- Page 1 ® Model 700T Installation Guide ® © 2001 Directed Electronics, Inc. Vista, CA N700T 8-01 Rev. E 1.1...
-
Page 2: Table Of Contents
table of contents What Is Included ..... . 3 Auxiliary Harness (H2) Wire Connection Guide . . 17 Connecting Door Lock Inputs to Vehicles with Installation Points to Remember. -
Page 3: What Is Included
what is included I One control module with on-board shock sensor I One plug-in status LED I One plug-in Valet/program switch I One 12-pin primary harness (H1) I One 5-pin auxiliary harness (H2) I One Revenger Soft-Chirp siren installation points to remember before beginning the installation I Check with the customer on Status LED location. -
Page 4: Tools Required
tools required This is a general list of tools required to complete the installation of this security system in most vehicles. Some vehicles may require additional tools. I Digital multi-meter I Nutdriver and/or socket set I Wire cutters/strippers I Panel removal tool I Solderless terminal crimpers I Drill bit set I Cordless power drill... -
Page 5: Control Module
control module Never put the control module in the engine compartment! The first step in hot-wiring a vehicle is removing the driver's side underdash panel to access the starter and ignition wires. If the control module is placed just behind the driver's side dash it can easily be disconnected. When locating the control module, try to find a secure location that will not require you to extend the harness wires (they are 1.5 meters long). -
Page 6: Status Led
IMPORTANT! When the vehicle is delivered, please show the user where the switch is located and how to disarm the system with it. status LED Things to remember when positioning the Status LED: I It should be visible from both sides and the rear of the vehicle, if possible. I It needs at least -inch clearance to the rear. -
Page 7: Finding The Wires You Need
wiring! Exposed yellow butt connectors do not look like factory parts, and will not fool anyone! For this reason, routing the starter kill wires away from the steering column is recommended. finding the wires you need Now that you have decided where each component will be located, you’re going to find the wires in the car that the security system will be connected to. -
Page 8: Finding A (+) Parking Light Wire
How to find (+)12V ignition with your multimeter: 1. Set to DCV or DC voltage (12V or 20V is fine). 2. Attach the (-) probe of the meter to chassis ground. 3. Probe the wire you suspect of being the ignition wire. The steering column harness or ignition switch harness is an excellent place to find this wire. -
Page 9: Finding The Door Pinswitch Circuit
finding the door pinswitch circuit The best places to find the door pinswitch wire are: I At the pinswitch: When testing at the pinswitch, check the wire to ensure that it “sees” all the doors. Often, the passenger switch will cover all the doors even if the driver’s switch will not. I At the domelight: This may not be your best choice if the vehicle has delayed domelight supervision, but it will work in vehicles with completely diode-isolated pinswitches. -
Page 10: Making Your Connections
4. Turn the ignition key switch to the start position. Make sure the car is not in gear! If your meter reads (+)12V, go to the next step. If it does not, probe a different wire. 5. Cut the wire you suspect of being the starter wire. 6. -
Page 11: Solder Connections
3. Insert the twisted pair of wires into one end of the butt connector and crimp securely. Vehicle Wire Crimp Vehicle Wire Module Wire 4. Insert the other end of the vehicle’s wire into the other end of the butt connector and crimp securely. Crimp solder connections 1. -
Page 12: Primary Harness (H1) Wire Connection Guide
primary harness (H1) wire connection guide This guide describes in detail the connection of each wire. Also included are possible applications of each wire. This system was designed with the ultimate in flexibility and security in mind. Many of the wires have more than one possible function. - Page 13 H1/2 WHITE light flash output As shipped, this wire should be connected to the (+) parking light wire. If the light flash polarity jumper inside the unit is moved to the opposite position (see the Internal Jumpers section of this guide), this wire supplies a (-) 200 mA output.
- Page 14 H1/4 BLACK/WHITE 200 mA (-) domelight-supervision output Connect this wire to the optional domelight supervision relay. IMPORTANT! This output is only intended to drive a relay. It cannot be connected directly to the domelight circuit, as the output cannot support the current draw of one or more bulbs. H1/5 GREEN (-) door trigger input Most vehicles use negative door trigger circuits.
- Page 15 H1/7 VIOLET (+) door trigger input This wire is used in vehicles that have a positive (+) switched dome light circuit. Connect the violet wire to a wire that shows (+)12V when any door is opened, and ground when the door is closed. H1/8 BLACK (-) chassis ground connection Connect this wire to bare metal, preferably with a factory bolt rather than your own screw.
