- Page 1 FABRICANTES DE BÁSCULAS TORREY S.A. DE C.V. LABEL PRINTING SCALE LSQ Series USER MANUAL REVISION 1.0 IMPORTANT: BEFORE OPERATING THIS SCALE PLEASE READ THIS MANUAL THOROUGHLY.
-
Page 2: Table Of Contents
INDEX PÁG. INTRODUCTION IMPORTANT CAUTIONS INSTALLATION SMART CARTRIDGE CHANGING THE PAPER ROLL CHANGINGTHE LABELS ROLL CHANGING THE CO TINUOUS LABEL ROLL IMPORTANT PARTS OPERATION KEYPAD EXAMPLES OF LABEL PRINTING FORMATS EXAMPLES OF PAPER PRINTING FORMATS GENERAL OPERATION DESCRIPTION WEIGHING A PRODUCT TARING A CONTAINER REFERENCING TO ZERO WEIGHT INTRODUCING NON-PLU PRODUCTS PRICES... -
Page 3: Introduction
Next we mention the several advantages you get when you buy a TOR-REY LSQ SERIES scale: Guaranteed accuracy due to the scale does not have any mechanical parts that suffer damage. -
Page 4: Installation
INSTALLATION 1.- Unpack the scale and check for any missing piece (see page 7 “Important parts” ), or any mistreated or striped piece. Your scale must include the following: QUANTITY DESCRIPTION Smart cartridge Set of 2 keys for programming access Box with 1 paper roll and 1 label roll Serial cable for PC communications User manual... -
Page 5: Smart Cartridge
SMART CARTRIDGE With this option you can program the scale operating mode (label or paper) only placing the selector button of the smart cartridge in the right place (see figure), in this way you don’t need to enter programming mode to change the operating mode. -
Page 6: Changing The Paper Roll
CHANGING THE PAPER ROLL Open the access door placed at the right of the scale. Raise the thermal printhead rotating its lever clockwise. III) Rotate counterclockwise the handle with the legend Pull the cartridge from the scale holding it with both hands taking it from the parts When the cartridge is out, take up the handle with the legend to leave the center of the paper roll,... -
Page 7: Changingthe Labels Roll
CHANGING THE LABELS ROLL Remove 40cm of labels from the roll (approx. 10 labels). Open the access door of the scale. III) Raise the thermal printhead rotating its lever clockwise. Rotate counterclockwise the handle with the legend Pull the cartridge from the scale holding it with both hands taking it from the parts Once the cartridge is out, raise the handle with the legend to leave the center of the paper roll. -
Page 8: Important Parts
IMPORTANT PARTS 1.- CABINET- Manufactured in stainless steel it is resistant to corrosion and strokes. 2.- PLATE.- Manufactured in stainless steel with bent and rounded borders for increased security. 3.- OPERATION KEYPAD .- It has multifunctions, with big and readable keys, their handling is very easy. 4.- PLU’S &... -
Page 9: Operation Keypad
OPERATION KEYPAD KEY.- Turn the weigh to zero to start with a new reference. KEY.- This key is used to eliminate any container’s weight that you do not wish to consider during a transaction. (for example bottles, bags, boxes, etc.) see page 10. KEY .- This key is used to load a PLU, that it was engraved in memory (see page 12). -
Page 10: Examples Of Label Printing Formats
EXAMPLES OF LABEL PRINTING FORMATS Your scale has 4 preprogrammed label printing formats, besides that you can personalized them or create the one you want (see page 14 of the programming manual). FORMAT 1 (PRE-PROGRAMMED) FORMAT 2 57 X 40 mm label With bar code (if it is programmed). -
Page 11: General Operation Description
GENERAL OPERATION DESCRIPTION WEIGHING A PRODUCT At the end of the countdown sequence, zeros will appear in the display, at this moment the scale is ready to use. (Otherwise, see the section reference to zero), then you place on the plate the product to weigh and you will see the weight in the indicator. -
Page 12: Referencing To Zero Weight
In this way every time that you load a plu with reference of tare, the weight of the programming tare will be substracted to the total weight on the plate, example: You have a program tare of 0.04 lb. in the PLU “sugar”. Assure it the indicator of weight is in zero weight. -
Page 13: Loading A Plu
LOADING A PLU You can “LOAD” a price of any product previous engraving in memory from two ways: Just pressing any of the keyboard keys for direct PLU’S (verify that the ABC mode is disable). PROGRAMMED TEMPLATE Type the PLU number that is programmed and press the. The capacity of the scale is up to 10,000 programmable PLU’S in your extended memory version. - Page 14 INTRODUCE CAPITAL LETTERS. Verify if the PROD. VARIOS mode is activate. 1.- For introduce capital letters press if you want to change it to small press again. In case that you are in capital letters an indicator appears on the display like the shown in the next figure: CAPS (CAPITAL LETTERS) PRINTING A LABEL WITH A PRODUCT NAME Example: Orange PLU to 12.50.
