Summary of Contents for Skoda Yeti

  • Page 1 SIMPLY CLEVER ŠKODA Yeti OWNER'S MANUAL...
  • Page 3 Introduction You have opted for a ŠKODA – our sincere thanks for your confidence in us. Your new ŠKODA offers you a vehicle featuring the most modern engineering and a wide range of equipment which you will undoubtedly wish to use to the full during your daily motoring. That is why, we recommend that you read this Owner's Manual attentively to enable you to become familiar with your car and all that it offers as quickly as possible.
  • Page 4 Introduction On-board literature The other chapters of the Owner's Manual are also important, however, for proper treatment of your car - in addition to regular care and main- The on-board literature for your vehicle consists of this “Owner's Man- tenance - helps to retain its value and in many cases is also one of the ual”...
  • Page 5: Table Of Contents

    Table of Contents Table of Contents Layout of this Owner's Manual Seats and Stowage Starting-off and Driving ....... . .
  • Page 6 Table of Contents Head airbags ........Fuel Fuel consumption according to the ECE standards and .
  • Page 7: Table Of Contents

    Table of Contents Using the system Safety Driving Tips General Maintenance Breakdown assistance Technical data...
  • Page 8: Layout Of This Owner's Manual (Explanations)

    Layout of this Owner's Manual (explanations) Layout of this Owner's Manual (explanations) The Owner's Manual has been systematically designed, in order to make it easy WARNING for you to find and absorb the information you require. The most important notes are marked with the heading WARNING. These Chapters, table of contents and subject index WARNING notes draw your attention to a serious risk of accident or injury.
  • Page 9 Layout of this Owner's Manual (explanations) Using the system Safety Driving Tips General Maintenance Breakdown assistance Technical data...
  • Page 10 Cockpit Fig. 1 Cockpit...
  • Page 11: Using The System

    Cockpit Using the system Cockpit Overview Fuse box (on side of dash panel) ........Light switch .
  • Page 12: Instruments And Warning Lights

    Instruments and warning lights Instruments and warning lights General information WARNING ● Pay attention primarily to the traffic situation! As the driver you are fully responsible for road safety. ● Operate the controls in the instrument cluster never while driving, only when the vehicle is stationary! ...
  • Page 13: Engine Revolutions Counter

    Instruments and warning lights Coolant temperature gauge ⇒  p age 11 Note Display This function is only valid for some countries.  – with counter for distance driven ⇒  p age 12 – with Service Interval Display ⇒  p age 12 Coolant temperature gauge –...
  • Page 14: Counter For Distance Driven

    The counter for distance driven indicates the total distance in kilometers or miles The following is displayed in the information display: which the vehicle has been driven. Service after ... km or... days. £ Valid for Yeti 4x4...
  • Page 15: Digital Clock

    Instruments and warning lights The kilometre indicator or the days indicator reduces in steps of 100 km. or days Note until the service due date is reached. ● Never reset the display between service intervals otherwise this may result in incorrect readouts.
  • Page 16: Shift Recommendation For Changing Gears

    Instruments and warning lights Shift recommendation for changing gears ⇒  p age 16 Distance driven ⇒  p age 17 Average speed ⇒  p age 17 Current speed ⇒  p age 17 Oil temperature ⇒  p age 17 Warning against excessive speeds On vehicles which are fitted out with information display, it is possible to switch off the display of some information.
  • Page 17: Outside Temperature

    Instruments and warning lights ⇒  f ig. 6 ⇒  f ig. 6 Switching over the memory with the help of the button on the wind- The rocker switch and the button are located on the windshield screen wiper lever or with the help of the button on the multifunction steering wiper lever.
  • Page 18: Distance Driven

    Instruments and warning lights If the outside temperature drops below +4 °C, a snow flake symbol (warning signal If you wish to determine the average fuel consumption over a certain period of for ice on the road) appears before the temperature indicator and a warning signal time you must set the memory to zero at the start of the measurement using the ⇒ ...
  • Page 19 Instruments and warning lights Average speed Adjust the speed limit while the vehicle is moving – With the button on the multi-function windshield wiper lever or the hand- wheel on the multi-function steering wheel, choose the menu point Warn- The average speed since the memory was last erased is shown in the display in km/hour ⇒ ...
  • Page 20: Maxi Dot Display (Information Display)

    Instruments and warning lights MAXI DOT display (information display) Main menu Introduction The information display provides you with information in a convenient way con- cerning the current operating state of your vehicle. The information system also provides you with data (depending on the equipment installed in the vehicle) re- lating to the radio, mobile phone, multi-functional indicator, radio navigation sys- tem, the unit connected to the MDI input and the automatic gearbox.
  • Page 21: Auto Check Control

    Instruments and warning lights Vehicle status ⇒  p age 19 Auto Check Control ■ Settings ⇒  p age 20 ■ Car state The menu point Audio is only then displayed when the factory-fitted car radio is switched on. The Auto Check Control carries out a check of certain functions and vehicle com- The menu point Navigation is only then displayed when the factory-fitted radio ponents.
  • Page 22 Instruments and warning lights Units ■  ⇒  p age 25 Engine oil pressure too low Assistants ■ Alternative speed displayed (Second speed) ■ Overheated clutches of the automatic  ⇒  p age 30 gearbox DSG ■ Service Interval ■ Factory setting Three successive warning signals will sound if a red symbol appears.
  • Page 23 Instruments and warning lights Lights and Visibility When exceeding the speed, an indication is displayed on the information display: Here you can activate, deactivate or adjust the following functions: Winter tyres max. speed ... km/h Coming Home Switch on/off and adjust the light duration of the Com- Measures ing Home function.
  • Page 24: Warning Lights

    Instruments and warning lights Warning lights Overview The warning lights indicate certain functions or faults. Fig. 8 Instrument cluster with warning lights  ⇒  p age 23  ⇒  p age 24 Turn signal lights (to the left) Failure of the light bulbs ...
  • Page 25 Instruments and warning lights WARNING  ⇒  p age 26 EPC fault light (petrol engine) ● If you do not pay attention to the warning lights coming on and the corre-  ⇒  p age 26 Glow plug system (diesel engine) sponding descriptions and warning notes, this may result in severe injuries or major vehicle damage.
  • Page 26 Instruments and warning lights Low beam trol unit shifts the engine into the emergency mode, which only has a reduced  power output. After switching the ignition off and on again the warning light  comes on. comes on when low beam is selected ⇒  p age 45. The indicator light ...
  • Page 27 Instruments and warning lights Airbag/belt tensioner deactivated WARNING The following situation applies if the airbag has been switched off using the Contact your specialist garage if the power steering is defective. switch for the airbag in the front passenger storage compartment: ●...
  • Page 28 Instruments and warning lights The following text will be displayed in the information display: Glow plug system (diesel engine)  Check oil level! The warning light lights up for a cold engine when switching on the ignition  The warning light will go out if the bonnet is left open for more than 30 seconds. (pre-heat position) 2 ⇒ ...
  • Page 29 Instruments and warning lights Do not continue driving if the warning light does not go off although the fluid is Anti-spin regulation (ASR)  at the correct level and also the fuse of the fan is in proper order. Contact a spe- cialist garage to obtain assistance.
  • Page 30 Instruments and warning lights Tyre inflation pressure A fault in the entire brake system  If the ABS warning light comes on together with the brake system warning  light (handbrake must be released), there is a fault not only in the ABS but also The warning light lights up, if there is a substantial drop in inflation pressure in ...
  • Page 31 Instruments and warning lights An audible signal sounds as an additional warning signal. An audible signal sounds three times as an additional warning signal. The warning light comes on even when the ignition is switched off. The warning One should get used to high pedal forces, long braking distances and long free light lights up for a maximum of 5 minutes.
  • Page 32: Fuel Reserve

    Instruments and warning lights Fuel reserve  WARNING If you must stop for technical reasons, then park the vehicle at a safe distance The warning light comes on, if the fuel level is still below 10.5 litres.  from the traffic and switch off the engine and switch on the hazard warning An audible signal sounds as an additional warning signal.
  • Page 33: Locking And Unlocking

    Locking and Unlocking Locking and Unlocking Vehicle key Note Please approach an authorised ŠKODA Service Partner if you lose a key since he can obtain a new one for you. Description  Changing the battery in the remote control key Fig.
  • Page 34: Child Safety Lock

    Locking and Unlocking Child safety lock For the sake of the environment Dispose of a used battery in accordance with environmental regulations. The child safety lock prevents the rear door from being opened Note from the inside. ● Pay attention to the correct polarity when changing the battery. ●...
  • Page 35: Central Locking System

    Locking and Unlocking Central locking system Unlocking a vehicle side door This selection function enables to unlock both doors on the driver's side. The oth- er doors and the fuel filler flap remain locked and are only unlocked after repeti- Description tive unlocking.
  • Page 36: Safe Securing

    Locking and Unlocking Safe securing Unlocking the vehicle using the key The central locking system is equipped with a safe securing system. Locking the vehicle from the outside causes the door locks to be automatically blocked. The warning light flashes for around 2 seconds in quick succession, afterwards it be- gins to flash evenly at longer intervals.
  • Page 37: Button For The Central Locking System

