Specifications
NOTE: Specifications are subject to change without any prior notice.
Parts
CPU
Cache Memory
ROM BIOS
RAM System
Shared video
Display Panel
Video controller
Video ports
Keyboard
Pointing device
Storage Floppy disk drive
device (external)
Hard disk drive
Optical drive
Audio ports
PC card
Card Reader
I/O ports
Modem
Specifications
Intel Mobile Pentium-M processor supporting 1.5 ~ 1.7 GHz or
Intel Dothan 1.8 GHz or above; 35 W thermal specifications
1 MB on-die for Intel Mobile Pentium-M
2 MB on-die for Intel Dothan
512 KB Flash EEPROM (includes system and VGA BIOS),
Plug-and-Play capability
2 × 200-pin DDR SO-DIMM socket for expansion, up to 1024 MB;
supports DDR266/333 specifications
8/16/32 MB (default 32 MB) when video controller is integrated in
NorthBridge or
64/128 MB (Discrete VRAM) for Ati M10/M11 video controller
15.4-inch TFT, resolution up to 1280×800 WXGA,
16.77 million colors with dithering
Integrated in NorthBridge or Ati M10/M11
VGA port, S-video connector
Standard keys, numeric keypad, 12 function keys, a special Fn
(Function) key and Windows keys
Touchpad
3.5-inch, 1.44 MB, USB (optional)
2.5-inch, 9.5 mm high, IDE, Ultra DMA 100 support
DVD-ROM / DVD-RW / Combo
Three audio ports for Mic-in / Line-out (S/P-DIF) / Line-in
Type II x 1, CardBus support
3-in-1 (MMC/SD/MS card) module
Three USB ports (USB 2.0 support), mini IEEE 1394a port
56 Kbps V.90 MDC internal fax modem
