Front Components

Ref Component
Top Cover
Latch
Mini IEEE
1394a Port
Audio Output
Connector
Audio Input
Connector
Microphone
Connector
Card Reader
Getting Started
Description
Locks the top cover.
Connects a 1394 device such as a scanner,
printer, DVCAM, VCR, and more.
Connects a set of headphones, external speakers
with amplifier, an audio recording device, or an
S/P-DIF device such as a digital speaker set for
digital audio output.
Connects a Hi-Fi set, radio, synthesizer,
walkman, etc.
Connects an external microphone.
Accepts a MultiMediaCard (MMC), Secure
Digital (SD), or Memory Stick (MS) card for
removable storage media.
See Also
P. 1-3
P. 4-6
P. 2-20
P. 2-20
P. 2-19
P. 4-9
1-9