    Locking and Unlocking ● The windows and the electric sliding/tilting roof close while the key is held in ● As long as one door is opened , the vehicle cannot be locked in order to avoid the lock position. inadvertently locking the key in the vehicle. ●...
  • Page 38 Locking and Unlocking Insert the key into the slot and turn it into the horizontal position in the – WARNING direction of the arrow (mirror-inverted on the right doors). ● Ensure that the lock is properly engaged after closing the boot lid. Other- –...
  • Page 39: Remote Control

    Locking and Unlocking Remote control Unlocking and locking car Description You can use the remote control key: ● to unlock and lock the car, ● unlocking boot lid, ● electrically open and close the windows. The transmitter with the battery is housed in the handle of the remote control key.
  • Page 40: Synchonisation Of The Remote Control

    Locking and Unlocking Display of the locking Anti-theft alarm system The turn signal lights flash once to confirm that the vehicle has been correctly locked. Description If the vehicle is locked by pressing the button and some doors or the boot lid are not closed, the turn signal lights flash only after closing.
  • Page 41: Power Windows

    Locking and Unlocking Note Note ● The working life of the alarm siren is 6 years. More detailed information is ● You can switch the interior monitor and the towing protection monitoring off if available by a specialist garage. there is a possibility that movements from (e.g. children or animals) inside the ve- hicle interior or if the vehicle must be transported (e.g.
  • Page 42 Locking and Unlocking Closing a window CAUTION – A window is closed through pulling lightly on the respective button in the ● Keep the window glass clean to ensure correct function of the electric win- door. The closing process stops when one releases the button. dows.
  • Page 43 Locking and Unlocking Closing a window WARNING – Lightly press the appropriate button up and hold it until the window has You should take particular care when closing the windows! You may otherwise moved into the desired position. suffer severe injuries as a result of getting an arm, for example, jammed in the Additionally you can close the window automatically (fully closed) by pressing –...
  • Page 44: Panoramic Sliding Roof

    Locking and Unlocking Operational faults Panoramic sliding roof Automatically operated power windows do not operate Introduction If the battery of the car has been disconnected and then reconnected, the auto- matically operated power windows do not operate. The system must be activated. The panoramic sliding roof with sun screen can only be operated with the control ⇒ ...
  • Page 45: Closing The Panoramic Sliding Roof

    Locking and Unlocking When the panoramic sliding roof is in the comfort position, the intensity of the Opening wind noise is reduced. ⇒  f ig. 22 – Briefly press the button in order to fully open. – Press the button and hold it pressed in order to open in the desired posi- CAUTION tion.
  • Page 46 Locking and Unlocking Emergency operation After initialising the panoramic sliding roof, press down the switch on the recess and push it forwards for approx. 10 seconds. ⇒  f ig. 22 Press the switch for approx. 10 seconds in order to initialise the sun screen.
  • Page 47: Lights And Visibility

    Lights and Visibility Lights and Visibility Lights WARNING Never drive with only the side lights on - risk of accident! The side lights are Switching lights on and off  not bright enough to light up the road sufficiently in front of you or to be seen by other oncoming traffic.
  • Page 48: Automatic Driving Lamp Control

    Lights and Visibility Deactivating the function daylight driving lights Switching off automatic driving lamp control – Pull the turn signal light lever towards the steering wheel within 3 seconds af- – Turn the light switch to the position 0,  or . ter switching on the ignition and at the same time, slide it down and hold it in If the light switch is in the position , the symbol illuminates when the ignition this position for at least 3 seconds.
  • Page 49: Parking Light

    Lights and Visibility Coming Home Function Note ● Do not affix any stickers in front of the light sensor, so that you do not impair The function makes it possible to switch on the lights in the darkness for a short its function or put it out of operation.
  • Page 50 Lights and Visibility Leaving Home Function Tourist light This function makes it possible to switch on the lights when approaching the ve- Xenon headlight hicle. This mode makes it possible to drive in countries with opposing traffic system, driving on the left/right, without dazzling the oncoming vehicles. When the mode Switching on Leaving Home Function “tourist light”...
  • Page 51: Instrument Lighting

    Lights and Visibility The warning light lights up in the instrument cluster when the fog lights are The rear fog light is located in the rear light array on the driver's side.  switched on ⇒  p age 22.  CAUTION The rear fog light should only be switched on if visibility is particularly poor (con- Fog lights with the function “CORNER”...
  • Page 52 Lights and Visibility Headlamp range adjustment  Switch for hazard warning lights  Once the low beam is switched on you can then adapt the range of the headlights to the load of the vehicle. Fig. 29 Dash panel: Switch for hazard warning lights ⇒ ...
  • Page 53 Lights and Visibility The turn signal and main beam lever Information concerning the function of the lights.    ● The turn signal system only operates when the ignition is switched on. The The parking lights and headlight flasher are also switched on and corresponding warning light in the instrument cluster also flashes.
  • Page 54: Interior Lighting

    Lights and Visibility Interior lighting If operating lights with the door contact switch is enabled, the light will come on when: Vehicle interior lighting front and rear ● the vehicle is unlocked, ● one of the doors is opened, ● or the ignition key is removed. If operating lights with the door contact switch is enabled, the light will go off when: ●...
  • Page 55: Visibility

    Lights and Visibility Switching on the interior lighting WARNING ⇒  f ig. – Press the cover glass in the area of the symbol  If the entry light comes on, do not touch its cover - risk of burns!  Switching off the interior lighting Press the cover glass in the area of the symbol O.
  • Page 56: Windshield Wiper And Wash System

    Lights and Visibility Windshield wiper and wash system For the sake of the environment As soon as the window is de-iced or free from mist, the heating should be switch- ed off. The reduced current consumption will have a favourable effect on fuel Windshield wiper economy ⇒ ...
  • Page 57 Lights and Visibility Automatic wipe/wash for windscreen The windscreen wipers and the wash system only operate if the ignition is switch- ed on and the bonnet is closed – Pull the lever towards the steering wheel into sprung position , the wash system sprays immediately, the windscreen wiper starts wiping a little later.
  • Page 58 Lights and Visibility Activation/deactivation CAUTION ● In cold temperatures and in winter, check before the trip or before switching The function of the automatic rear window wiper is activated/deactivated in the on the ignition that the wiper blades are not frozen. Switching on windscreen information display in the menu: wipers when the blades are frozen to the windscreen may result in damage both Settings...
  • Page 59 Lights and Visibility The wiper arms move back into the rest position - after switching on the ignition CAUTION and after changing the position of the window wiper lever or when driving at a Never remove the nozzles from the headlamp cleaning system by hand - risk of speed greater than 6°km/h.
  • Page 60: Rear-View Mirror

    Lights and Visibility With the other hand unlock the locking button and remove the wiper blade If the automatic dimming is switched on, the mirror dims automatically depending – in the direction of arrow on the light striking the mirror from the rear. The mirror has no lever on the bot- tom edge of the mirror.
  • Page 61: Using The System Safety

    Lights and Visibility The exterior mirror heater only operates when the engine is running and up to an WARNING outside temperature of +20 °C. ● Convex (curved outward) or a spherical exterior mirrors increase the vision Adjusting left and right exterior mirrors simultaneously field.
  • Page 62 Lights and Visibility Note ● Automatic mirror dimming operates only properly if the light striking the rear of the interior rear-view mirror is not affected by other objects. ● Do not affix any stickers in front of the light sensor, so that you do not impair the automatic dimming function or put it out of operation.
  • Page 63: Seats And Stowage

    Seats and Stowage Seats and Stowage Front seats WARNING (Continued) ● Ensure that there are no objects in the footwell as any objects may get be- Basic information hind the pedals during a driving or braking manoeuvre. You would then no longer be able to operate the clutch, to brake or accelerate.
  • Page 64: Folding Seat Backrest Of The Front Passenger Seat

    Seats and Stowage The driver's seat should be adjusted in such a way that the pedals can be fully WARNING pressed to the floor with slightly bent legs. ● If you want to carry objects on the folded seat backrest, you will need to The seat backrest on the driver's seat should be adjusted in such a way that the disable the front passenger airbag ⇒ ...
  • Page 65: Adjusting Front Seats Electrically

    Seats and Stowage Adjust the angle of the seat cushion WARNING – Press the switch at the front in the direction of arrow or at the back in ● The folding table must not be in the horizontal position while driving. This the direction of arrow could lead to injuries in the event of an accident.
  • Page 66 Seats and Stowage Storing setting Emergency Off You can interrupt the setting operation at any time, if you operate any button of the driver seat. Note ● For safety reasons, it is not possible to store this position if the inclination an- gle of the seat backrest is more than 102°...
  • Page 67: Head Restraints

    Seats and Stowage ● The assignment of the radio remote control to a memory button is retained, Head restraints however, after reassigning the seats and exterior mirrors. ● After the successful assignment, the turn signal lights flash and an audible signal will sound as a confirmation.
  • Page 68: Middle Rear Head Restraint

    Seats and Stowage WARNING WARNING ● The head restraints must be correctly adjusted in order to offer effective ● The head restraints must be correctly adjusted in order to offer effective protection for the occupants in the event of an accident. protection for the occupants in the event of an accident.
  • Page 69: Adjusting The Seat Backrest

