appliance protection rating (with programmer blanking plate fitted) Appliance protection rating (with fascia programmer fitted) Weight (excluding packaging) Emissions class for NOx and CO class INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 TECHNICAL DATA 8 716 113 000a (01/07)

  • Page 7: Layout & Components

    33 TEMPERATURE CONTROL KNOB 34 DEMAND INDICATOR OPTIONAL ACCESSORIES (not supplied) 7 day TWIN CHANNEL DIGITAL PROGRAMMER Part No. 7 716 192 033 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 LAYOUT & COMPONENTS 8 716 113 000a (01/07)

  • Page 8: Cleaning Primary Systems

    Run the boiler and system at normal operating temperature in accordance with the manufacturer's instructions. Drain and thoroughly flush the system to remove the flushing agent and any debris. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 CLEANING PRIMARY SYSTEMS 8 716 113 000a (01/07)

  • Page 9: Mains Supplies

    • Any system connected to the boiler must not have a separate electrical supply. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 MAINS SUPPLIES 8 716 113 000a (01/07)

  • Page 10: Oil Supply

    The table and illustration above is a guide only and does not in any way override the de- as the sole fire protection device. aerator manufacturers instructions. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 OIL SUPPLY 8 716 113 000a (01/07)

  • Page 11: Water Systems & Pipework

    1” / 1 ” BSP outlets. • An automatic air vent (N) must be fitted. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 WATER SYSTEMS & PIPEWORK 8 716 113 000a (01/07)
  • Page 12 Heating return Auto air vent Non return 1000mm above valve the highest point of the system Stop cock Fill Point INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 WATER SYSTEMS & PIPEWORK 8 716 113 000a (01/07)

  • Page 13: Condensate Pipework

    (as shown) to help prevent freezing. Outside wall. Drain pipe. External drain. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 CONDENSATE & 8 716 113 000a (01/07) PRESSURE RELIEF PIPEWORK...

  • Page 14: Boiler Location & Clearances

    25/32 275 25/32 275 * Remove the flue 'knock-out' panel sections if this clearance is less than 75mm. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 BOILER LOCATION & CLEARANCES 8 716 113 000a (01/07)

  • Page 15: Boiler Location & Clearances

    Any pipework in bathrooms and shower rooms must be cross bonded. 600mm radius A - Bath or shower cubicle (zone 0) INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 BOILER LOCATION & CLEARANCES 8 716 113 000a (01/07)

  • Page 16: Flue Terminal Positions

    • **Minimum distance of the flue terminal to a facing wall, fence, building or property boundary is 2500mm. boundary INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 FLUE TERMINAL POSITIONS 8 716 113 000a (01/07)

  • Page 17: Conventional Flue

    'Contact Information' on the back cover. A - Boiler B - Flue C - Max. 2 bends at 135° D - Anti down-draught terminal E - Chimney INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 CONVENTIONAL FLUE 8 716 113 000a (01/07)

  • Page 18: Room Sealed Flue Options

    12/18 & 18/25 125mm Ø 125mm Ø 25/32 150mm Ø** INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 ROOM SEALED FLUE OPTIONS 8 716 113 000a (01/07)

  • Page 19: Unpacking The Boiler

    At all times the correct method for handling heavy objects should be strictly observed. UNPACKING THE BOILER INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 8 716 113 000a (01/07)

  • Page 20: Pipework Positions & Flue Opening

    240 - 330mm 185mm Ø 755** 330 - 420mm 190mm Ø 420 - 500mm 195mm Ø Clear away any debris. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 PIPEWORK POSITIONS & 8 716 113 000a (01/07) FLUE OPENING...

  • Page 21: Boiler Installation

    Carefully move the boiler into position observing at all times the correct method for handling heavy objects. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 BOILER INSTALLATION 8 716 113 000a (01/07)

  • Page 22: Flue Installation

    52mm for each metre away from the boiler to ensure that condensate flows back into the boiler for safe discharge via the condensate waste pipe. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 FLUE INSTALLATION 8 716 113 000a (01/07)

  • Page 23: Combustion Chamber

    Plan sectional view Plan sectional view 25/32 IMPORTANT when refitting Plan sectional view the combustion chamber access door (6) Combustion chamber access door tightening sequence. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 COMBUSTION CHAMBER 8 716 113 000a (01/07)

  • Page 24: Pipework Connections

    (L). IMPORTANT: The condensate trap must be correctly filled to prevent the possibility of potentially harmful flue products escaping via the condensate pipework. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 PIPEWORK CONNETIONS 8 716 113 000a (01/07)

