  • Page 3 Copyright 2004 All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual may cause harmful interference to radio communications.
  • Page 5 There is no internal power supply. This Class B digital apparatus meets all requirements of the Canadian Interference - Causing Equipment Regulations. Cet appareil numerique de la classe B repecte toutes les exigences du Règlement sur le matèriel brouilleur du Canada.
  • Page 6 Page intentionally left blank...

  • Page 7: Table Of Contents

    Chapter 1: Before you Start --------------------------------------------------------------------------------- 7 Conventions of This Manual.......................... 7 Things you must remember before working on your computer ..............14 Chapter 2: Introduction --------------------------------------------------------------------------------------- 17 Welcome to the Notebook PC........................18 Getting to Know Your Computer........................18 Chapter 3: Getting Started ----------------------------------------------------------------------------------- 31 Connecting to a Power Source ........................
  • Page 8 Launching Submenus............................. 60 General Help ..............................60 The Main Menu ............................. 61 The Advanced Menu............................62 The Security Menu............................63 The Boot Menu .............................. 64 The Exit Menu ............................... 65 Chapter 7: The Software Utilities Disks ----------------------------------------------------------------- 67 AutoRun Installation............................67 VGA Utilities..............................

  • Page 9: Chapter 1: Before You Start

    Conventions of This Manual Use this manual will help you get the most from your notebook computer. • If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories.
  • Page 10 Whether or not you are an experienced user, you should consult on the Troubleshooting Chapter if you encounter any problems with your notebook. The check mark symbol indicates that you should take note on every detailed information when you encounter some function that might be useful when you are using your notebook.
  • Page 11 Make sure to use the right voltage for the power source when connecting the equipment to the power outlet. Place the power cord in such a way that people can not step on it. Do not place anything on top of the power cord. All cautions and warnings on the equipment should be noted.
  • Page 12 selection. • The cord set must be approved for the country in which it is used. • The appliance coupler must have a configuration for mating with a CEE22/EN6032/IEC 320 appliance inlet. For U.S. and Canada: • The cord set must be UL Listed and CSA Certified. •...
  • Page 13 into the AC adapter. Laser Warning: Laser Class I Product Caution - Invisible laser radiation when open avoid exposure to beam. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.
  • Page 14 das Gerät gelangen. Dies könne einen Brand bzw. Elektrischen Schlag auslösen. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen der elektrischen Sicherheit nur von authorisiertem Servicepersonal geöffnet werden. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer qualifizierten Servicestelle zu Überprüfung.: Netzlabel oder Netzstecker sind beschädigt.
  • Page 15 • Das Kabel-Set muss UL-gelistet und CSA zertifiziert sein. • Die Minimalanforderungen für das Kabel entsprechen No. 18 AWG. Für Japan: • Alle Teile des Kabel-Sets müssen entsprechend dem japanischen Dentori Law mit einem „PSE“ or „T”-Symbol markiert sein • Die Minimalanforderungen für das Kabel sind .75m ㎡...

  • Page 16: Things You Must Remember Before Working On Your Computer

    Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß ersetzt wird. Ersetzen Sie den Akku nur durch einen Akku gleichen oder äquivalenten Typs, der vom Hersteller empfohlen wird. Entsorgen Sie Akkus entsprechend den Anweisungen des Herstellers. Entfernen Sie den Akku auf keinen Fall bei eingeschaltetem Notebook, da hierdurch Daten verloren gehen könnten.
  • Page 17 Suitable place to work Your computer will run well wherever you’re comfortable but extremes of temperature and humidity can be challenging to your system’s parts. There are some things you can tolerate that the computer can’t – things like static electricity, dust, water, steam and oil.
  • Page 18 Page intentionally left blank...

  • Page 19: Chapter 2: Introduction

    There are more and more people spending large amounts of time in front of computer monitors now that scientists from many fields including anatomy, psychology, and occupational safety are involved in the study of ergonomically sound work environments. A few tips to help you work effectively without a lot of physical discomfort: •...