    Seats and Stowage Adjusting the seat backrest Fold the middle rear seat backrest forwards in the same way, then pull once – ⇒  f ig. 50 more on the lever and press the seat backrest downwards until it is heard to lock into a lower position. ⇒ ...
  • Page 70 Seats and Stowage Unlocking and removing seats Move seats into the initial position – Unlock the folded forward seat by pressing the seat locks in direction of arrow ⇒  f ig. Remove the seat by way of the carrying handles on the seat cushion –...
  • Page 71 Seats and Stowage Folding table on the middle seat backrest Seat heating of the front seats Fig. 56 Dash panel: Regulator for front Fig. 55 Rear seats: Armrest seat heating The middle seat backrest can be folded ⇒  p age 67, Folding rear seats forwards –...
  • Page 72: Pedals

    Seats and Stowage Distribute the items of luggage as evenly as possible. – CAUTION ● You should not kneel on the seats or otherwise apply pressure at specific Place heavy objects as far forward as possible. – points in order to avoid damaging the heating elements of the seat heaters. Attach the items of luggage to the lashing eyes or the fixing net ⇒ ...
  • Page 73: Fastening Elements

    Seats and Stowage Note WARNING Tyre pressure must be adjusted to the load ⇒  p age 201.  ● The load to be transported must be fixed in place in such a way that it can- not move during the journey and when braking. Vehicles of category N1 ●...
  • Page 74 Seats and Stowage Fastening strip with moveable hook Fixing nets - Net programme Fig. 59 Luggage compartment: Fastening strip with moveable hook/remove hook Fig. 60 Fixing net: double horizontal pocket, floor fixing net/double vertical pocket A fastening strip is located on both sides of the luggage compartment with two Fixing examples of the fixing net as double horizontal pocket, floor fixing net ⇒ ...
  • Page 75 Seats and Stowage The luggage compartment cover WARNING You can use the luggage compartment cover behind the head re- No objects should be placed on the luggage compartment cover, the vehicle straints for storing light and soft items. occupants could be endangered if there is sudden braking or the vehicle col- lides with something.
  • Page 76: Variable Loading Floor In The Luggage Compartment

    Seats and Stowage Pull the strap through the tensioning clasp, first of all on the one side and The variable loading floor makes it easier to handle bulky goods and creates an – then on the other side. even luggage compartment floor when the rear seat backrests are folded forward. The maximum permissible surface load of the variable loading floor is 75 kg.
  • Page 77: Variable Loading Floor With Spare Wheel

    Seats and Stowage Remove carrier rails Variable loading floor with spare wheel Use variable loading floor Fig. 64 Luggage compartment: Slacken check points/remove carrier rails Remove carrier rails Fig. 65 Luggage compartment: Fold the side parts of the loading floor/example for using the ⇒ ...
  • Page 78: Roof Rack

    Seats and Stowage Removable storage box CAUTION ● Only use roof racks approved by ŠKODA. ● If you use other roof rack systems or if the roof bars are not properly fitted, then any damage which may result to your car is not covered by the warranty agreements.
  • Page 79: Cup Holder

    Seats and Stowage Cup holder Cup holder in rear centre console Cup holder in front centre console Fig. 69 Centre console at rear: Cup holder ⇒  f ig. 69 – Press on the panel in the area - the cup holder comes out. Fig.
  • Page 80: Note Holder

    Seats and Stowage Note holder Replacing ashtray – Insert the ashtray vertically. WARNING Never lay flammable objects in the ashtray basin - risk of fire!  Rear ashtray - low centre console Fig. 70 Windscreen: Note holder The parking ticket holder is designed e.g. for attaching a car park ticket in parking areas.
  • Page 81: Cigarette Lighter, Power Sockets

    Seats and Stowage Rear ashtray - high centre console Cigarette lighter, power sockets Cigarette lighter You can also use the socket on the cigarette lighter for other elec- trical appliances. Fig. 73 High centre console: Rear ash- tray Opening ashtray ⇒ ...
  • Page 82: Storage Compartments

    Seats and Stowage ⇒  p age 80 CAUTION Storage compartment on the front passenger side ⇒  p age 81 Always use matching plugs to avoid damaging the power socket. Storage compartment on the dash panel ⇒  p age 82 Stowage compartment in front centre console Note ⇒ ...
  • Page 83: Cooling Of Storage Compartment On Front Passenger

    Seats and Stowage Opening and closing the storage compartment on the front passenger side Storage compartment on the dash panel ⇒  f ig. 76 – Press the button - the lid folds down. – Raise the lid and press it until the catch is heard to engage. In the storage compartment are pin holders.
  • Page 84: Stowage Compartment In Front Centre Console

    Seats and Stowage Stowage compartment in front centre console CAUTION ● The compartment must only be opened when removing or inserting the spec- tacles and otherwise must be kept closed. ● Do not put any heat-sensitive objects in the stowage compartment - they may be damaged.
  • Page 85: Stowage Compartment Below Front Passenger Seat

    Seats and Stowage Stowage compartment below front passenger seat Closing stowage compartment – Open the lid up to the stop, then you can fold it downwards. Setting height First of all fold the lid to the bottom and lift it in the direction of arrow into one –...
  • Page 86: Stowage Compartment In Rear Centre Console

    Seats and Stowage Stowage compartment in rear centre console Storage compartments are located on both sides of the luggage compartment. ⇒  f ig. 85 The removable storage compartment on the left side is suitable for stowing small objects weighing up to 1.5 kg. ⇒ ...
  • Page 87: Removable Through-Loading Bag

    Seats and Stowage Removable through-loading bag WARNING ● After placing the skis into the removable through-loading bag, you must The removable through-loading bag is solely used for transporting secure it with the securing belt skis. ● The securing belt must hold the skis tight. ●...
  • Page 88: Heating And Air Conditioning System

    Heating and air conditioning system Heating and air conditioning system Introduction tem. This produces a permanent odour when the air conditioning system is oper- ating which can only be eliminated through considerable effort and expense (re- placement of compressor). Description and information ●...
  • Page 89: Air Outlet Vents

    Heating and air conditioning system Air outlet vents Close air outlet vents 6 – Turn the vertical wheel into the end position. Change air flow of air outlet vents 3 and 4 In order to change the strength of the air flow, swivel the horizontal lamellas –...
  • Page 90 Heating and air conditioning system Heating Turn the blower switch into position 0 in order to switch the blower off. – If you wish to shut off the fresh air supply, use the button - recirculated air – mode ⇒  in Recirculated air mode on page 89.
  • Page 91: Air Outlet Vents 4

    Heating and air conditioning system Setting of the control dial Set-up Button Air outlet vents 4 Defrosting the windscreen and side To the right up to the Open and align with the side win-  Do not switch on windows stop Free windscreen and side windows Open and align with the side win-...
  • Page 92 Heating and air conditioning system ⇒  f ig. 91 The cooling only operates if button is pressed, and the following Turn the blower switch into position 0 in order to switch the blower off. – conditions are met: If you wish to shut off the fresh air supply, use the button - recirculated –...
  • Page 93: Recirculated Air Mode

    Heating and air conditioning system Setting air conditioning system Recommended basic settings of the control elements of the air conditioning sys- tem for the respective operating modes: Setting of the control dial Button Set-up Air outlet vents 4 Defrost windscreen and side Desired tempera- Is activated auto- Open and align with the side...
  • Page 94: Climatronic (Automatic Air Conditioning)

    Heating and air conditioning system Note WARNING ● We recommend that you have Climatronic cleaned by a specialist garage once You should not leave recirculated air mode on over a longer period of time, as every year. “stale” air may result in fatigue in the driver and occupants, divert your atten- ●...
  • Page 95: Setting Temperature

    Heating and air conditioning system Buttons/control dial When pressing again the button , the Climatronic changes into the “LOW” AUTO mode and the warning light in the top left corner lights up. The Climatronic uses Setting of the temperature for the left side, operation of the seat heating of only in this mode the lower blower speed.
  • Page 96 Heating and air conditioning system numerical scale. In both limit positions the Climatronic operates at maximum cool- WARNING ing or heating capacity, respectively. The temperature is not controlled in this case. You should not leave recirculated air mode on over a longer period of time, as “stale”...
  • Page 97: Auxiliary Heating (Auxiliary Heating And Ventilation)

    Heating and air conditioning system Defrosting windscreen WARNING ● The auxiliary heating must never be operated in closed rooms - risk of poi- Defrosting windscreen - switching on soning! ⇒  f ig. – Press the button  ● The auxiliary heating must not be running during refuelling - risk of fire. ⇒ ...
  • Page 98 Heating and air conditioning system ● The air inlet in front of the windscreen must be free of ice, snow or leaves in By selecting the menu point Back, you will reach one level higher in the menu – order to ensure that the auxiliary heating operates properly. Aux.
  • Page 99 Heating and air conditioning system If the system is running, a warning light in the button for direct switching on/off The auxiliary heating can only be switched on or off with the radio remote control, of the auxiliary heating lights up. if the distance between the radio remote control and the vehicle is at least 2 m.
  • Page 100 Heating and air conditioning system For the sake of the environment Dispose of a used battery in accordance with environmental regulations. Note ● Pay attention to the correct polarity when changing the battery. ● The replacement battery must have the same specification as the original bat- tery.
  • Page 101: Starting-Off And Driving

