Table of zones
A zone is represented by the number of LED flashes used by the system
to identify a particular type of input. Standard input assignments are
listed in the following table, along with spaces to write in any optional
sensors or switches that have been installed.
Zone
Description
1
Trunk Pin
2
Instant trigger: a heavier
impact detected by the
shock sensor
3
Door switch trigger
4
Instant trigger: For
optional sensors
5
Ignition trigger
6
Hood Pin
Interpreting zone diagnostics
Warn Away responses are not reported by arming or disarming diag-
nostics. If you receive a Bypass notification when arming or a Tamper
Alert notification when disarming, look at the LED.
Active or triggered zones will be indicated by a pattern of blinks by the
LED.
For example: If zone 3 was active or triggered, the LED will blink three
times with a two-second pause. Then it will blink three times again,
and repeat until the ignition is turned on.
Dealer installed options
© 2008 Directed Electronics—all rights reserved