  • Page 20: Welcome To The Notebook Pc

    • Try to place the LCD panel or external monitor so that there is little glare from the sun on the monitor. • Walk around the room every hour. • Every half hour look away from the computer screen for a few minutes. •...
  • Page 21 Slide the display panel latch to the right until the display panel releases, and then raise the LCD screen. At any time you can tilt the display toward or away from you to a comfortable viewing position. To avoid damage to the display panel: 1.
  • Page 22 Each of these features is briefly described below.
  • Page 23 LCD Cover Release Latch Slide this latch to the right to open the LCD cover. LCD Screen Your Notebook computer is equipped with a replaceable color Liquid Crystal Display (LCD) screen that supports up to 1400 x 1050 resolution. A built-in backlight allows you to comfortably view the screen even when ambient lighting is low.
  • Page 24 Power/Resume Button Pressing this button for 1-2 seconds will turn on the system or pressing this button when the computer is in Suspend mode will resume normal operation. Pressing this button for 4-6 seconds will also turn off the system. TouchPad The TouchPad is hardware-compatible with the IBM PS/2 mouse and software- compatible with the Microsoft mouse.
  • Page 25 The Left Side Ventilation Opening Please don’t block this opening during operation of the system. 1394A A very fast external bus standard that supports data transfer rates of up to 400 Mbps (400 million bits per second).
  • Page 26 Can be used to connect up 63 external devices, also supports isochronous data -- delivering data at a guaranteed rate. This makes it ideal for devices that need to transfer high levels of data in real-time, such as video devices. Also supports both Plug-and-Play and hot plugging, and also provides power to peripheral devices.
  • Page 27 Audio Line Out Jack You can plug an external speaker, headphone or connect the line out jack to an audio device such as a cassette recorder to record the notebook's audio output. These three LED indicators are separately program for the following functions: Power On, Suspend Mode and Battery Charge.
  • Page 28 Battery Charge This indicator will lit green when the battery is in charging status. When the indicator light turns off, it indicates the system is in full charge. Suspend Mode This indicator will lit when the notebook enter the suspend mode. The Right Side...
  • Page 29 The CD-ROM/DVD-ROM or DVD CD-RW Combo (Option) Your Notebook comes with a swappable 24X (or higher) 5.25" IDE CD-ROM/DVD- ROM/Combo Drive (DVD-ROM+CD-RW), DVD-RW, DVD+RW, DVD-Dual. DC IN Connector Plug the AC adapter into this connector. The Rear...
  • Page 30 Ventilation Opening Please don't block this opening during operation of the system. Kensington Lock Allows you to connect a special computer lock to secure your system. You can purchase a lock at most computer retailers. S-Video Port Allows you to connect any S-Video ready television to your system. You can display output simultaneously on both the LCD and the television or toggle between the two screens.
  • Page 31 It will eventually replace the need for separate connectors for external keyboards, serial ports, and parallel (printer) port. The Bottom Panel MiniPCI/Wireless LAN/Modem Combo Compartment (Option) This compartment can be used to extend the capabilities of your system by providing a connection with various extension card.
  • Page 32 Battery Release Latch Lift up this latch to release the battery from its bay. Battery Your notebook comes equipped with a factory-installed battery pack module. After the battery runs down, the module can be removed and replaced with a charged battery.

  • Page 33: Chapter 3: Getting Started

    Connecting to a Power Source Connecting the AC Adapter A universal AC adapter is provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country.
  • Page 34 The power cord for the AC adapter requires a three-hole grounded AC outlet. To connect the computer to an external power source: Plug the AC adapter’s connector into the DC-IN connector on the rear of the computer. Connect the power cord to the AC adapter and then to a wall outlet. The best kind of AC power source to connect your Notebook to is a UPS (Uninterruptible Power Supply).

