Page 1: Installation Guide
Installation guide Evolve Models: RHFE950ETRN/RHFE950ETRL RHFE1250ETRN/RHFE1250ETRL... - Page 2 Important: Appliance must be installed with a Rinnai approved flue system. This appliance shall be installed in accordance with: - Manufacturer’s installation instructions - AS/NZS 5601 Gas Installations - Local regulations and municipal building codes Installation, servicing and repair shall be carried out only by authorised personnel.
-
Page 3: Table Of Contents
Before you start ............ 4 Specification ............5 Dimensions ............6 Gas supply ............7 Electrical supply ........... 7 Wall penetration ........... 8 Framing dimensions ..........9 Clearances from combustibles ......10 TV installation ............12 Flueing options ............. 13 Evolve installation overview ......... -
Page 4: Before You Start
This could result in serious injury and/or property damage. Flue installation guide These instructions are to be used in conjunction with the Rinnai Arriva and Evolve flue installation guide supplied with the flue kits. Carton contents The components for the Evolve are supplied in three separate cartons (four if a mesh guard is purchased). -
Page 5: Specification
Appliance must be installed with a • Evolve 1250: 100 kg Rinnai flue system. * Will vary according to gas type and flue configuration ** Will vary depending on geographical location in NZ Evolve Installation Guide: 12471-C 03-15 | 5... -
Page 6: Dimensions
Dimensions All dimensions are in mm. Evolve 950 1070 Evolve 1250 1255 1320 1000 6 | Evolve Installation Guide: 12471-C 03-15... -
Page 7: Gas Supply
The power cord passes through a slot in the back right hand corner of the appliance. Rinnai recommend the heater be plugged into a 230 V, 10 A earthed power point. The power point must not be above the heater. Alternatively the appliance can be direct wired if the power supply is to be concealed. -
Page 8: Wall Penetration
Wall penetration Direct flue wall penetration requirements Use the guide pictured to mark the penetration points for the gas supply and flue transition locations. Consideration must be given to the position of any studs, noggins or other components of the wall structure on both sides of the wall. -
Page 9: Framing Dimensions
D-depth 570 mm min. 570 mm min. The main points governing location are flueing and warm air distribution. The Rinnai Evolve has an integrated zero clearance box that isolates the appliance from combustible materials. This means it can be installed directly into a decorative fireplace constructed from materials such as wood or plaster. -
Page 10: Clearances From Combustibles
Clearances from combustibles The clearances listed below, measured from the edge of the glass, are minimum clearances unless otherwise stated. While the heater is operating The appliance must not be installed where curtains or other combustible materials could come into contact with the heater. - Page 11 The below diagrams are to assist people who are determining the clearance area around the Evolve without having the unit on site. Evolve 950 1500 Minimum to ceiling Minimum above fire Clearance Glass width Clearance Evolve 1250 1800 Minimum to ceiling Minimum above fire 1000 Clearance...