  • Page 25: Oil Burner And Pump

    (not supplied) to the oil pump and return pipe fixing (D on page 23) and tighten to secure. (on 12/18 model only) Brass air deflector washer Locating circlip INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 OIL BURNER & PUMP 8 716 113 000a (01/07)

  • Page 26: Refitting Components

    (G) in the bottom locations. Plug burner lead (H) into control box. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 REFITTING COMPONENTS 8 716 113 000a (01/07)

  • Page 27: Electrics

    (A). *Move the orange wire from terminal 9 to terminal 6 for a 3 port valve system. 7 8 9 10 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 ELECTRICS 8 716 113 000a (01/07)
  • Page 28 Brown Brown Brown Green/Yellow Black Blue Grey 1 2 3 4 5 6 1 2 3 4 5 6 Green/Yellow Black Grey Riello Burner INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 ELECTRICS 8 716 113 000a (01/07)
  • Page 29 Connect terminal 6 on the boiler terminal block (G) to the ‘HOT WATER OFF’ at the remote junction box (O). 1 2 3 4 5 6 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 ELECTRICS 8 716 113 000a (01/07)
  • Page 30 A frost thermostat can also be connected to the remote junction box if required. N1 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 ELECTRICS 8 716 113 000a (01/07)
  • Page 31 Connect the plug from programmer (P) into connector (F). N1 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 ELECTRICS 8 716 113 000a (01/07)

  • Page 32: Electrics

    Move the orange wire from terminal 9 to terminal 6. N1 1 2 3 4 5 6 7 8 9 10 Orange 1 2 3 4 5 6 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 ELECTRICS 8 716 113 000a (01/07)

  • Page 33: Pre-Commissioning Checks - Appliance

    Complete the installation part of the Guarantee Registration Card, and complete a CD10 or equivalent, to inform the LABC of the installation. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 PRE-COMMISSIONING CHECKS - 8 716 113 000a (01/07) APPLIANCE...

  • Page 34: Filling The System

    The (A) in use and (B) must be bled. Bleed air from the primary heat exchanger air vent (B). INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 FILLING THE SYSTEM 8 716 113 000a (01/07)

  • Page 35: Starting The Appliance

    The internal filter is accessed by removing the BEHIND BOILER FRONT PANEL, ON BURNER oil pump cover. Safely dispose of the container/discharge. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 STARTING THE APPLIANCE 8 716 113 000a (01/07)
  • Page 36 T2 L/H 25/32 adjust the air shutter setting (L) to obtain *25/32 model for 25kW see following page. the correct CO level. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 STARTING THE APPLIANCE 8 716 113 000a (01/07)
  • Page 37 Remove the two screws (C) securing the plastic air guide. Remove air guide (D) and reassemble the burner in reverse order. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 STARTING THE APPLIANCE 8 716 113 000a (01/07)

  • Page 38: Starting The Appliance

    The ‘demand’ indicator light (A), burner and circulating pump should be off. 3 Check that any other controls that are fitted to the system are operating properly. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 STARTING THE APPLIANCE 8 716 113 000a (01/07)

  • Page 39: Water Treatment

    . INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 WATER TREATMENT 8 716 113 000a (01/07)

  • Page 40: Finishing Commissioning - Appliance

    NOTE: Release drain point (H) to drain the secondary heat exchanger. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 FINISHING COMMISSIONING - 8 716 113 000a (01/07) APPLIANCE...

  • Page 41: Inspection And Service

    Clean or replace all oil filters. Check that the condensate system is not obstructed, clean and refill as necessary. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 INSPECTION AND SERVICE 8 716 113 000a (01/07)
  • Page 42 (on 12/18 model only) the room. Brass air deflection washer Locating circlip G - Retaining screws - cover H - Cover - oil pump INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 INSPECTION AND SERVICE 8 716 113 000a (01/07)
  • Page 43 A fire valve sensor clip (Q) is sequence. provided for this purpose. INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 INSPECTION AND SERVICE 8 716 113 000a (01/07)

  • Page 44: Inspection And Service

    (see page 36). 0.75 80°EH 2.37 12.0 28.3 27.5 T2 L/H 25/32 0.85 80°EH 2.58 3.27 12.5 30.8 30.0 T2 L/H 25/32 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 INSPECTION AND SERVICE 8 716 113 000a (01/07)