  • Page 35: Turning On Your Notebook Computer

    Never turn off or reset your Notebook while the hard disk is in use and the HDD status icon is lit; doing so can result in loss or destruction of your data. Always wait at least 5 seconds after turning off your Notebook before turning it back on;...
  • Page 36 • The disk/CD-ROM drives run no more than 10% of the time. Only use batteries that are approved by an authorized dealer. All batteries are not the same and therefore should not be treated as such. Using the wrong battery could cause serious damage to your computer and yourself through toxic emissions.
  • Page 37 To remove the battery pack: Turn off the notebook, and disconnect the AC adapter. Close the LCD panel and turn it over and place it on a solid, flat surface. Lift the release latch to release the battery from the bay. At this time the battery will now be angled slightly out of the bay.
  • Page 38 Page intentionally left blank...

  • Page 39: Chapter 4: Using The Notebook Computer

    Adjusting the LCD Screen Display The LCD screen display can be adjusted by the following key combinations. KEYS FUNCTIONS [Fn] + [F7] Decreases the brightness level. [Fn] + [F8] Increases the brightness level. [Fn] + [F10] Use this key combination to expand your video screen or reset to its original size.
  • Page 40 Overlay mode (playing video). [Fn] + [F12] This key combination toggles the display between the LCD, CRT, simultaneous LCD/CRT, and TV only. This function will be disabled when the system is in Overlay (playing video) or Extended Desktop mode. LCD Care LCD screens are delicate devices that need careful handling.

  • Page 41: A Tour Of The Notebook's Keyboard

    A Tour of the Notebook’s Keyboard The Notebook’s keyboard uses a standard QWERTY layout with the addition of special function keys and an embedded numeric keypad for number intensive data entry. Your keyboard supports Windows by incorporating the two Windows specific keys.

  • Page 42: The Touchpad

    The Notebook’s Hot Key Controls KEYS FUNCTION(S) Power Button Press this button once to power on or enter the suspend/resume mode. Press this button for more than 4 seconds to power off the system. Internet Button Open Internet WWW Home short-cut key Email Button Open Email Reader short-cut key [Fn] + [F1]...
  • Page 43 can use the buttons below the touchpad as left and right mouse buttons. TouchPad Precautions The TouchPad is a pressure sensitive device. Please take note of the following precautions. • Make sure the TouchPad does not come into contact with dirt, liquids or grease. •...

  • Page 44: Connecting An External Tracking Devices

    applications. Connecting an External Tracking Devices The system will only enables you to use one tracking device whether it is an internal or external tracking device. Data Storage and Retrieval Data storage and retrieval are two of the most fundamental tasks you will perform when working with your computer.
  • Page 45 • Use a clean, dry, cloth to remove dust, smudges, or fingerprints. Wipe from the center outward. • Do not write or place objects on the surface of the disc. • Store discs in a cool dry place not to damage the disc. •...

  • Page 46: Pcmcia Cards And Expansion Sockets

    Do not insert any foreign objects into the disc tray. If you experience difficulty when ejecting the CD disk tray, stretch a paper clip (or use a pin or a thin metal rod) and insert it into the emergency eject hole located on the right side of the front panel.
  • Page 47 Inserting a PCMCIA Card The computer will emit a medium tone followed by a high tone when a PC card is inserted. When you eject a card, the computer will emit a high tone followed by a medium tone. You can insert and remove a PC card whether the computer is turned On or Off.

  • Page 48: Power Saving Modes

    Power Saving Modes This section contains information on the Notebook’s power system, including the AC Adapter, the battery system, recharging the battery, and tips for conserving battery power. The power system is comprised of two parts, the AC Adapter and the battery system. The AC Adapter converts AC power from a wall outlet to the DC power required by the computer.
  • Page 49 To calibrate the battery pack follows the instructions below: Insert the battery into the battery compartment and turn on the Notebook. If the battery is completely without power go to the next step. Otherwise, let the battery run down until the battery low-low warning beeps are heard.
  • Page 50 Battery Status Windows XP has an applet in the Control Panel that will display an icon in the Windows taskbar indicating when the Notebook is running on battery power or is attached to the AC adapter. This applet also displays a meter that indicates how much charge is remaining in the battery.
  • Page 51 Small Battery for the Real Time Clock There is a small built-in battery pack that supplies power to the system in order to maintain certain system information while the power is off. If the Notebook is left without a power source for long period of time, this battery will be exhausted and system information will be lost.
  • Page 52 Page intentionally left blank...