- Page 16 H1/10 BROWN (+) siren output Connect this to the red wire of the siren. Connect the black wire of the siren to (-) chassis ground, preferably at the same point you connect the control module’s black ground wire. H1/11 RED (+)12V constant power input Before connecting this wire, remove the supplied fuse.
-
Page 17: Auxiliary Harness (H2) Wire Connection Guide
auxiliary harness (H2) wire connection guide H2/1 BROWN (-) horn honk output This wire supplies a (-) 200 mA output that can be used to honk the vehicle’s horn. It provides a pulsed output when the security system is in the triggered sequence or in panic mode. In most vehicles with (-) horn circuits this wire can control the vehicle’s horn without adding a relay. -
Page 18: Connecting Door Lock Inputs To Vehicles With Driver's Door Unlock From Factory Remote
has no function. If the customer wants the system to automatically lock the doors when the system passively arms, connect this wire to the lock circuit in the vehicle. An optional relay may be required. IMPORTANT! Never use this wire to drive anything but a relay or a low-current input! This transistorized output can only supply (-) 200 mA, and connecting directly to a solenoid, motor, or other high-current device will cause the module to fail. -
Page 19: Connecting Door Lock Inputs In Vehicles With Driver's Door Unlock And External Relays
connecting door lock inputs in vehicles with driver’s door unlock and external relays This system is used in many four-door GM sedans. To test for this type of system, probe the unlock wire from the interior switch (black or white). Unlock the driver’s door, by itself, using the factory remote. If the switch wire shows (+) 12V, then use the following diagram: NOTE: It is often easy to access the passenger unlock wire going to the rear door motor on the driver’s side. -
Page 20: Door Lock Learn Routine
NOTE: Failure to insert the diodes at the correct point will allow the system to be disarmed by one of the power door lock switches inside the vehicle. The best place to insert the diode is at the keyless entry module itself or at the relays. door lock learn routine Before the unit will respond to the factory remote keyless system, it must learn the polarity of the door lock wires. -
Page 21: Plug-In Harnesses
3. Press and HOLD the Valet/program for three seconds. 4. The LED will flash once to confirm the lock polarity was learned. plug-in harnesses super-bright LED, 2-pin white plug The super-bright LED operates at 2VDC. Make sure the LED wires are not shorted to ground as the LED will be damaged. -
Page 22: Internal Programming Jumper
internal programming jumper light flash jumper This jumper is used to determine the light flash output. In the (+) position, the on-board relay is enabled and the unit will output (+)12V on the WHITE wire, H1/2. In the (-) position, the on-board relay is disabled. The WHITE wire, H1/2, will supply a (-) 200 mA output suitable for driving factory parking light relays. -
Page 23: System Features Learn Routine
system features learn routine The System Features Learn Routine dictates how the unit operates. It is possible to access and change any of the feature settings using the Valet/program switch. To enter the System Features Learn Routine: Open a door: The GREEN wire, H1/5, or the VIOLET, H1/7 must be connected. Turn the ignition on, then off: The YELLOW wire, H1/9 must be connected. -
Page 24: System Features Menu
2. Then press the Valet/program switch once more and HOLD it. For example, if you just programmed the second feature and you would like to program the seventh feature in the menu, you would press and release the Valet/program switch five times. Then press it once more and HOLD it. The siren would chirp seven times to confirm access to the seventh feature. - Page 25 3 SIREN DURATION 30/60 SECONDS: In the default setting, the full triggered sequence will continue when trig- gered for 30 seconds. This can be changed to 60 seconds in the system features learn routine. 4 DOOR TRIGGER INSTANT/DELAYED: In the instant (default) setting, if a door is opened while the security system is armed the system will trigger immediately.
-
Page 26: Table Of Zones
table of zones When using the diagnostic functions, use the Table of Zones to determine which input has triggered the system. It is also helpful in deciding which input to use when connecting optional sensors and switches. ZONE NO. TRIGGER TYPE INPUT DESCRIPTION Instant H1/6 BLUE wire. - Page 27 I Door input does not immediately trigger full alarm. Instead, first I hear chirps for three seconds. That’s how the progressive two-stage door input works! This is a feature of this system. This is an instant trigger, so even if the door is instantly closed, the progression from chirps to constant siren will continue. I Closing the door triggers the system, but opening the door does not.
-
Page 28: Wiring Quick Reference Guide
wiring quick reference guide © 2001 Directed Electronics, Inc. Vista, CA...