-
Page 12: Tv Installation
TV installation with the TV manufacturer—some have warranty conditions that state a TV is not to be installed above a fireplace. Rinnai does not accept any responsibility for damage to a TV resulting from the use of this information. 400 mm... -
Page 13: Flueing Options
The below options detail the most common types of flue installations. If you have an installation that varies from those below, please contact Rinnai. For further detail on each of the options refer to the Arriva and Evolve flue installation guide. -
Page 14: Evolve Installation Overview
Evolve installation overview Construct frame as per Line wall—could also plaster at Complete the gas connection enclosure dimensions on p. 9. this stage. refer p. 7. Electrical supply can also be completed at this point. Connect flue system. Install heater into enclosure*, Install burn media, refer p screw to frame, and complete 18-23. -
Page 15: Connect Flue System
Connect flue system Consult the Rinnai Arriva and Evolve flue installation guide supplied with the Arriva/ Evolve flue kits for detailed flue installation instructions. For connection of the flue to the heater refer information below. Removing the pipe clamp, extension tube and exhaust pipe Before installing the heater into the enclosure the pipe clamp, telescopic extension tube, and exhaust pipe need to be removed so there is room to connect the flue system. -
Page 16: Install Heater Into Enclosure
Install heater into enclosure 1. Carefully move the heater into the enclosure, guiding the piping, flexible gas connection, and telescopic extension tube into the access openings and through the appliance. Ensure that the air hose is not in a position where it could get caught or crushed by the unit. 2. -
Page 17: Removing And Replacing The Glass Panel
Removing and replacing the glass panel Before the burn media can be installed into the combustion chamber, the glass panel needs to be removed. Remove the four retaining screws—two at the top and two at the bottom. When replacing tighten all four screws and then back off by quarter of a turn. If the glass panel is screwed too tight, the panel will bow and the spring release mechanism won’t work properly. -
Page 18: Install Burn Media - Log Set
Install burn media - log set The glass retainer will need to be removed before installing the log set and granules. Use extreme care when handling the log pieces, they are made from a fragile material and will damage easily. Use these instructions in conjunction with the burn media guide sheet, which is attached to the engine. - Page 19 The installation procedure for both models is the same. The only difference is the position of log eight and the addition of logs 9 and 10—the Evolve 1250 has an extra two logs. 1. Back left log 2. Back right log Align bottom locating holes with the locating pins at the Align bottom locating holes with the locating pins at back of the burner—the log will sit up against the back of...
-
Page 20: Adding The Granules
10. Far RHS small log (1250 model only) 9. Far LHS small log (1250 model only) Fit the far small right hand log onto the two locator Fit the far small left hand log onto the two locator brackets. brackets. Adding the granules • Evolve 950: Two granule packs... -
Page 21: Install Burn Media - Stones
Install burn media - stones The glass retainer will need to be removed before installing the stone set and granules. Use extreme care when handling the stones, they are made from a fragile material and will damage easily. Use these instructions in conjunction with the burn media guide sheet, which is attached to the engine. - Page 22 4. Place the fourth grey cut out stone (4G) 3. Place first white cut out stone (3W) Place the fourth grey cut out stone on the next Place the first white cut out stone on the middle burner bracket. burner bracket. The white stones are designed to be interspersed to add contrast and provide a good visual picture—make sure they are not all placed together.
- Page 23 Evolve 1250 1. Place the five skinny stones (S) 2. Place the eight large stones (L) The five skinny stones (two dark grey, two light Place the eight large stones evenly throughout the grey, one white) with the bottom cut outs need to burner bed.
-
Page 24: Commissioning
Commissioning The gas pressures of the appliance are factory preset for direct flue installations (most common type of installation) and will normally not require adjustment. The combustion chamber glass must be on when checking the operating pressures. The commissioning sheet is located in a plastic pouch inside the unit on the right hand side. -
Page 25: Install The Inner And Outer Frame
Install the inner and outer frames Installing the outer frame 1. Remove, but don’t discard, the two black screws installed in the lower bracket of the heater engine. 2. Position the outer frame close to the heater engine and connect the RJ45 plug into the socket on the inside top left of the heater. -
Page 26: Test Operation And Lighting Sequence
If the appliance cannot be made to perform correctly please contact Rinnai. Installation checklist and customer handover Complete the installation checklist in the customer operation guide, and make sure you leave the guide with the customer. -
Page 27: Wiring Diagram
Wiring diagram (part of commissioning) ON/OFF DISPLAY UNIT Wiring Diagram RHFE950/1250ETR Issue A CONTROL DISPLAY UNIT OH.TH 2 blk blk OH.TH 1 F (3A) gr/y R.TH AC 230-240V gr/y 6 5 4 4 3 2 1 3 2 1 bl w y bk bk bk bk y pl gy or y or bk br bl w... - Page 28 Experience our innovation Rinnai.co.nz 0800 746 624 http://www.youtube.com/rinnainz http://www.facebook.com/rinnainz Evolve 950 Installation Guide: 12471-C 03-15...