  • Page 53: Chapter 5: Desktop Operation

    Your notebook is capable of providing you with efficient and productive mobile computing, it also has the speed and capacity to service as a desktop system. This chapter discusses those functions of your notebook that are typical of desktop systems.

  • Page 54: Audio

    Audio The Multimedia Sound System The Notebook’s built-in audio capabilities allow you to take advantage of a wide range of education and entertainment multimedia software. The Notebook is equipped with internal stereo speakers, a microphone, and input audio ports for external audio units.

  • Page 55: Connecting Peripheral Devices

    Audio Software Your notebook comes equipped with an integrated sound system capable of providing you with quality audio sound through the built-in speakers or through external speakers connected via the system ports. Sound Recording Your system allows you to record sounds and store them as files using the microphone via the microphone jack on the rear of the notebook computer.
  • Page 56 The computer is equipped with several interface ports, including an enhanced parallel (printer) port, a serial port, and USB ports. These are provided as a means of connecting peripheral devices to the computer. Connect peripheral devices to the computer's interface ports as shown below:...
  • Page 58 Page intentionally left blank...

  • Page 59: Chapter 6: Running Bios Setup

    Introduction The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to reflect installed hardware or alter system performance. When the Notebook is turned back on, the system is configured with the values stored in CMOS.

  • Page 60: Navigating Through Bios Setup

    • Bootup Drive Sequence • Password protection The settings made in the BIOS Setup program intimately affect how the Notebook performs. Navigating through BIOS Setup The Setup program has been designed to make it as easy to use as possible. If you accidentally make a setting and don’t know which one to switch back to, the Setup program has a hot key that allows you to return to the previous value.

  • Page 61: The Legend Bar

    Security - Use this menu to set a password. The password allows bootup and controls access to the BIOS setup menu. Boot - Use this menu to configure the default system device used to locate and load the Operating System and for booting up the Notebook. Exit - Use this menu to exit the current menu or specify how to exit the Setup program.

  • Page 62: Launching Submenus

    Scrolls backward through the values for the Minus key ( highlighted field. Plus key (+) Scrolls forward through the values for the highlighted field. Home PgUp Moves the cursor to the field at the top of the window. PgDn Moves the cursor to the field at the bottom of the window.

  • Page 63: The Main Menu

    Use the [PgUp] and [PgDn] keys or the up and down arrow keys (↑↓) to scroll through the entire help document. Press the Home key to display the first page, press End to go to the last page. To exit the help window, press the [Enter] or the [Esc] key.

  • Page 64: The Advanced Menu

    The Advanced Menu Selecting Advanced from the menu bar displays the Advanced menu:...

  • Page 65: The Security Menu

    The Security Menu The Notebook’s advanced system of security allows you to set a password to prevent unauthorized access to system resources, data, and the BIOS Setup Program.

  • Page 66: The Boot Menu

    The Boot Menu The Boot menu allows the user to specify the order in which the Notebook is to check for a device to boot the system. You can also configure the way that the system will boot up. To make changes, select Boot from the menu bar. The following screen appears:...

  • Page 67: The Exit Menu

    The Exit Menu Once you have made all of your selections from the various menus in the Setup program, you should save your changes and exit Setup. Select Exit from the menu bar to display the following menu:...
  • Page 68 Page intentionally left blank...

