Citizen E650 User Manual

Analog solar-powered watch
Hide thumbs Also See for E650:
Table of Contents

Advertisement

Quick Links

Thank you for your purchase of this Citizen watch.
Before using the watch, read this instruction manual carefully to ensure
correct use.
After reading, be sure to store this manual in a safe place should it be
needed for future reference.
The case has different features depending on the model.
✳
Details of model specific features may not be outlined in this manual. See
http://www.citizenwatch.jp/support/default.htm
To determine the movement number
Your watch features a case number engraved on the
case back (refer to figure to the right).
The first four characters of the case number
represent the movement caliber number of the
watch.
In the example on the right, "1234" is the movement
number.
Engraving position example
The engraving position may differ
depending on watch model.
1

Advertisement

Table of Contents
loading

Related Manuals for Citizen E650

Summary of Contents for Citizen E650

  • Page 1 Thank you for your purchase of this Citizen watch. Before using the watch, read this instruction manual carefully to ensure correct use. After reading, be sure to store this manual in a safe place should it be needed for future reference.
  • Page 2 Safety Precautions Safety Precautions This manual may contain certain safety advisories. Your watch should be used ■ Important instructions are categorized and depicted in this manual as follows: in accordance with these advisories at all times to ensure optimal enjoyment of Warning (caution) symbol followed by instructions that should be your watch and to prevent injury to yourself, other persons and/or damage to followed and/or precautions that should be observed.

  • Page 3: Features

    1-second steps. ◆ Alarm function that can be set based on a 24-hour clock. ◆ Perpetual calendar function that eliminates the need to correct the date at the end of each month. * Eco Drive is Citizen proprietary technology.

  • Page 4: Table Of Contents

    Table of contents Component identification …………………………………………… 8 Adjusting the time/calendar manually …………………………… 42 Checking the power reserve ……………………………………… 12 Checking and correcting the current reference (0) position …… 46 Checking the radio signal reception ……………………………… 14 Troubleshooting …………………………………………………… 50 Selecting a time zone (city) ………………………………………… 16 Resetting the watch to the default settings ………………………...

  • Page 5: Component Identification

    Component identification Component identification RX: Reception in progress H, M, L: ● Function hand NO: Reception Reception level/ Day of week result reception result Charge level Upper right Tachymeter button (B) Chronograph Function hand (minute) Hour hand Minute hand 24 hour hand Crown ●...
  • Page 6 Component identification Component identification ● How to use the screw down crown and screw down push button Unlock Lock Some models feature a screw down crown and/or screw down push button. Screw down Rotate the crown Push the crown in to Locking the crown and/or button prevents accidental operation.

  • Page 7: Checking The Power Reserve

    Checking the power reserve Checking the power reserve Modes supporting this function: [LAX] [DEN] [CHI] [NYC] [LON] [A-TM] Charge level Level 0 Level 1 Level 2 Level 3 Check the power reserve level as follows: 1. Ensure that the crown is in position Charge indicator 2.

  • Page 8: Checking The Radio Signal Reception

    Checking the radio signal reception Checking the radio signal reception Modes supporting this function: [LAX] [DEN] [CHI] [NYC] [LON] ● Second hand positions and reception results To check result of previous radio reception time update: NO: Reception failed. H: Radio reception and time 1.

  • Page 9: Selecting A Time Zone (City)

    Selecting a time zone (city) Selecting a time zone (city) To select a time zone (city): ● Table of radio controlled time zones (city) 1. Pull the crown out to position Button (B) • The cities listed in the table below may be abbreviated or spelled out, depending on the model. The second hand moves to the 30 seconds position.

  • Page 10: Notes On The Radio Signal Reception

    Notes on the radio signal reception Notes on the radio signal reception Modes supporting this function: [LAX] [DEN] [CHI] [NYC] [LON] • Radio signal reception cannot be deactivated. ■ Receiving the radio signal • Even when this watch receives a radio signal successfully, the accuracy of There are three ways to receive the radio signal.
  • Page 11 Notes on the radio signal reception Notes on the radio signal reception ■ Note on the radio signal ● Station locations and reception ranges This watch receives the radio signal from the two signal stations located in * The distance values below are given only for information purpose. The actual reception condition may differ depending on the environment and climate.
  • Page 12 Notes on the radio signal reception Notes on the radio signal reception ■ When signal reception is poor ■ Poor reception areas Radio signal reception may be affected by the surrounding environment. It may be difficult to receive the radio signal properly under certain environmental conditions or in areas susceptible to radio noise.

