Table of zones

When using the Diagnostic functions, use the Table of Zones to see which input
has triggered the system. It is also helpful in deciding which input to use when
connecting optional sensors and switches.
ZONE NO.
1
2
3
4
5
6
Note:
The WarnAway® response does not report on the LED

Shutdown diagnostics

To perform shutdown diagnostics:
1. With the ignition OFF, press and hold the Valet/Program switch.
2. Turn the ignition ON and then back OFF while holding the Valet/Pro-
gram switch.
3. Release the Valet/Program switch.
4. Press and release the Valet/Program switch. The LED flashes to report
the last shutdown for one minute or until the ignition is turned on, as
shown in the following table:
LED Flashes
1 flash
2 flashes
3 flashes
4 flashes
5 flashes
6 flashes
56
TRIGGER TYPE
Trunk Input
Shock Sensor
Door Trigger
Sensor 2
Ignition
Hood Trigger
Shutdown Mode
Runtime expired
Over-rev shutdown
Low or no RPM
Transmitter shutdown (or optional push button)
(+) Brake shutdown
(-) Hood shutdown
INPUT DESCRIPTION
BLUE (H1/7)
Onboard shock sensor
GREEN (H1/8) and VIOLET (H1/6).
Optional MUX sensor port
Heavy gauge pink of remote start harness
GRAY on the 6-pin shutdown harness.