    Starting-off and Driving Starting-off and Driving Setting steering wheel position WARNING (Continued) ● If you adjust the steering wheel further towards the head, you will reduce the protection offered by the driver airbag in the event of an accident. Check that the steering wheel is aligned to the chest.
  • Page 102: Starting The Engine

    Starting-off and Driving - start engine Starting the engine Applies to all models: General Position You can only start the engine only using an original ignition key. To lock the steering, with the ignition key withdrawn, turn the steering wheel un- til the steering locking pin is heard to engage.
  • Page 103: Petrol Engines

    Starting-off and Driving You should not switch on any major electrical components during the heating CAUTION period otherwise the vehicle battery will be drained unnecessarily. ● The starter may only be operated (ignition key position ), if the engine is not running.
  • Page 104: Pedals

    Starting-off and Driving Pedals Note ● The radiator fan may continue running for a further 10 minutes or so after the Operation of the pedals must not be hindered! engine and the ignition have been switched off. The coolant fan may, however, al- so switch on again after some time if the coolant temperature rises because of an accumulation of heat in the engine or if the engine is warm and the engine com- WARNING...
  • Page 105: Rear Parking Aid

    Starting-off and Driving The handbrake warning light lights up when the handbrake is applied, provided The audible parking aid determines the distance from the rear bumper to an ob-  the ignition is on. stacle behind the car with the aid of ultrasound sensors. The tones of the parking aid can be adapted in the menu of the Information display ⇒ ...
  • Page 106: Front And Rear Parking Aid

    Starting-off and Driving The audible parking aid determines the distance between the front or rear bump- WARNING er and an obstacle with the aid of ultrasound sensors. The sensors are integrated in the front and rear bumper. The signal tones for the front parking aid sound ●...
  • Page 107: Park Assist

    Starting-off and Driving Function of the system is based on: WARNING ● Length and depth measurement of the parking spaces when driving ● The parking aid is not a substitute for the driver paying proper attention ● Evaluation of the size of the parking space and it is always the driver's responsibility to take care when reversing the ve- ●...
  • Page 108 Starting-off and Driving ● The accuracy of the evaluation for the parking space can be influenced by the If you press the button at a speed greater than 30 km/h and less than 50 km/h, incorrectly determined outside temperature if the later is influenced by the ther- the message indicating that the speed for detecting the space is exceeded will be mal radiation of the engine i.e for stop and go in a traffic jam.
  • Page 109 Starting-off and Driving Parking with the help of the park assist and concluding the Observe the surroundings and reverse carefully at a maximum speed of 7 km/h – with the help of the pedal. parking procedure – In the event that the parking procedure cannot be carried out in one go, pro- ceed to parking in further stages.
  • Page 110: Cruise Control System (Ccs)

    Starting-off and Driving Driver steering intervention: Please take over steering! Park Assist: ASR intervention. The parking procedure is ended through driver intervention. Intervention of the TCS while searching for a suitable parking place. Park Assist finished. ASR deactivated. ASR intervention! Please take over steering! The parking procedure cannot be carried out because the TCS system is switched Parking procedure is ended through the intervention of the TCS.
  • Page 111 Starting-off and Driving This does not apply, however, if you drive at a speed which is more than 10 km/h Note higher than the saved speed for a period of more than 5 minutes. The stored ● Models fitted with a manual gearbox: Always depress the clutch pedal if you speed will be cancelled in the memory.
  • Page 112: (Start-Stop)

    Starting-off and Driving Switching off the cruise control system temporarily In the start-stop mode, the engine automatically switches to the vehicle's idle phase, e.g. when stopped at traffic lights. – You can switch off the cruise control system temporarily by depressing the Information regarding the current state of the “START-STOP”...
  • Page 113 Starting-off and Driving The pressure in the brake system is sufficient. WARNING The difference between the outdoor- and the set temperature in the interior is ● The brake servo unit and power steering only operate if the engine is run- not too great.
  • Page 114: Automatic Gearbox Dsg

    Automatic gearbox DSG Automatic gearbox DSG Automatic gearbox DSG appear in the Information display Move selector lever to position P/N! or, in the instrument cluster display:  P/N. At temperatures below -10 °C the engine can only be started in the selector lever position P. Information for driving with the automatic gearbox DSG It is sufficient to engage selector lever position P when parking on a flat surface.
  • Page 115: Selector Lever Positions

    Automatic gearbox DSG - Reverse gear CAUTION Reverse gear must only be engaged when the vehicle is stationary and the engine ● The double clutch on the automatic gearbox DSG is equipped with an overload idling ⇒  protection. If you make use of the uphill function on a vehicle which is stationary or driving slowly uphill, it will result in an increase of thermal stress of the clutch- The brake pedal must be depressed and at the same time the Shiftlock must be pressed, if you wish to obtain the selector lever positions R, P or N.
  • Page 116: Kickdown Function

    Automatic gearbox DSG Keylock - Ignition key withdrawal lock WARNING You can only withdraw the ignition key after switching off the ignition if the selec- ● Never move the selector lever into position R or P when driving - risk of an tor lever is in position P.
  • Page 117: Emergency Programme

    Automatic gearbox DSG Selecting the most appropriate driving programme for the particular style of driv- Shifting down gears ing is a continuous process. Irrespective of this it is, however, possible to switch or – One-touch back of the selector lever (in the Tiptronic position) shift down into a dynamic shift programme by depressing the accelerator rapidly.
  • Page 118: Selector Lever-Emergency Unlocking

    Automatic gearbox DSG Selector lever-emergency unlocking Fig. 108 Selector lever-emergency un- locking In case of interruption of the power supply (e.g. flat vehicle battery, defective fuse) or defect of the selector lever lock, the selector lever can no longer be shif- ted from the position P in the normal way and the vehicle can no longer be moved.
  • Page 119: Communication

    Communication Communication Multifunction steering wheel Operate radio and radio navigation system on the multifunction steering wheel You can of course operate the radio and radio navigation system at the appliance. You will find a description in the relevant Owner's manual. If the side lights are switched on, the buttons on the multifunction steering wheel are illuminated.
  • Page 120 Communication Button Action Radio, traffic information CD/CD changer/MP3 Navigation press briefly Switch off/on tone/activation and deactivation of the voice control press button for a switch off/on without function long period of time  turn upwards Increase volume  turn downwards Decrease volume Changing to the next stored radio station ...
  • Page 121: Universal Telephone Preinstallation Gsm Ii

    Communication for your mobile phone, use your mobile phone exclusively in the adapter so that To ensure an optimum signal transmission, always leave the telephone with the the radiation in the vehicle drops to a minimum. This also improves the quality of adapter in the telephone mount.
  • Page 122 – Confirm the PIN (as standard 1234). ● Is the telephone switched on? If the hands-free system announces (as standard Skoda UHV) on the display of – ● Is the PIN code entered? the mobile phone, enter the PIN (as standard 1234) within 30 seconds and wait ®...
  • Page 123 Communication ● Inserting the mobile phone into the adapter ensures an optimal sending and CAUTION receiving power and offers at the same time the advantage of the battery charg- Taking the mobile phone out of the adapter during the call can lead to interrup- ing.
  • Page 124 Communication Operation of the telephone on the multifunction steering wheel This applies only if your vehicle has been equipped with the telephone preinstalla- tion at the factory. If the side lights are switched on, the buttons on the multifunction steering wheel are illuminated.
  • Page 125 ■ ■ Voice mailbox ■ Phone name - the possibility to change the name of the telephone unit (pre- Bluetooth ■ set SKODA UHV) Settings ■ Settings Back ■ In the menu Settings you can select the following menu points:...
  • Page 126: Voice Control

    Communication Voice control Switching off voice control (dialogue) If the system is currently playing a message, you will need to stop the message currently being played: Dialogue ● by briefly pressing the button on the adapter  On vehicles which are factory-fitted with the navigation system Co- ●...
  • Page 127: Music Playback Via Bluetooth

    Communication ® Music playback via Bluetooth Voice command Action Play music from the mobile phone or another paired MUSIC device. The universal telephone preinstallation GSM IIl makes it possible to play back mu- ® sic via Bluetooth from the devices such as MP3 player, mobile phone or note- After this command the system offers additional con- FURTHER OPTIONS book.
  • Page 128 Communication CD change Note ● Always guide the CD into the CD-case with the printed side pointing up- wards. ● Never push the CD with force into the CD-case as the insertion is performed automatically. ● After loading a CD into the CD-changer, you must wait until the LED of the cor- responding button lights up.
  • Page 129 Communication WARNING ● If there are passengers of both of the rear seats, the DVD player holder must not be used alone (without the DVD player) - risk of injury! ● The inclination of the holder can be adjusted to three preset positions. Risk of finger injuries between the holder and the backrest in case of changes in the position of the DVD player holder.
  • Page 130: Safety

    Passive Safety Safety Passive Safety Basic information ● seat belt height adjuster for front seats, ● front airbag for the driver and front passenger, ● driver's knee airbag, Driving the safe way ● front side airbags, Passive safety measures reduce the risk of injury in accident situa- ●...
  • Page 131: Correct Seated Position