  • Page 45: Short Parts List 12/18

    Part Number: 8-716-112-954-0 18 Nozzle holder Part Number: 8-716-112-777-0 19 Circlip Part Number: 8-716-112-773-0 20 Brass air restrictor washer Part Number: 8-716-112-729-0 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 SHORT PARTS LIST 12/18 8 716 113 000a (01/07)

  • Page 46: Short Parts List 18/25

    15 Cleaning brush Part Number: 8-716-109-428-0 16 Manifold access cover seal Part Number: 8-716-107-536-0 17 Secondary Heat Exchanger gasket Part Number: 8-716-112-954-0 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 SHORT PARTS LIST 18/25 8 716 113 000a (01/07)

  • Page 47: Short Parts List 25/32

    14 Cleaning brush Part Number: 8-716-109-428-0 15 Manifold access cover seal Part Number: 8-716-107-536-0 16 Secondary Heat Exchanger gasket Part Number: 8-716-112-954-0 INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 SHORT PARTS LIST 25/32 8 716 113 000a (01/07)
  • Page 48 Set up as in installation instructions Oil pressure incorrect Adjust to correct pressure Incorrect components used on Check with installation instructions combustion head Faulty nozzle Replace nozzle INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 FAULT FINDING 8 716 113 000a (01/07)

  • Page 49: Fault Finding & Diagnosis

    Rectify burner operation and lockouts operation, numerous lockouts Odour in boiler room, oil leaks Rectify oil leaks, replace components if from pipework, flexible hoses necessary connections INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 FAULT FINDING 8 716 106 252b (07/06...

  • Page 50: Fault Finding Logic For 535 Se/Ld Rdb Control Box

    FAULT FINDING LOGIC FOR 535 SE/LD RDB CONTROL BOX INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32 FAULT FINDING 8 716 113 000a (01/07)

  • Page 51: Combustion Record

    Service Interval Record Overleaf. Service Provider. Before completing the appropriate Service Interval Record below, please ensure you have carried out the service as described in this manual. Always use Worcester, Bosch Group specified spare parts when replacing all controls.
  • Page 52 SERVICE 2 SERVICE 1 DATE DATE ENGINEER NAME ENGINEER NAME COMPANY NAME COMPANY NAME TEL No. TEL No. OFTEC REG No. OFTEC REG No. PUMP PRESSURE: PUMP PRESSURE: NOZZLE CHANGED? NOZZLE CHANGED? F.G.T. °C FLUE PRESSURE: F.G.T. °C FLUE PRESSURE: COMMENTS COMMENTS SIGNATURE...

  • Page 55: Baffle Arrangement Diagram

    18/25 fitted into tube 2. BAFFLE RETAINER Remove and fit through baffle access door. BAFFLE (2 for 12/18, 3 for 18/25 and 6 for 25/32) Lift baffle to remove the baffle retainer then pull down to remove the baffle through the combustion chamber.
  • Page 56 EXCELLENCE COMES AS STANDARD Worcester, Bosch Group Cotswold Way, Warndon, Worcester WR4 9SW. Tel. 01905 754624 Fax. 01905 754619 Worcester, Bosch Group is a brand name of BBT Thermotechnology UK Ltd. www.worcester-bosch.co.uk 8 716 113 000a (01/07)
  • Page 57 These must be fitted. 8 716 113 453a 02/07 SECONDARY HEAT EXCHANGER REPLACEMENT SEAL Worcester, Bosch Group. Cotswold Way, Warndon, Worcester WR4 9SW. Tel. 01905 754624 Fax. 01905 754619 Worcester, Bosch Group is a trading name of BBT Thermotechnology UK Ltd. www.worcester-bosch.co.uk...

  • Page 58: Greenstar Camray Kitchen

    FOR FULLY PUMPED OPEN VENT OR SEALED CENTRAL HEATING SYSTEMS AND DOMESTIC HOT WATER CYLINDERS For use with the following Greenstar oil fired appliances: Greenstar Camray Kitchen 12/18, 18/25, 25/32 THE APPLIANCE IS FOR USE WITH 28 SECOND KEROSENE ONLY USER INSTRUCTIONS &...
  • Page 59 Electronic Printed Circuit Board. SEDBUK Seasonal Efficiency for Domestic Boilers in the United Kingdom. OFTEC Oil Firing Technical Association for the Petroleum Industry. USER INSTRUCTIONS & GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 8 716 113 001a (01.07) CUSTOMER CARE GUIDE...
  • Page 60 Controlling central heating Fault conditions ENERGY SAVING TIPS ON ENERGY SAVING 10-11 MAINTENANCE MAINTAINING YOUR APPLIANCE FAULT FINDING FAULT OR BREAKDOWN GUARANTEE YOUR GUARANTEE GUARANTEE REGISTRATION GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 CONTENTS 8 716 113 001a (01.07)