  • Page 69: Chapter 7: The Software Utilities Disks

    AutoRun Installation Follow the step-by-step procedures on the CD-ROM/DVD-ROM to execute the “AutoRun” application by selecting the topic of “Driver Installation”. If you encounter this message when executing the Auto Run in...
  • Page 70 Windows 2000, please perform the following procedures: Click on the “Start” – “Setting” – “Control Panel” – “System” – “Advanced” tab – “Performance” tab – “Change” tab – reduce the maximum Virtual Memory setting to 200MB. Installing the INTEL_INFINST Driver •...
  • Page 71 • Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive. • Click “Start” and Select “Run”. • Type the following: D:\Driver\Audio\Setup.exe (If D is not your CD-ROM/DVD- ROM drive, substitute D with the correct drive letter). • Click on “Setup” to begin the Installation Wizard. •...
  • Page 72 Installing the TouchPad Driver To install the touchpad driver you must first remove the currently installed driver. • Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive. • Click “Start” and Select “Run”. • Type the following: D:\Driver\Touchpad\Win2K&XP\Setup.exe (If D is not your CD-ROM/DVD- ROM drive, substitute D with the correct drive letter).
  • Page 73 • From Start, click on the "My Computer" icon and click the "View System Information". • Click on the "Hardware" tab from the "System Properties" dialog window. • Click the "Device Manager" button. • Double click on the "Other Devices" , double click the " Network Controller " and click on the "Driver"...

  • Page 74: Vga Utilities

    VGA Utilities After you have restarted Windows, open the “Control Panel” and double click on the “Display” icon. From the “Display Properties” window, select the “Settings” tab and click on the “Advanced” tab to enter the “INTEL® 82852/82855 GM/GME Graphics Controller Properties"...
  • Page 79 Color You can adjust the right resolution for your screen display.
  • Page 80 Schemes...
  • Page 81 Hot Keys...
  • Page 82 OpenGL...
  • Page 83 Page intentionally left blank...

  • Page 84: Chapter 8: Troubleshooting

    This chapter describes locating and solving problems that you may encounter while using your computer. Locating a Problem Problems with your computer can be caused by something as minor as an unplugged power cord – or as major as a damaged hard disk. The information in this chapter is designed to help you find and solve minor problems.

  • Page 85: Checking Cables And Connections

    correct the problem and contact your dealer. Successful troubleshooting is the result of careful observation, deductive reasoning, and an organized approach to solving the problem. The problems that you will encounter can be divided into two basic categories: hardware problems and software problems. Hardware problems can be further divided into electrical and mechanical problems.

  • Page 86: The Power-On Self Test

    Check the wall outlet or power strip with an item that you know is functioning properly. A lamp or radio is a convenient item for checking the power. You may also need to check the fuses and breakers in your electric box.

  • Page 87: General Hardware Problems

    Two classifications of malfunctions can be detected during the POST: • Error messages that indicate a failure with either the hardware, the software, or the Basic Input/Output System (BIOS). These critical malfunctions prevent the computer from operating at all or could cause incorrect and apparent results. An example of a critical error is microprocessor malfunction.
  • Page 88 Make sure that the computer is not in Suspend mode. Check the Brightness Solution: controls for the screen. If the controls are turned too far down, the screen will be dark. An incorrect date and time are displayed. Problem: Correct the date and time using the DOS DATE and TIME commands or the Solution: options in the Setup Utility.

  • Page 89: Contacting Your Dealer

    Check the printer cable connection. Ensure that the printer power switch is Solution: turned on. Confirm that the printer is on-line. You can’t save data to disk. Problem: Ensure that the disk has been formatted. Solution: Consult your operating system manual for information on formatting floppy diskettes. The diskette is write-protected.
  • Page 90 • How is your computer configured? Your dealer needs to know what peripheral devices you are using. • What messages, if any, are on the screen? • What software were you running at the time? • What have you done already to try to solve the problem? If you have overlooked a step, your dealer may be able to solve the problem over the phone.
  • Page 91 Page intentionally left blank...

