  • Page 1 M O D E L U S E R’ S G U I D E 851T...
  • Page 2 l l i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y For a period of one calendar year from the date of purchase of this auto-security device, Directed Electronics, Inc.
  • Page 3 TO THE MAXIMUM EXTENT ALLOWED BY LAW, ANY AND ALL WAR- RANTIES ARE EXCLUDED BY THE MANUFACTURER AND EACH ENTITY PARTICIPATING IN THE STREAM OF COMMERCE THEREWITH. THIS EXCLUSION INCLUDES BUT IS NOT LIMITED TO THE EXCLUSION OF ANY AND ALL WARRANTY OF MERCHANTABILITY AND/OR ANY AND ALL WAR- RANTY OF FITNESS FOR A PARTICULAR PURPOSE AND/OR ANY AND ALL WARRANTY OF NON-INFRINGEMENT OF PATENTS, IN THE UNITED STATES OF AMERICA AND/OR ABROAD.

  • Page 4: Table Of Contents

    t t a a b b l l e e o o f f c c o o n n t t e e n n t t s s w w h h a a t t i i s s i i n n c c l l u u d d e e d d ..................... . 2 2 i i n n s s t t a a l l l l a a t t i i o o n n t t o o o o l l s s .
  • Page 5 w w h h a a t t i i s s i i n n c c l l u u d d e e d d ➤ Control Module ➤ One Two-Button Transmitter ➤ 8-Pin Main H/1 Harness ➤...

  • Page 6: System Maintenance

    i i m m p p o o r r t t a a n n t t i i n n f f o o r r m m a a t t i i o o n n Congratulations on the purchase of your remote start keyless entry system.

  • Page 7: Your Warranty

    ➜ your warranty Your warranty registration must be completely filled out and returned within 10 days of purchase. Your product warranty will not be validated if your warranty registration is not returned. Please note that it is necessary to keep your proof of purchase. ➜...
  • Page 8 1. Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage). 2. When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must be disabled using the toggle switch. 3.
  • Page 9 the vehicle starts in gear, cease remote start operation imme- diately and consult with the Dealer to fix the problem imme- diately. ➤ After the remote start module has been installed, test the remote start module in accordance with the Safety Check outlined in this installation guide.
  • Page 10 p p r r i i m m a a r r y y h h a a r r n n e e s s s s ( ( H H / / 1 1 ) ) , , 8 8 -p p i i n n c c o o n n n n e e c c t t o o r r H H 1 1 / / 1 1 BLACK...
  • Page 11 r r e e l l a a y y s s a a t t e e l l l l i i t t e e r r i i b b b b o o n n h h a a r r n n e e s s s s ( ( H H / / 3 3 ) ) , , 5 5 -p p i i n n c c o o n n n n e e c c t t o o r r H H 3 3 / / 1 1 H H 3 3 / / 2 2...
  • Page 12 i i n n s s t t a a l l l l a a t t i i o o n n Be sure to read this section thoroughly and view the Hornet Do- It-Yourself Installation Video in its entirety before starting the installation.

  • Page 13: Step

    warning! Verify that the vehicle is set to park and that the parking brake is set before beginning installation. ➜ step 1 Ground Wire The BLACK wire on the main 8-pin harness is ground. This wire should be connected to a clean, paint-free area of metal in the drivers kick panel area.