    Passive Safety ● Safely attach the items of luggage ⇒  p age 70, Loading the luggage compart- Correct seated position ment. ● Ensure that no objects can obstruct the pedal. Correct seated position for the driver ● Adjust the mirror, the front seat and the head restraint to match your body size.
  • Page 132 Passive Safety Manual front passenger adjustment ⇒  p age 61. WARNING Electrical front passenger seat adjustment ⇒  p age 63, Adjusting front seats elec- ● The front seats and the head restraints must always be adjusted to match trically. the body size of the seat occupant as well as the seat belts must always be correctly fastened in order to provide an optimal protection for you and your WARNING occupants.
  • Page 133 Passive Safety ● put the feet on the dash panel, WARNING ● put the feet on the seat upholstery, ● The head restraints must always be adjusted to match the body size, in or- ● occupy the footwell, der to offer an optimal protection for you and your occupants. ●...
  • Page 134: Seat Belts

    Seat belts Seat belts Why seat belts? WARNING ● Fasten your seat belt each time before setting off - also when driving in town! This also applies to the people seated at the rear - risk of injury! ● Expectant women must also always wear a seat belt. This is the only way of ensuring optimal protection for the unborn child ⇒ ...
  • Page 135: Important Safety Information Regarding The Use Of

    Seat belts The speed of the vehicle is, nevertheless, the most important factor. Doubling the WARNING (Continued) speed of the vehicle from 25 km/h up to 50 km/hour increases the kinetic energy ● The belt webbing must not run across solid or fragile objects (e.g. specta- four times.
  • Page 136: How Are Seat Belts Correctly Fastened

    Seat belts How are seat belts correctly fastened? WARNING ● The shoulder part of the seat belt must never run across your neck but Fastening three-point seat belts must run approximately over the middle of the shoulder and fit snugly against the chest.
  • Page 137: Belt Tensioners

    Seat belts Fastening the seat belt WARNING – Pull the seat belt with both lock tongues out of the headliner mount. Adjust the height of the belt in such a way that the shoulder part of the belt is – Insert the lock tongue at the end of the belt into the seat belt buckle on the positioned approximately across the middle of your shoulder - on no account left side until it is heard to lock in place.
  • Page 138 Seat belts Belt tensioners are not activated in the event of minor frontal collisions, side and rear-end collisions, in the case of a rollover and also not in accidents in which no major forces are produced from the front. WARNING ●...
  • Page 139: Airbag System

    Airbag system Airbag system Description of the airbag system WARNING ● To enable the occupants of a car to be protected with the greatest possi- General information on the airbag system ble effect when the airbag is deployed, the front seats must be ⇒  p age 129, Correct seated position correctly adjusted to match the body size of the occu- The front airbag system is complementary to the three-point seat belts and offers pant.
  • Page 140: Front Airbags

    Airbag system It is also possible under certain special accident situations that the front as well as Front airbags the side airbags and head airbags are deployed simultaneously. The airbags are not deployed in the case of minor frontal and side collisions, rear- Description of the front airbags end collisions, tilting of the vehicle, and vehicle rollover.
  • Page 141 Airbag system Function of the front airbags Important safety information regarding the front airbag system Risk of injury to the head and chest area is reduced by fully inflated Correct use of the airbag system considerably reduces the risk of airbags.
  • Page 142: Driver's Knee Airbag

    Airbag system The driver's knee airbag is complementary to the three-point seat belt and offers WARNING (Continued) adequate protection to the knees of the driver. Please note that an airbag can ● The steering wheel and the surface of the airbag module in the dash panel only offer you optimal protection in combination with a seat belt which is fas- on the passenger side must not be stuck onto, covered or modified in any oth- tened.
  • Page 143: Side Airbags

    Airbag system Important safety information on the driver's knee airbag The front side airbags are housed in the upholstery of the seat backrests of the ⇒  f ig. 125 front seats and are marked with the lettering “AIRBAG” on the middle part.
  • Page 144 Airbag system The load of the occupants is cushioned when plunging into the fully inflated air- WARNING (Continued) bag and the risk of injury to the entire upper body (chest, stomach and pelvis) is ● In the event of a side collision, the side airbags will not function properly, if reduced on the side facing the door.
  • Page 145: Head Airbags

    Airbag system Head airbags Function of the head airbags The risk of injury to the head and neck area is reduced in the event Description of the head airbags of a side collision by fully inflated head airbags. The head airbag together with the side airbag offers enhanced oc- cupant protection in the event of a side collision.
  • Page 146: Deactivating An Airbag

    Airbag system Important safety information on the head airbag WARNING (Continued) sories fitted may in certain circumstances be thrown into the interior of the Correct use of the airbag system considerably reduces the risk of car and cause injuries to the occupants ⇒  p age 207, Accessories, changes and injury! replacement of parts.
  • Page 147 Airbag system If the airbag was switched off using diagnostic equipment: Switching on an airbag – Switch off the ignition. ● The warning light for the airbag system lights up for 4 seconds after switching on the ignition and then flashes for 12 seconds afterwards in 2 second intervals. –...
  • Page 148: Transporting Children Safely

    Transporting children safely Transporting children safely What you should know about transporting children! Note National legal provisions, which deviate from the information contained in these operating instructions, take precedence over the information contained in the op- An introduction to the subject erating instructions.
  • Page 149 Transporting children safely WARNING (Continued) WARNING ● Children are exposed to an increased risk of injury in the event of an acci- ● Warning - particular hazard! Never use a child safety seat on the front pas- dent if they lean forward or adopt an incorrect seated position when the vehi- senger seat in which the child is seated with its back facing the direction of cle is moving.
  • Page 150: Child Seat

    Transporting children safely Child safety and side airbag WARNING Children must never be seated in the deployment area of the side ● It is essential to always switch off ⇒  p age 144 the front passenger front airbags and head airbags. airbag when attaching a child safety seat on the front passenger seat where the child is seated with its back facing in direction of travel (in some countries also when the child is facing the direction of travel).
  • Page 151 Transporting children safely Children who are more than 1.50 m in height or who weigh more than 36 kg can Child seats in which the child is facing with its back towards the direction of use normal seat belts without a seat bolster. travel should not be used on the front passenger seat when the vehicle is fitted ...
  • Page 152: Child Safety Seats In Group 3

    Transporting children safely Child seats in which the child is facing with its back towards the direction of WARNING travel should not be used on the front passenger seat when the vehicle is fitted with a front passenger airbag ⇒  p age 147, Use of child safety seats on the front ●...
  • Page 153: Attaching A Child Seat Using The "Isofix" System

    Transporting children safely Pull on both sides of the child seat! – WARNING One can mount a child safety seat using the “ISOFIX” system quickly, easily and ● When transporting a child on the front passenger seat, please comply with reliably.
  • Page 154: Attaching Child Seat Using The "Top Tether" System

    Transporting children safely Attaching child seat using the “Top Tether” system Fig. 136 Rear seat: Top Tether IIn certain countries national legal provisions also require the equipment of the ⇒  f ig. rear seat with fixing eyes for child seat using the “Top Tether” system 136.
  • Page 155: Driving Tips

    Intelligent technology Driving Tips Intelligent technology Electronic stability programme (ESP) Operating principle The ESP switches on automatically when the engine is started and then conducts a self-test. The ESP control unit processes data from the individual systems. It al- General so processes additional measurement data which are supplied by highly sensitive sensors: the rotational velocity of the vehicle about its vertical axis, the lateral ac- celeration of the vehicle, the braking pressure and the steering angle.
  • Page 156 Intelligent technology Note WARNING ● All four wheels must be fitted with the same tyres in order to achieve prob- ● Carefully depress the accelerator when accelerating on uniformly slippery lem-free operation of the ESP. Differing rolling circumferences of the tyres can road surfaces, such as ice and snow.
  • Page 157: Brakes

    Intelligent technology Operating principle Note The TCS switches on automatically when the engine is started and then conducts ● All four wheels must be fitted with the same tyres in order to achieve prob- a self-test. The system monitors the speeds of the driven wheels with the aid of lem-free operation of the TCS.
  • Page 158: Brake Booster

    Intelligent technology There also may be a certain delay before the full braking efficiency is available CAUTION when driving on roads which have been treated with road salt if you have not ● Never allow the brakes to rub by applying slight pressure if you do not wish to used the brakes for some considerable time beforehand.
  • Page 159: Antilock Brake System (Abs)

    Intelligent technology Antilock brake system (ABS) WARNING ● The ABS can also not overcome the physical limits of your vehicle. Please ABS prevents the wheels locking when braking. do not forget this, particularly when driving on icy or wet road surfaces. If the ABS is operating within the control range, adapt your speed immediately to General the conditions of the road surface and the traffic situation.
  • Page 160: Uphill Start Assist

    Intelligent technology The Brake Assist is able to help you achieve a shorter braking distance in emer- If there is a fault in the power steering, the warning light lights up in the   instrument cluster ⇒  p age 25. gency situations by rapidly producing the pressure required in the brake system.
  • Page 161: Diesel Particle Filter (Diesel Engine)

    Intelligent technology Basic setting of the system ● cannot warn in case of very rapid tyre inflation pressure loss, e.g. in case of sudden tyre damage. In this case carefully bring the vehicle to a standstill without After changing the tyre inflation pressures, after changing one or several wheels, sudden steering movements and without sharp braking.
  • Page 162: Off-Road