  • Page 92: Chapter 9: Upgrading Your System

    Upgrading your Memory Refer to the following instructions and illustration for information on upgrading your notebook's memory. Turn off the computer and disconnect the AC adapter and all peripherals. Turn the notebook over so that the rear ports are facing you and locate the memory module compartment.
  • Page 93 aside in a safe place. Remove the compartment cover and then angling it up and out. If you need to install a higher capacity module, gently push the edge clips on both sides to release the module. Angle the card slightly upward and gently slide it from its edge connector slot.

  • Page 94: The Easy To Upgrade Hdd Module

    The Easy to Upgrade HDD Module The hard drive in your notebook computer is made to be easily swapped out for upgrading. You should back up your hard drive before attempting o change the hard drive. Make sure that before you install a new drive, all the files in your system should be backed up.

  • Page 95: Upgrading Your System Cpu

    Power down the system completely. Turn the system over with the front of the unit facing you. Remove the three screws that secure the compartment cover and set them in a safe place. Slide the HDD cover away from the compartment. The drive is attached to a special bracket that secures it to the notebook computer.
  • Page 96 Remove the screen that is attached to the keyboard in order to remove the heatsink on top of the CPU. Remove all the screws attached to the heatsink.
  • Page 97 Before removing the screws, there are certain measures to followed in removing the heatsink To remove the heatsink, first loosen the screw carefully. After loosening one screw, be certain that the next to be loosen should be the screw on its adjacent side as shown on the illustration. Be sure to loosen all the screws first before removing it totally to release the heatsink.

  • Page 98: Appendix A: Specification

    Detailed Notebook Specifications General • Intel Pentium-M Banias processor from 1.3GHz to 1.7GHz, 1M L2 cache • Intel Dothan processor from 1.8GHz to 2.0GHz, 2M L2 cache...
  • Page 99 • 478 pin uFC-PGA2 478 socket, CPU front-side bus up to 400MHz • TDP : 21W. • Intel 855GM/GME, • Support FSB 400MHz Memory • 2 expandable memory slot up to 2GB,1GB per DIMM Max. with 512Mb technology • 128/256/512 MB memory options •...
  • Page 100 • Supports CD-ROM/DVD-ROM/Combo Drive (DVD-ROM+CD-RW), DVD-RW, DVD+RW, DVD-Dual; 5.25” 12.7mm height • Fast IDE and ATAPI interface CD-ROM/DVD-ROM/Combo Drive (DVD- ROM+CD-RW), DVD-RW, DVD+RW, DVD-Dual • Synaptics TouchPad • Support four way scrolling feature • US/Europe, DOS/V keyboard for Japan, full size keyboard alike pitch •...
  • Page 101 • Dual full-duplex Direct Sound Channels • Hardware SoundBlaster Pro for real-mode DOS legacy compatibility • 18-bit ADC & DAC resolution • Support S/PDIF out • AC’97 2.2 & PC2001 compliant I/O Ports • One parallel port supported EPP/ECP (25-pin female D-connector) •...
  • Page 102 • Integrated IEEE 1394a OHCI-link & two ports with IEEE 1394 internal PHY • Data transfer rate : 100/200/400 Mbps Graphics and Video • Intel 855GM/GME internal graphics • High performance 3D graphics engine (floating triangle setup/rendering) • Up to 64 MB of dynamic video memory allocation •...
  • Page 103 • 4 hrs charge time while system on • Charging time for one battery pack : 3.5 hours to full charge when system off or in suspend • More than 2.0 hrs w/ 4-cell battery, 4.0 hrs w/ 8-cell battery Dimensions •...
  • Page 104 • Factory Option : 802.11b wireless LAN with MiniPCI slot • Memory Extension Card • Module bay : CD-ROM/ DVD-ROM/ Combo(DVD-ROM+CD-RW) Drive, DVD- RW, DVD+RW, DVD-Dual • Bootable external USB FDD Accessories • User‘s Manual & Driver CD title • AC Adapter •...