  • Page 61: Safety Precautions

    The system is empty, frozen or unpressurised (sealed systems). The condensate pipe is blocked or restricted. The appliance clearances are inadequate. The air supply is restricted or vents damaged. SAFETY PRECAUTIONS GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 8 716 113 001a (01.07)

  • Page 62: Excellence Comes As Standard

    To find out more about Worcester, Bosch Group, use the 'Contact Information' shown on the inside front cover. GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 EXCELLENCE COMES AS STANDARD 8 716 113 001a (01.07)
  • Page 63 If the system loses pressure it should be repressurised and the cause of the loss investigated. GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 GENERAL INFORMATION 8 716 113 001a (01.07)

  • Page 64: General Information

    Model Area (cm into the area where the boiler is situated. 12/18 18/25 25/32 GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 GENERAL INFORMATION 8 716 113 001a (01.07)
  • Page 65 Level Level Level Level Model 12/18 18/25 25/32 Room Sealed flue: Internal ventilation External ventilation High High Level Level Level Level Model 12/18 18/25 25/32 GENERAL INFORMATION GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 8 716 113 001a (01.07)

  • Page 66: Controls

    Reset button - flue overheat thermostat (behind front panel). G Reset button - boiler overheat thermostat (behind front panel). H Holder for quick reference User Guide. Front panel. GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 CONTROLS 8 716 113 001a (01.07)

  • Page 67: Operating The Appliance

    ON/OFF periods. Turn the room thermostat to the temperature required. Set thermostatic radiator valves to the required temperature for each room. GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 OPERATING THE APPLIANCE 8 716 113 001a (01.07)

  • Page 68: Fault Conditions

    5. If the demand light stays off contact your ACCESSING RESET BUTTONS: service engineer for advice. PULL BOTTOM FRONT PANEL OUT AND LIFT TO REMOVE GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 OPERATING THE APPLIANCE 8 716 113 001a (01.07)

  • Page 69: Tips On Energy Saving

    Warning: do not block or seal any air vents that are installed to ensure the central heating boiler (or other appliance) operate safely. GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 TIPS ON ENERGY SAVING 8 716 113 001a (01.07)
  • Page 70 If you decide to turn off radiators in unused rooms, spare bedrooms etc., you may experience slightly lower room temperatures in rooms adjacent to unheated rooms. GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 TIPS ON ENERGY SAVING 8 716 113 001a (01.07)

  • Page 71: Maintaining Your Appliance

    Regularly check the oil level in the tank. Regularly check the system pressure, ask your installer for guidance. Do not obstruct the flue outlet or the air inlet. GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 MAINTAINING YOUR APPLIANCE 8 716 113 001a (01.07)

  • Page 72: Fault Finding

    Hot water not in timed Check programmer period on the programmer settings Temperature control on Check setting boiler set too low GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 FAULT FINDING 8 716 113 001a (01.07)

  • Page 73: Fault Or Breakdown

    Your service administrator will arrange for an Engineer to call with the minimum of delay. Under normal circumstances this will be GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 FAULT OR BREAKDOWN 8 716 113 001a (01.07)

  • Page 74: Your Guarantee

    Great Britain. This guarantee is given in addition to all your normal statutory rights. Worcester, Bosch Group is a trading name of BBT Thermotechnology UK Ltd. YOUR GUARANTEE GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 8 716 113 001a (01.07)

  • Page 75: Guarantee Registration

    This does not affect your statutory rights. For your own record: Model Serial No. (See identity label inside appliance casing) Type / size Date of installation GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 GUARANTEE REGISTRATION 8 716 113 001a (01.07)
  • Page 76 NOTES NOTES GREENSTAR CAMRAY KITCHEN 12/18 - 18/25 - 25/32 8 716 113 001a (01.07))

  • Page 77: User Instructions

    CUSTOMER CARE GUIDE EXCELLENCE COMES AS STANDARD Worcester, Bosch Group Cotswold Way, Warndon, Worcester WR4 9SW. Tel. 01905 754624 Fax. 01905 754619 www.worcester-bosch.co.uk Worcester, Bosch Group is a brand name of BBT Thermotechnology UK Ltd. 8 716 113 001a (01.07)
