COMPLETE PARTS LIST
Item No.
49 Belt 550 J6
50 Tool storage cover
51 Plastic flat round cap
52 Pedals
53 Pedal bracket
54 Adjustable foot
55 Small square plastic cap
56 End cap (T-Bar)
57 Rear cover left
58 Rear cover right
59 Outer rear cover left
60 Outer rear cover right
61 Screw M3*10mm
62 Motor
D- Axle ∮15**182mm
63
Magnet ∮14.8*7L
64
65 Washer 5/16*16*1.0
66 Pulley
67A Base frame
67B Main frame
68 Upright tube
69 Swivel tube, LH
70 Swivel tube, RH
71 Fixed handle bar
72 Handle bar, LH
73 Handle bar, RH
74A Left pedal arm front
74B Left pedal arm rear
75A Right pedal arm front
75B Right pedal arm rear
76 Front foot ( Stabilizer )
77 Rear foot ( Stabilizer )
78 Flywheel holder bracket
79 Belt tensioner
80 Metal cross, LH
81 Metal cross, RH
82 NY lock nut M12
83 Retainer R12
84 Metal plate
Roller axle ∮12**103mm
85
86 Connecting tube
87 Left decorative cover
88 Right decorative cover
89 Console cable 990MM
90A Cable 1300MM
Description
www.smoothfitness.com
Qty.
1 CE90-49
1 CE90-50
2 CE90-51
2 CE90-52
2 CE90-53
2 CE90-54
2 CE90-55
2 CE90-56
1 CE90-57
1 CE90-58
1 CE90-59
1 CE90-60
1 CE90-61
1 CE90-62
1 CE90-63
1 CE90-64
4 CE90-65
2 CE90-66
1 CE90-67A
1 CE90-67B
1 CE90-68
1 CE90-69
1 CE90-70
1 CE90-71
1 CE90-72
1 CE90-73
1 CE90-74A
1 CE90-74B
1 CE90-75A
1 CE90-75B
1 CE90-76
1 CE90-77
1 CE90-78
1 CE90-79
1 CE90-80
1 CE90-81
6 CE90-82
2 CE90-83
2 CE90-84
2 CE90-85
2 CE90-86
1 CE90-87
1 CE90-88
1 CE90-89
1 CE90-90A
9
Part No.