  • Page 14: Step

    ➜ step 2 Constant Power and Ignition wires Almost all power and ignition wires can be found behind the key cylinder under the lower drivers side dash panel. Using the appropriate hand tools, remove the lower dash panel using care not to break any parts.
  • Page 15 warning! Before making any connection to constant battery power make sure that the two green 30 amp fuses are removed from the fuse holders on the two thick red wires. Failure to do so may cause fire or shorting of sensitive electrical components. Once the constant power wire has been identified, solder the two thick RED wires from the relay satellite pack to it and cover the connection with electrical tape to ensure a safe connection.
  • Page 16 If the vehicle requires more than one ignition as per the Web site information follow the same test procedure and solder the thick PINK/WHITE wire to it and be sure to cover your connection with electrical tape. If your vehicle requires more than two igni- tions, contact Hornet Technical Support.
  • Page 17 Now that the accessories have been located, find the wire suspected to be the starter wire according to the web information on your vehicle. Place the red lead of your meter on the wire. With the key in the off position the meter should read 0.00 volts and will stay at 0.00 volts in all key positions except the crank position.
  • Page 18 ➜ step 4 Safety Shutdown Wires important! These wires are meant to protect the vehicle and anyone near the vehicle. They must be connected appropriately to prevent damage to the vehicle and possi- ble bodily injury. Failure to properly install these wires may cause the vehicle to lunge if remote started while in gear.
  • Page 19 Installing the hood pin switch requires drilling a ¼-inch hole in the metal lip under the hood. Choose a location that will allow the pin switch to be depressed when the hood is closed. The pin switch has a connector on the bottom to connect to. Using a spade connector (included) strip back a ¾-inch section of the insulation and crimp the connector on to the wire.
  • Page 20 The last safety shutdown wire is the neutral safety wire. This wire is extremely important as it prevents the vehicle from starting in gear which could cause serious bodily harm. When determining the neutral safety wire it is important to test the vehicles starting circuit for factory neutral safety features.
  • Page 21 The majority of neutral safety switches can be located at the steering column in the harness coming from the gear shift. With the meter black lead still in the kick panel, use the red lead of the meter to probe the suspected wires. The correct wire will show a small amount of voltage in any gear but once the gear shift is put in neutral or park it will read 0.00 Volts.
  • Page 22 ➜ step 5 Parking light flash There are several different types of parking light circuits. The following description is for a standard negative-triggered parking light circuit, usually located at the light switch. If the web vehicle information suggests a different type of parking light circuit, please contact Hornet Technical Support.
  • Page 23 ➜ step 6 Door locks Although there are numerous types of door lock circuits, the most common is the negative triggered door lock system. Check the web information on your vehicle to determine your door lock system type. If your vehicle has a negative triggered door lock system, follow the steps below.
  • Page 24 Repeat this process for the unlock wire but press the switch to the unlock position when testing. Once you have identified the correct wire, solder the LIGHT BLUE wire off the main connector to it and cover the connection with electrical tape. note: Additional parts may be required to interface with certain door lock types.
  • Page 25 enough to actually start the engine, it is possible to change the programming to extend the crank time. Refer to the Programming Options section of this guide. On some vehicles the electrical system has too low of a voltage variance for the remote start module to see. In this case the engine will not be protected from over cranking, over revolution, or under revolution of the engine.
  • Page 26 voltage should read between 1.5 volts and 2.9 volts. Once the correct tachometer wire has been identified, turn the vehicle off. Run the VIOLET/WHITE wire through the firewall along side the hood pin wire. Then run it into the engine compartment through the factory rubber grommet used for the hood pin.
  • Page 27 ➜ step 8 Factory Alarm/Disarm Since most newer vehicles come equipped with a factory alarm system, it is necessary for the factory alarm to be disarmed while remote starting the vehicle. Locate the factory alarm disarm wire using the web vehicle infor- mation.
  • Page 28 ➜ step 9 Immobilizer Bypass Modules warning! Any vehicle equipped with a fac- tory immobilizer must use an immobilizer bypass module to remote start. If not used, the vehicle ignition or fuel supply circuits could lock up and require a costly trip to the dealer to reset the computer system.
  • Page 29 ➜ step 10 Testing the system Once steps 1-9 have been completed, the operation of the system can be tested. Place the two 30-amp fuses back into the relay satellite RED wire fuse holders. Make sure that the vehicle is in park with the emergency brake on and the hood closed.

  • Page 30: Standard Configuration

    t t r r a a n n s s m m i i t t t t e e r r f f u u n n c c t t i i o o n n s s The receiver uses a computer-based learn routine to learn the transmitter buttons.
  • Page 31 Button I The door locking and unlocking functions are controlled by pressing Button II Timer Mode is controlled by Button I and II The remote start function of your system is controlled by pressing simultaneously. t t r r a a n n s s m m i i t t t t e e r r / / r r e e c c e e i i v v e e r r l l e e a a r r n n r r o o u u t t i i n n e e The system comes with one transmitter that has been taught to the receiver.
  • Page 32 2. C C h h o o o o s s e e . . Within 10 seconds, press and release the Program switch the number of times corresponding to the desired channel listed below. Once you have selected the channel, press the switch once more and hold it.