    Intelligent technology Switch on Off-road WARNING ⇒  f ig. The Off-road mode is switched on by pressing the button 141. The warning ● The diesel particle filter achieves very high temperatures. Therefore do not light in the button lights up. The warning light lights up in the instrument cluster park at points where the hot filter comes into direct contact with dry grass or ⇒ ...
  • Page 163 Intelligent technology Downhill Drive Support Manual gearbox The vehicle speed is steadily regulated by the Assist System depending on the Operating principle type of gearbox or engine: The Downhill Drive Support maintains a constant speed on a steep downhill sec- ●...
  • Page 164: Driving And The Environment

    Driving and the environment Driving and the environment The first 1 500 kilometres and then afterwards CAUTION All the speed and engine revolution figures apply only when the engine is at its normal operating temperature. Never rev up an engine which is cold, neither when New engine the vehicle is stationary nor when driving in individual gears.
  • Page 165: Driving In An Economical And Environmentally Conscious Manner

    Driving and the environment For vehicles with petrol engine only refuel with unleaded petrol ⇒  p age 186, Driving in an economical and environmentally – Fuel. conscious manner – Never run the fuel tank completely empty. Do not switch off the ignition while you are driving the vehicle. –...
  • Page 166 Driving and the environment Shifting gears and saving energy Avoiding full throttle Shifting up early saves on fuel. Driving more slowly means saving fuel. Fig. 142 Fuel consumption in litres/100 Fig. 143 Fuel consumption in litres/100 km. and speed in km/h. km.
  • Page 167 Driving and the environment Regular servicing Avoid driving short distances A poorly tuned engine uses an unnecessarily high amount of fuel. Short distances result in an above-average high fuel consumption. Having your vehicle serviced regularly at a specialist garge enables you to satisfy one of the requirements for economical motoring even before you set off on your journey.
  • Page 168: Environmental Compatibility

    Driving and the environment Do not drive with winter tyres all year round for this costs about 10 % more fuel. Environmental compatibility Winter tyres are also louder.  Environmental protection has played a major role in the design, selection of mate- No unnecessary ballast rials and manufacture of your new ŠKODA.
  • Page 169: Motoring Abroad

    Driving and the environment been created, where you can trade-in your vehicle. After you trade-in your vehicle, The adaptation of the headlights with Xenon lights (applies to vehicles which are you will receive a confirmation stating the recycling in accordance with environ- designed for driving on the left and on the right) is performed in the menu Set- tings Travel mode of the information display ⇒ ...
  • Page 170: Off-Road Driving

    Driving and the environment WARNING WARNING (Continued) ● In case the vehicle is stationary on a hillside at a steep angle, do not exit ● Driving through water, mud, sludge etc. can reduce the braking power and the vehicle when it is facing downhill. Through this the overall centre of gravi- extend the braking distance - risk of accident! ty can shift in such a way that the vehicle tilts and rolls down the hillside - ●...
  • Page 171: Important Information

    Driving and the environment er not possible to predict if these rules are valid for all the situations which may WARNING (Continued) occur. Before driving through unknown terrain, it is therefore important that you ● If the wheels lose contact with the ground, for example when the vehicle know what lies ahead of you.
  • Page 172 Driving and the environment Explanation of technical terms Slope angle The difference of altitude (upward slope) which is overcome on a stretch of road of 100 m, is indicated in percentage or degrees, i.e the gradiant at which the vehi- cle can climb a hill on its own (among other things, depending on the road surface and the engine power).
  • Page 173 Driving and the environment ● spare wheel and tyre repair kit, Off-road driving ● shovel.  ● Never be alone when driving off-road and be prepared to encounter unexpec- ted situations. Travel together with at least two off-road vehicles. Equipment with Safe off-road driving which you can call for help in an emergency is particularly useful.
  • Page 174 Driving and the environment Manual gearbox CAUTION ● If you are driving through difficult terrain, on no account use the clutch or ● Pay attention to the ground clearance of the vehicle! The vehicle can be se- change the gear. When the clutch is depressed, the vehicle may come to a stand- verely damaged and become disabled once it touches the ground.
  • Page 175 Driving and the environment WARNING WARNING Observe the important guidelines ⇒  p age 168. ● Driving through snow-covered terrain poses special dangers. Never choose a dangerous route and never take a risk which could jeopardize your safety CAUTION and that of your passengers. If you cannot go on or if you doubt the safety of the route, turn back and choose another way.
  • Page 176 Driving and the environment Engage the reverse gear and carefully drive backwards in your own tracks. Driving at an angle on a hillside – Press the foot brake in order to maintain a constant speed. – Downhill Switch on the Off-road mode ⇒  p age 160. –...
  • Page 177 Driving and the environment Exiting the vehicle on a hillside If the ruts and troughs are on firm and soft ground, you can simply follow the ruts. If the vehicle comes to a standstill at a steep angle on a hillside and you and your Do not drive over ruts and troughs which are too deep.
  • Page 178 Driving and the environment Driving through sand Drive back and forth repeatedly until the momentum is sufficient to free the – vehicle. Do not reduce the tyre inflation pressure. If you nevertheless reduce the inflation pressure, do not forget to re-establish the correct tyre inflation pressure level be- –...
  • Page 179 Driving and the environment WARNING ● Combustible materials which are trapped under the vehicle floor can be dangerous. They can impair the driving safety and the safety of all the occu- pants of the vehicle. After driving off-road, always check the underside of the vehicle and remove trapped objects.
  • Page 180: Towing A Trailer

    Towing a trailer Towing a trailer Towing a trailer height above sea level. The towed weight is the weight of the (laden) vehicle and the (laden) trailer together. One should take this into account before driving up to higher altitudes. Technical requirements The trailer and drawbar load information on the type plate of the towing device are merely test data for the towing device The data relating to your vehicle,...
  • Page 181 Towing a trailer Please refer to the following guidelines ⇒  p age 26, Coolant temperature/Coolant Driving Tips quantity . – Do not, as far as possible, drive with your vehicle unladen and the trailer laden. The coolant temperature can be reduced by switching on the heating. –...
  • Page 182: General Maintenance

    Taking care of your vehicle and cleaning the vehicle General Maintenance Taking care of your vehicle and cleaning the vehicle General Care of the exterior of vehicle Proper care retains the commercial value of your vehicle. Washing the vehicle Regular and proper care retains the value of your vehicle. It may also be one of Frequent washing protects your vehicle.
  • Page 183: Automatic Vehicle Wash Systems

    Taking care of your vehicle and cleaning the vehicle Automatic vehicle wash systems CAUTION ● Do not wash your vehicle in bright sunlight - risk of paint damage. The paintwork of the vehicle is sufficiently resistant that the vehicle can be wash- ●...
  • Page 184: Chrome Parts

    Taking care of your vehicle and cleaning the vehicle A new layer of a high-quality hard wax polish can be applied to the clean body- The authorised ŠKODA Service Partners have a range of matching touch-up pens work after it has dried thoroughly. Even if you use a wax preserver regularly we or spray cans available in the colour of your vehicle.
  • Page 185: Underbody Protection

    Taking care of your vehicle and cleaning the vehicle The headlight lenses Light alloy wheels Regular care of light alloy wheels is necessary in order to retain their decorative appearance over long periods. It is particularly important to remove regularly any Please do not use any aggressive cleaning or chemical solvent products for clean- ing the front headlights - risk of damage to the plastic lenses.
  • Page 186: Care Of The Interior Of Vehicle

    Taking care of your vehicle and cleaning the vehicle Protection of hollow spaces Natural leather Natural leather requires quite particular care and attention. All the cavities of your vehicle which are at risk from corrosion are protected for life by a layer of protective wax applied in the factory. Leather should be treated from time to time according the following guidelines This wax protection does not require to be inspected or re-treated.
  • Page 187 Taking care of your vehicle and cleaning the vehicle CAUTION WARNING ● You must on no account treat the leather with solvents (e.g. gasoline, turpen- ● The seat belts must not be removed for cleaning. tine), floor wax, shoe cream or such like. ●...
  • Page 188: Fuel

    Fuel Fuel Petrol On vehicles with prescribed unleaded petrol min. 95 RON, the use of petrol with a higher octane number than 95 RON does not result in a power increase or a lower fuel consumption. Unleaded petrol Prescribed fuel - unleaded petrol 98/95 RON Your vehicle can only be operated with unleaded petrol, which complies with the Use unleaded fuel with the octane rating 98 RON.
  • Page 189: Diesel

    Fuel Diesel It is therefore the case that the standard EN 590 (standard DIN 51628 in Germany, standard ÖNORM C 1590 in Austria, GOST R 52368-2005/EN 590:2004 in Russia) is the diesel fuel class prescribed for certain periods of the year which can also be Diesel fuel purchased at the corresponding time during the year.
  • Page 190 Fuel Unscrew the fuel filler cap anti-clockwise and place the fuel filler cap from – ⇒  f ig. 150 above on the fuel filler flap - right. Closing fuel filler cap – Screw on the cap by turning it to the right until it is heard to lock. –...
  • Page 191: Inspecting And Replenishing