-
Page 15: Entering To Programming Mode
TOTAL SALE This can be printing in any mode (label or paper). 1.- For printing the total sale press 2.- In case you are working with label with or without gap will ask you that press the key in order that labels amassed and you could continue with the total sale printing, in case of paper will print it in continuous form. -
Page 16: Printing Format Description Detailed
PRINTING FORMAT DESCRIPTION PAPER AND CONTINUOUS LABEL PRINTING FORMATS BRIEF FORMATS These printings are designed to print several operations in the same ticket (you can sell several products per receipt) as a cash registers. In the option per product printing format you can print just one product per receipt as if you were working with labels, paper printing examples: The receipt printed by the scale will include the next information depending of the programmed format: 56 mm... -
Page 17: Sale Operation Formats
PAPER AND CONTINUOUS LABEL PRINTING FORMATS OPERATION ADDING PRODUCTS TO A SALE To add any product from of sale, use the key. First type the price of the product (only if are enable the NON PLU`S ), or load the plu to add and then press the key, then appear on the display: In this way, you can know at any moment, the quantity that the customer has to pay. -
Page 18: Calculating A Discount
CALCULATING A DISCOUNT You may use this key, for discounting a certain quantity in percentage or in cash of the total accumulated in a sale. In order to make a discount press the key if you desire to make a discount in percentage. If you desire to make in total press the key again, then type the percentage or the cash to discount and the press again the key for ending with the operation. -
Page 19: Label Printing Format
LABEL PRINTING FORMAT Your scale has 4 preprogrammed label printing formats which can be printed in 2 label sizes LABEL SIZES FOR PREPROGRAMMED LABEL PRINTING FORMATS PRINTING LABELS To print a weighed product, there are two ways to print it, Automatic or Manual: 1.- Manual printing mode To print in this mode just load a PLU, or introduce the price, place the product over the plate and press the key. -
Page 20: Agent's Operation
To clear this function press the key. NOTE: If you want to work with the fixed price function without automatic printing is necessary press the key again, and the automatic printing will disable and will be necessary press the key when you want print. AGENT’S OPERATION You can operate your scale with or without agents, to work with agents you may assign a number (1-20) to each one, with this number the agent will start any sale, in this manner the scale manage several accounts one per... -
Page 21: Maintenance And Cleanness
MAINTENANCE AND CLEANNESS - Do not use flow of water to clean your scale. Use a damp rag and clean each of its components daily: Cabinet, Plate, etc. Use a clean rag with water or alcohol only to clean the keyboard. - To clean the sensor labels must be use a disposable cleaning pad damped with alcohol (see label w/use instructions in lateral door) - If you observe any problem with the operation of your scale, before consulting to their authorized distributor, read this... - Page 22 POSSIBLES FAILURES WHEN YOU ARE WORKING WITH PAPER Shows printhead up The thermal printhead is Bring down the thermal printhead rotating its lever counterclockwise The paper roll is empty Place a new labels roll. The cassette is wrong Follow the steps to remove the cassette, and reinstall Shows paper out placed it again.
-
Page 23: Technical Specifications
TECHNICAL SPECIFICATIONS TECHNICAL CHARACTERISTICS Max. Capacity 40 lb./ 20 kg Min. Div. 0.01 lb /0.005 kg Max. Tare 40 lb./ 9.995 kg Max. price $ 999.99 -14 to 104 °F (-10 to 40 °C) Range of operation temp. -4 to 122 °F (-20 to 60 °C) Range of storage temp. -
Page 24: Terms Glosary
GLOSSARY PLU: Price-Look-Up, memory space to store all the information of a PLU DEFAULT: The values or programming manners that are already programmed from the manufacture. PRODUCTS NOT WEIGHED: The sales or the labels that carry out the make with pieces not with pounds. MANNER OF PRODUCTS NOT WEIGHED: Refers to the normal manner of the scale, the sales or labels carry out multiplicand the weight for the price of pound.
