Chapter 5. Rack PDU Specifications

When connected to a dedicated power source, the 100-127V and Universal Rack
PDUs conform to UL1950, CSA 22.2-950, EN-60950, and IEC-950 standards. The
following table contains the product specifications for the 100-127V and Universal
Rack PDUs.
Height
Width
Depth
Additional Clearance
Weight
Operating temperature at 0-914 m
(0-3000 ft)
Operating temperature at 914-2133 m
(3000-7000 ft)
Operating humidity
Rated voltage
Rated frequency
Maximum power rating
Circuit breaker
Power inlet
Power outlets
© Copyright IBM Corp. 2003
41.5 mm (1.63 in.)
222.5 mm (8.76 in.)
114.5 mm (4.51 in.)
100-127V Rack PDU: 20 mm (0.79 in.) for circuit
breaker; 2.5 mm (0.1 in.) for outlets
Universal Rack PDU: 20 mm (0.79 in.) for circuit
breaker; 3.0 mm (0.12 in.) for outlets
100-127V Rack PDU: 1.7 kg (3.7 lb), with fixed line
cord
Universal Rack PDU: 1.3 kg (2.8 lb), without
power cord
10°-35° C (50°-95° F)
10°-32° C (50°-90° F)
8-80% (non-condensing)
100-127V Rack PDU: 100-127 V ac, 15 A, single-
phase
Universal Rack PDU: 100-240 V ac, 15 A, single-
phase
50-60 Hz
100-127V Rack PDU: 1900 VA
Universal Rack PDU: 3600 VA
Two-pole, 15 A with time-delay protection
100-127V Rack PDU: Fixed line cord with L5-15P
connector rated at 15 A
Universal Rack PDU: IEC 320-C20 inlet rated at
16 A (VDE) / 20 A (UL/CSA)
100-127V Rack PDU: Six NEMA 5-15 outlets rated
at 10 A (VDE) / 15 A (UL/CSA)
Universal Rack PDU: Seven IEC 320-C13 outlets
rated at 10 A (VDE) / 15 A (UL/CSA)
15