    Inspecting and Replenishing Inspecting and Replenishing Engine compartment – Ensure that the arms of the windshield wipers are correctly in place against the windshield before opening the bonnet, otherwise damage could occur to the paintwork. Bonnet remote release ⇒  f ig. 152 Pressing on the locking lever in direction of arrow will unlock the –...
  • Page 192 Inspecting and Replenishing Working in the engine compartment WARNING (Continued) ● If you wish to work under the vehicle, you must secure the vehicle from Particular care is required when carrying out any work in the en- rolling away and support it with suitable supporting blocks: the car jack is not gine compartment! sufficient for this - risk of injury! ●...
  • Page 193: Engine Oil

    Inspecting and Replenishing Overview of the engine compartment Engine oil The main inspection points. Check engine oil level The dipstick indicates the level of oil in the engine. Fig. 154 Dipstick Fig. 153 Petrol engine 1.8 ltr./118 kW TSI Checking the oil level –...
  • Page 194 Inspecting and Replenishing It is normal for the engine to consume oil. The oil consumption may be as much as WARNING 0.5 l/1 000 km depending on your style of driving and the conditions under which you operate your vehicle. The oil consumption may be slightly higher than this ●...
  • Page 195: Cooling System

    Inspecting and Replenishing Coolant capacity Note After your skin has come in contact with the oil, you must thoroughly wash your Petrol engines Capacities (in litres) skin.  1.2 ltr./77 kW TSI - EU 5 1.4 ltr./90 kW TSI - EU5 1.8 ltr./118 kW TSI - EU5, EU2 Cooling system (1.8 ltr./112 kW TSI - EU5)
  • Page 196 Inspecting and Replenishing Open the bonnet ⇒  p age 189. The coolant which you use for replenishing the system, must comply with one – specific specification ⇒  p age 193. Do not use an alternative additive if the speci- ⇒  f ig. Check the level of coolant in the coolant expansion bottle 155.
  • Page 197: Brake Fluid

    Inspecting and Replenishing ⇒  f ig. Radiator fan Inspect the brake fluid level in the reservoir 156. The level must be be- – tween the “MIN” and “MAX” markings. The radiator fan may switch on suddenly. A slight drop in the fluid level results when driving due to normal wear-and-tear and automatic adjustment of the brake pads, and is perfectly normal.
  • Page 198: Battery

    Inspecting and Replenishing CAUTION WARNING (Continued) Brake fluid damages the paintwork of the vehicle. ● Splashes of acid on your skin or clothes should be neutralised as soon as possible using soap suds and then rinsed with plenty of water. If acid was For the sake of the environment swallowed, seek immediate medical attention.
  • Page 199 Inspecting and Replenishing ⇒  f ig. 157 ● Do not place the battery in direct daylight in order to protect the battery hous- The edge of the polyester battery cover - left is inserted between the ing from the effects of ultra-violet light. battery and the side wall of the battery cover when working on the battery.
  • Page 200: Charging The Battery

    Inspecting and Replenishing Operation in winter It is, however, necessary to disconnect both cables before charging the battery with high amperages, so-called “quick-charging”. The battery has to provide greater amounts of electricity during the winter. It also “Quick-charging” a battery is dangerous ⇒  in General information on page 196.
  • Page 201: Windshield Washer System

    Inspecting and Replenishing Replacing the battery Windshield washer system When replacing a battery, the new new battery must have the same capacity, voltage (12 V), amperage and be the same size. Suitable types of vehicle battery are available from an authorised ŠKODA Service Partner. We recommend you have a battery change carried out by an authorised ŠKODA Service Partner, who will properly install the new battery and dispose of the origi- nal one.
  • Page 202 Inspecting and Replenishing CAUTION ● On no account should you add radiator antifreeze or other additives to the windscreen washer fluid. ● If the vehicle is fitted with a headlight cleaning system, you should only add cleaning products which do not attack the polycarbonate glass of the headlights to the windshield washer fluid.
  • Page 203: Wheels And Tyres

    Wheels and Tyres Wheels and Tyres Wheels WARNING ● New tyres during the first approximately 500 km do not offer optimal grip General information and should therefore be run appropriately - risk of accident! ● Never drive with damaged tyres - risk of accident! ●...
  • Page 204 Wheels and Tyres The tyre inflation pressure for tyres of the tyre size 205/50 R17 or 205/55 R16, Wear indicators which are intended to be used with snow chains, is identical to the tyre inflation ⇒  f ig. pressure for tyres of size 225/45 R17 or 215/60 R16, see 160.
  • Page 205: Changing Wheels Around

    Wheels and Tyres Changing wheels around The tyre/wheel combinations which are approved for your vehicle are indicated in your vehicle documents. Approval and licensing may differ according to the legis- lation prevailing in individual countries. Proper knowledge of the tyre data makes it easier for you to select the correct type of tyre.
  • Page 206 Wheels and Tyres WARNING WARNING ● Only use those tyres or wheel rims which have been approved for your ● In case of incorrect treatment of the wheel bolts, the wheel can loosen model of ŠKODA vehicle. Failure to observe this instruction will adversely af- when the car is moving - risk of accident! fect the road safety of your vehicle - risk of accident! Approval and licensing of ●...
  • Page 207: Unidirectional Tyres

    Wheels and Tyres You can fit winter tyres of a lower speed category to your vehicle provided that Snow chains you also do not drive faster than the permissible maximum speed for such tyres, even if the possible maximum speed of your vehicle is higher. The corresponding When driving on wintry roads, snow chains improve not only traction, but also the tyre category can damage the tyres when exceeding the permissible maximum braking performance.
  • Page 208 Wheels and Tyres Remove the full wheel trims before installing the snow chains. Observe the different national legal regulations relating to the use of snow chains and the maximum vehicle speed with snow chains. WARNING Please pay attention to the information in the supplied fitting instructions of the snow chain manufacturer.
  • Page 209: Accessories, Changes And Replacement Of Parts

    Accessories, changes and replacement of parts Accessories, changes and replacement of parts General WARNING ● Work or modifications on your vehicle, which have been carried out unpro- ŠKODA vehicles have been built according to the latest discoveries in safety engi- fessionally, can cause operational faults - risk of accident! neering.
  • Page 210: Breakdown Assistance

    Breakdown assistance Breakdown assistance Breakdown assistance Space for first-aid box and warning triangle Please read carefully the instructions which are attached to the fire extinguish- The fire extinguisher must be checked by an authorised person or company annu- ally (please observe the differing legal requirements). WARNING If the fire extinguisher is not correctly attached, in case of sudden manoeu- vres or an accident it can be “thrown”...
  • Page 211: Spare Wheel

    Breakdown assistance The vehicle tool kit and the lifting jack, on which a sign is affixed, are stowed in a The spare wheel is stowed in the luggage compartment in the area below the var- ⇒  f ig. ⇒  f ig. box in the luggage compartment 164;...
  • Page 212: Full Wheel Trim

    Breakdown assistance Note WARNING ● All bolts must be clean and must turn easily. ● If you find yourself in flowing traffic switch on the hazard warning lights ● You must never grease or oil the wheel bolts! system and place the warning triangle on the side of the road at the prescri- ●...
  • Page 213 Breakdown assistance Push the wheel key through the clamp, support the wheel key at the tyre and Wheel trim caps – pull off the wheel trim. Install – First press the full wheel trim onto the wheel at the valve opening provided. Then press the full wheel trim into the wheel in such a way that its entire cir- cumference locks correctly in place.
  • Page 214 Breakdown assistance Tightening wheel bolts – Insert the wheel wrench fully onto the wheel bolt – Grasp the end of the wrench and turn the bolt to the right until it is tight. WARNING Loosen the wheel bolts only a little (about one turn) while the vehicle has not yet been jacked up - risk of an accident!.
  • Page 215: Tyre Repair Kit

    Breakdown assistance The safety wheel bolts on vehicles fitted with them (one safety wheel bolt per WARNING (Continued) wheel) can only be loosened or tighten up by using the adapter provided. ● Secure the base plate of the lifting jack with suitable means to prevent It is meaningful to note the code number hammered into the rear side of the possible moving.
  • Page 216 Breakdown assistance Components of the tyre repair kit WARNING ● If you find yourself in flowing traffic switch on the hazard warning lights system and place the warning triangle on the side of the road at the prescri- bed distance from your vehicle. Comply with the national legal regulations. In this way you are protecting not only yourself but also other road users.
  • Page 217 Breakdown assistance Have all the occupants get out. While changing a tyre, the occupants of the On vehicles fitted with a manual gearbox, move the gearshift lever into Neu- – – vehicle should not stand on the road (instead they should remain behind a tral.
  • Page 218: Jump-Starting

    Breakdown assistance CAUTION WARNING Switch off the air compressor after running 8 minutes at the latest - danger of ● A discharged battery may already freeze at temperatures just below 0 °C. overheating! Allow the air compressor to cool a few moments before switching it In case of frozen battery carry out no jump-starting - risk of explosion! on again.
  • Page 219: The Vehicle

    Breakdown assistance Connecting negative terminal and engine block Jump-starting on vehicles with the “START-STOP” system – Attach one end to the negative terminal of the battery supplying the power Attach the other end to a solid metal part which is connected firmly to the –...
  • Page 220 Breakdown assistance The maximum towing speed is 50 km/h. Note ● We recommend a tow rope from the range of ŠKODA Original Accessories that Driver of the towed vehicle you can purchase from an authorised ŠKODA Service Partner. – Switch the ignition on so that the steering wheel is not blocked and you can ●...
  • Page 221 Breakdown assistance CAUTION The towing eye must always be screwed in fully and firmly tightened, otherwise the towing eye can tear when towing in or tow-starting!  Rear towing eye Fig. 176 Rear bumper: Removing the cover/installing the towing eye ⇒ ...
  • Page 222: Fuses And Light Bulbs