  • Page 33: Locking/Arming

    Program switch. Press it one time and release it to advance from Channel One to Channel Two. Now, press and hold the Program switch. The LED will flash two times. As before, do not release it. If you want to program Channel Three after programming Channel One, release the Program switch, press it twice and release it to advance to Channel Three.

  • Page 34: Unlocking/Disarming

    ➜ unlocking/disarming To unlock the doors press lights will flash twice to confirm that the doors are unlocked. ➜ ignition-controlled door locks If power door locks have been connected to your system and the ignition-controlled door locks are programmed on, the vehicle's door will lock three seconds after the ignition has been turned on and unlock when the ignition is turned off.
  • Page 35 To remote start the vehicle: 1. Simultaneously press second. 2. The parking lights will flash to confirm remote start opera- tion. 3. Once the vehicle has started, it will run for the pre-program- med period of time (12 or 24 minutes) or until a shutdown input is triggered.

  • Page 36: Timer Mode

    ➜ timer mode Timer Mode automatically starts the engine and runs it for a pre-programmed time period, every three hours for a total of six operation cycles. This feature helps to ensure that your engine will start in the morning after a night of extremely cold temper- atures.

  • Page 37: Valet Take-Over

    1. Start the engine by pressing 2. Press and release 3. Within two seconds press and release 4. The engine will shut down and the parking lights will flash four times to confirm that Timer Mode has been exited. If the car has already been remote started, skip Step One.
  • Page 38 f f e e a a t t u u r r e e s s m m e e n n u u The factory settings are indicated in bold text in the table below. Feature L L E E D D O O n n S S e e t t t t i i n n g g Number ( ( p p r r e e s s s s c c h h a a n n n n e e l l 1 1 ) ) E E n n g g i i n n e e c c h h e e c c k k i i n n g g o o n n...
  • Page 39 r r a a p p i i d d r r e e s s u u m m e e l l o o g g i i c c This Directed system will store its current state to non-volatile memory.
  • Page 40 ➤ The starter cranks for six seconds but does not start. Either the wrong ignition wire is being energized, the system’s ignition and accessory wires have been connected backwards, or the vehicle has two ignition circuits. Try acti- vating the unit with the ignition key in the “run” position. If the vehicle then runs normally, retest your ignition system.
  • Page 41 check the 3A and both 30A fuses on the relay satellite. Also make sure that the ground wire is going to a chassis ground and not to something under the dash. ➤ The remote start will activate but the starter never engages. Check for voltage on the purple starter wire two seconds after the remote start becomes active.
  • Page 42 ➤ The vehicle starts, but the starter keeps running. Is the system programmed for engine checking off or voltage sense? When programmed for either of these features, the engine cranks for the preprogrammed crank time regardless of how long it takes to start the vehicle to actually start. Adjust to a lower cranking time.
  • Page 43 g g l l o o s s s s a a r r y y o o f f t t e e r r m m s s The “brain” of your system. Usually hidden under Control Unit: the dash area of the vehicle.
  • Page 44 s s e e c c u u r r i i t t y y & & c c o o n n v v e e n n i i e e n n c c e e e e x x p p a a n n s s i i o o n n s s Listed below are some of the many expansion options available for use with your system.
  • Page 45 w w i i r r i i n n g g q q u u i i c c k k r r e e f f e e r r e e n n c c e e g g u u i i d d e e ©...
  • Page 46 n n o o t t e e s s _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ © 2002 directed electronics, inc.
  • Page 47 © 2002 directed electronics, inc.

  • Page 48: Quick Reference Guide

    QUICK REFERENCE GUIDE: To lock the doors using your remote s Pressing for one second will lock the doors. The parking lights will flash once to confirm the doors are locked. NOTE: Control of power door locks is optional. Extra parts and labor may be necessary to interface with power door locks.
  • Page 49 Since its inception, Directed Electronics, Inc. has had one purpose, to provide consumers with the Vista, CA 92083 finest vehicle security and car stereo products www.directed.com and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, Directed Electronics, Inc.
