Summary of Contents for Rinnai Evolve 950
- Page 1 Operation guide Evolve 950...
- Page 2 Important: Appliance must be installed with a Rinnai approved flue system. This appliance shall be installed in accordance with: Manufacturer’s installation instructions AS/NZS 5601 Gas Installations Local regulations and municipal building codes Installation, servicing and repair shall be carried out only by authorised personnel.
-
Page 3: Table Of Contents
About your Evolve ........... 4 Operation without the remote ......5 Operation using the remote ......6 Clearances ............8 General information ........9 Care and maintenance ........10 Servicing ............11 Safety ............... 12 Troubleshooting ..........14 Error codes ............16 Abnormal flame pattern ........ -
Page 4: About Your Evolve
About your Evolve Congratulations on the purchase of your Rinnai Evolve gas fireplace. We hope you love this product as much as we do, and on the off chance that something does go wrong, or if you need help, we’re only a phone call away. -
Page 5: Operation Without The Remote
Do not unplug the main power supply to turn the unit off as the convection fan is required to operate for several minutes after the unit is turned off to assist in cooling the unit down. Evolve 950 Operation Guide: 12472-A | 5... -
Page 6: Operation Using The Remote
Never Press the Standby/On button. mix old and new This will turn off the unit and the batteries. LED will glow red to indicate the appliance is in standby. 6 | Evolve 950 Operation Guide: 12472-A... - Page 7 The Extra Low function is useful show ‘Lock’. To cancel press the revert to displaying the time. in situations when the room Lock button for three seconds. temperature keeps rising even Evolve 950 Operation Guide: 12472-A | 7...
-
Page 8: Clearances
For example; a mantel depth (B) of 350 mm will require 600 mm (A) of vertical clearance. Surround from side of glass 250 mm min. Surround projection at C - 250 mm (side clearance) 250 mm max. 8 | Evolve 950 Operation Guide: 12472-A... -
Page 9: General Information
General information Before operation please read these instructions to get an overview of how to operate, maintain and service your Rinnai gas fire. Electrical connection Power failure TV installation above the fireplace The Evolve 950 is If the power is disrupted... -
Page 10: Care And Maintenance
LED indicator, located by the infra-red remote receiver window, will illuminate and the appliance will go to a low setting. To restore normal operation remove the obstruction and use the remote control to resume normal operation. 10 | Evolve 950 Operation Guide: 12472-A... -
Page 11: Servicing
Do not attempt to carry out any service work other than that mentioned in the troubleshooting section. If you have any other faults or problems, please refer to your installer or contact Rinnai. Evolve 950 Operation Guide: 12472-A | 11... -
Page 12: Safety
Do not allow anyone to post Do not spray aerosols while the articles through into the heater. appliance is operating. Most contain butane gas which can be a fire hazard if used near the appliance. 12 | Evolve 950 Operation Guide: 12472-A... - Page 13 Evolve 950 Troubleshooting & error codes...
-
Page 14: Troubleshooting
Evolve are a normal part of operation. If you are still unsure or concerned after reading this section, please contact Rinnai. During installation there will be an initial burning in period where some smoke and smell may be experienced. - Page 15 • Replace batteries Flat batteries in remote control Remote lock- up due to signal being Press the • out of range, Standby/On incorrectly button aimed, or obstructed Evolve 950 Operation Guide: 12472-A | 15...
-
Page 16: Error Codes
Spark sensor faulty Service call. Combustion fan motor faulty Service call. Solenoids faulty Service call. Flame detection circuit fault Service call. Communication error Service call. Looking down at the error display window—sits underneath filter 16 | Evolve 950 Operation Guide: 12472-A... -
Page 17: Abnormal Flame Pattern
Abnormal flame pattern Each Rinnai flame fire has a distinct flame pattern. This should look the same every time you start your fire, after an initial warm up period of approximately 20 minutes. Abnormal flame performance and/or pattern can indicate a... -
Page 18: Installation Checklist
Checklist F Appliance positioned in a suitable location (clearances, mantels, surrounds etc.). F Rinnai flue system installed and tested to ensure effective draw. F Gas pressure checked, set, and down rated (if applicable) according to data plate instructions F Burn media installed as per instructions. -
Page 19: Limited Warranty
Limited Warranty Rinnai brings you peace of mind with a: 2 Year minimum warranty Terms and conditions during or after installation, has not been 5. Servicing of the product is to be carried operated in accordance with operating out by a Rinnai authorised service centre. - Page 20 Experience our innovation Rinnai.co.nz 0800 746 624 http://www.youtube.com/rinnainz http://www.facebook.com/rinnainz Evolve 950 Operation Guide: 12472-A...