    Fuses and light bulbs Fuses and light bulbs Electric fuses Colour coding of fuses Colour Maximum amperage Replacing fuses light brown brown Defect fuses must be replaced. blue yellow white green orange CAUTION Fig. 177 Fuse cover: left side of the dash panel ●...
  • Page 223 Fuses and light bulbs On some vehicles, the battery cover must be removed before removing the fuse Power consumer cover ⇒  p age 197. Control unit for automatic gearbox Removing fuse cover Instrument cluster, windshield wiper lever and turn signal light lever ⇒ ...
  • Page 224 Fuses and light bulbs Fuse assignment in the dash panel Power consumer Diagnostic socket, engine control unit, brake sensor Control unit for ABS, ESP, switch for tyre air pressure control, control unit for parking aid, switch for Offroad mode, start/stop button Switch and control unit for airbag WIV, parking light, dimming mirrors, pressure sensor, telephone prein- stallation, air mass meter...
  • Page 225: Bulbs

    Fuses and light bulbs Bulbs Rear light unit Bulb Reversing lights, brake lights and rear fog light P21W Changing bulbs Turn signals PY21W Parking lights The relevant lamp must always be switched off before a light bulb is replaced. Others Bulb Defect light bulbs should only be replaced with light bulbs of the same type.
  • Page 226 Fig. 182 Remove cap/removing the fixture for the parking light (halogen headlight) ● We recommend that you have the headlight setting checked by a Skoda Serv- ice Partner after replacing the light bulb.
  • Page 227: Daylight Driving Lights

    Installation is carried out in the reverse order. Remove the bulb for daylight driving lights Note – Switch the ignition and all lights off. We recommend that you have the headlight setting checked by a Skoda Service ⇒  f ig. – Remove the rubber protective cap 181.
  • Page 228 Fuses and light bulbs Rear light unit Replace the defective light bulb. – In order to replace a bulb for the brake light, reversing light, rear fog or turn – signal light, turn the fixture of the bulb to the left up to the stop and take the bulb out of the housing or pull the bulb for the parking light out of the fixture ⇒ ...
  • Page 229 Fuses and light bulbs Replace the the glass cover of the light and press it down to the stop - ensure – that the glass cover is correctly installed. – Screw the glass cover tight.  Using the system Safety Driving Tips General Maintenance Breakdown assistance...
  • Page 230: Technical Data

    Technical data Technical data Technical data General information Weight The details given in the official vehicle registration documents always take prece- dence over the details in the Owner's Manual. Please refer to the official vehicle registration documents or consult a specialist garage concerning the engine with which your vehicle is equipped.
  • Page 231: Identification Details

    Technical data The identification plate is affixed to the lower part of the column between the Sticker on inside of fuel filler flap front and rear doors on the front passenger side. The stickers are affixed to the inside of the fuel filler flap and contain the follow- ing information: WARNING ●...
  • Page 232: Dimensions

    Technical data Dimensions Dimensions (mm) Length 4223 Width 1793 Width including exterior mirror 1956 Height 1691 (1671 Clearance 180 (155 Wheel base 2578 Track gauge front/rear 1541/1537  GreenLine Other information Angle (in degree) Front embankment angle 19 (17.1 Rear embankment angle 26.7 (25.2 Ramp angle 19.4 (17.2...
  • Page 233: Engine Oil Specifications

    Technical data Engine oil specifications Engine oil specifications for vehicles with fixed service intervals (QG2) Petrol engines Specification Content The grade of engine oil should be selected in accordance with pre- 1.2 ltr./77 kW TSI - EU5 VW 502 00 cise specifications.
  • Page 234: Engine 1.2 L/77 Kw Tsi - Eu5

    Technical data Engine 1.2 l/77 kW TSI - EU5 Output (kW per rpm) Max. torque (Nm per rpm) Number of cylinders/Displacement (cm 77/5000 175/1550-4100 4/1197 Performances Maximum speed (km/h) Acceleration 0 - 100 km/h (s) 11.8 12.0 Fuel consumption (in ltr./100 km) and CO (in g/km) Urban /8.0...
  • Page 235: Engine 1.4 L/90 Kw Tsi - Eu5

    Technical data Engine 1.4 l/90 kW TSI - EU5 Output (kW per rpm) Max. torque (Nm per rpm) Number of cylinders/Displacement (cm 90/5000 200/1500-4000 4/1390 Performances Maximum speed (km/h) Acceleration 0 - 100 km/h (s) 10.5/10.6 Fuel consumption (in ltr./100 km) and CO (in g/km) Urban 8.9/7.9...
  • Page 236: Engine 1.8 Ltr./118 Kw Tsi - Eu2, Eu5 (1.8 Ltr./112 Kw Tsi - Eu5)

    Technical data Engine 1.8 ltr./118 kW TSI - EU2, EU5 (1.8 ltr./112 kW TSI - EU5) Output (kW per rpm) Max. torque (Nm per rpm) Number of cylinders/Displacement (cm 118/4500-6200 (112/4300 - 6200) 250/1500-4500 (250/1500 - 4200) 4/1798 1.8 ltr./112 kW TSI Performances M6 4x4 Maximum speed (km/h)
  • Page 237: Engine 1.6 L/77 Kw Tdi Cr - Eu5

    Technical data Engine 1.6 l/77 kW TDI CR - EU5 Output (kW per rpm) Max. torque (Nm per rpm) Number of cylinders/Displacement (cm 77/4400 250/1500-2500 4/1598 Performances Maximum speed (km/h) Acceleration 0 - 100 km/h (s) 12.1 Fuel consumption (in ltr./100 km) and CO (in g/km) Urban Non-urban...
  • Page 238: Engine 2.0 L/81 Kw Tdi Cr - Eu5

    Technical data Engine 2.0 l/81 kW TDI CR - EU5 Output (kW per rpm) Max. torque (Nm per rpm) Number of cylinders/Displacement (cm 250/1500-2500 81/4200 4/1968 M6 4x4 280/1750-2750 Performances M6 4x4 Maximum speed (km/h) Acceleration 0 - 100 km/h (s) 11.6 12.2 Fuel consumption (in ltr./100 km) and CO...
  • Page 239: Engine 2.0 L/103 Kw Tdi Cr - Eu4, Eu5

    Technical data Engine 2.0 l/103 kW TDI CR - EU4, EU5 Output (kW per rpm) Max. torque (Nm per rpm) Number of cylinders/Displacement (cm 103/4200 320/1750-2500 4/1968 Performances M6 4x4 DQ6 4x4 Maximum speed (km/h) 190/193 Acceleration 0 - 100 km/h (s) 9.9/9.7 10.2 Fuel consumption (in ltr./100 km) and CO...
  • Page 240: Engine 2.0 L/125 Kw Tdi Cr - Eu5

    Technical data Engine 2.0 l/125 kW TDI CR - EU5 Output (kW per rpm) Max. torque (Nm per rpm) Number of cylinders/Displacement (cm 125/4200 350/1750-2500 4/1968 Performances M6 4x4 Maximum speed (km/h) Acceleration 0 - 100 km/h (s) Fuel consumption (in ltr./100 km) and CO (in g/km) Urban Non-urban...
  • Page 241: Multi-Purpose Vehicles (Af)

    Technical data Multi-purpose vehicles (AF) Weight (in kg) Engine 1.2 ltr./77 kW TSI 1.4 ltr./90 kW TSI 1.8 ltr./118 (112) kW 1.6 ltr./77 kW TDI 2.0 ltr./81 kW TDI 2.0 ltr./103 kW TDI 2.0 ltr./125 kW TDI Permissible gross 2070/2095 1880/1910 1915/1935 2045/2080...
  • Page 242: Index

    Index Index Automatic gearbox Button in the driver's door Emergency programme ..... . 115 Power windows ......39 Abroad .
  • Page 243 Index Closing the panoramic sliding roof ....42 Diesel engines ESP ......... 153 Starting the engine .
  • Page 244: General View

    Index General view Interior mirror ....... . 58 Luggage compartment ..... 36, 70 Cockpit .
  • Page 245: Safety Information

    Index Operation in winter Rear-view mirror taking off ........135 Battery .
  • Page 246 Index Unlocking ....... . . 31, 33 Windshield wiper ......54 Remote control .
  • Page 247 Index Using the system Safety Driving Tips General Maintenance Breakdown assistance Technical data...
  • Page 248 Index...
  • Page 249 Index Using the system Safety Driving Tips General Maintenance Breakdown assistance Technical data...
  • Page 250 ŠKODA pursues a policy of constant product and model development. We trust Reprinting, reproduction or translation, either in whole or in part, is not permitted that you will understand that changes to models in terms of shape, equipment without the written consent of ŠKODA. and engineering, may be introduced at any time.
  • Page 252 Also please pay attention to those parts in the Owner's Manual that are marked  below. Work with us – for the sake of the environment. Owner's Manual Yeti anglicky 11.2011 S90.5610.05.20 5L0 012 003 FD...

Table of Contents

Save PDF
