This appendix lists cables that have been tested and verified for use with the
HP ProCurve 10Base-T Hubs. It also includes minimum pin-out information
so, if you wish to use an unlisted cable, you can verify that the cables used in
your installation are correctly wired. Note that each pin-out does not neces-
sarily match the pin-out for the corresponding HP cable, but cables manufac-
tured to follow the minimum pin-out will function correctly.

Minimum Cable Pinout for ASCII Console Connection

HP 10Base-T Hubs Installation Guide
PC end
9-pin male
2
3
5
Hub end
9-pin male
2 Rx
3 Tx
5 GND
B-4