  • Page 13: On-Demand Reception-Manual Signal Reception Activation

    On-demand reception—manual signal reception activation On-demand reception—manual signal reception activation Modes supporting this function: [LAX] [DEN] [CHI] [NYC] [LON] When the reception has finished, a tone sounds, and the second hand Manual reception updating may be attempted restores the normal operation. at anytime.

  • Page 14: Using The Alternate Time Mode

    Using the alternate time mode Using the alternate time mode Modes supporting this function: [A-TM] 4. To set the alternate time: The alternate time mode allows you to set the time in any region other than • Rotate the crown clockwise to advance the time in one hour increments. the featured five cities in 15 minute increments.

  • Page 15: During The Daylight Saving Time Season

    During the Daylight Saving Time season During the Daylight Saving Time season ■ Checking the daylight savings time setting Some areas observe Daylight Saving Time. Button (B) While the watch is in the time display mode or A-TM • Daylight Saving Time rules will vary depending on the country or region mode and the crown is set at position , perform within a country.
  • Page 16 During the Daylight Saving Time season During the Daylight Saving Time season ■ To manually change the Daylight Saving ● Sharing of daylight savings time setting Time setting Button (B) • The Daylight Saving Time / standard time is shared by multiple cities and regions 1.

  • Page 17: Using The Chronograph Function

    Using the chronograph function Using the chronograph function Modes supporting this function: [CHR] ■ Starting time measurement The chronograph is able to measure time up to 59 minutes 59 seconds in Press and release the upper right button (B). Button (B) 1-second units.

  • Page 18: Using The Alarm

    Using the alarm Using the alarm Modes supporting this function: [ALM] • Check AM and PM with the 24-hour hand (10:00 sub dial) to set the correct The alarm function uses a 24-hour clock. Once the alarm has been set, the alarm AM or PM time.
  • Page 19 Using the alarm Using the alarm ■ Setting the alarm to ON or OFF Button (B) 4. Rotate the crown to select a city or [A-TM]. 1. Pull the crown out to position • While the watch is in the alarm mode, the alarm will not sound. 2.

  • Page 20: Recharging Your Watch

    Recharging your watch Recharging your watch ■ Charging time by environment This watch has a rechargeable cell which is charged by exposing the dial to Below are the approximate times needed for charging when exposing the watch light such as direct sunlight or fluorescent lamps. dial to light continuously.
  • Page 21 Recharging your watch Recharging your watch ■ When the watch reaches a low charge state ■ Power save feature — insufficient charge warning function 2-second When the watch is continuously not exposed to light for 30 minutes or When the power reserve becomes low, the second more, for example being stored in a case, the second hand is automatically 2-second hand moves once every 2 seconds —...

  • Page 22: Adjusting The Time/Calendar Manually

    Adjusting the time/calendar manually Adjusting the time/calendar manually Modes supporting this function: [LAX] [DEN] [CHI] [NYC] [LON] 6. Press and release the lower right button (A). 1. Pull the crown out to position Second hand The second hand points to the current month and year. 2.
  • Page 23 Adjusting the time/calendar manually Adjusting the time/calendar manually ■ Month and leap year indications When the time and date are corrected manually, the elapsed years from the most recent leap year and the month are indicated at the position of the second hand.

  • Page 24: Checking And Correcting The Current Reference (0) Position

    Checking and correcting the current reference (0) position Checking and correcting the current reference (0) position Modes supporting this function: [CHR] 1. Pull the crown out to position If the time, date or chronograph hands do not indicate properly, the correct 2.
  • Page 25 Checking and correcting the current reference (0) position Checking and correcting the current reference (0) position 4. Press and release the lower right button (A). 8. Rotate the crown to align the 24 hour hand Hour hand hour and minute hands to 0 The function hand (2:00 position) moves slightly.

  • Page 26: Troubleshooting

    Troubleshooting Troubleshooting Symptoms Remedies Pages If you have a problem with your watch, check the table below. The correct time Check the city setting. 16, 17 ● Problems with radio signal reception. and date are not Check and correct the current reference (0) indicated after 46 to 49 Symptoms...
  • Page 27 24, 25 Attempt manual radio signal updating. nearest Authorized Citizen Service Center setting. listed in your warranty booklet. 42 to 45 Set the time and date manually. Daylight Saving...

  • Page 28: Resetting The Watch To The Default Settings

    Resetting the watch to the default settings Modes supporting this function: Resetting the watch to the default settings [CHR] 1. Pull the crown out to position If the watch operation is unstable due to strong impact or static electricity, or Button (B) 2.

  • Page 29: Solar-Powered Watch Handling Precautions

    Solar-powered watch handling precautions Solar-powered watch handling precautions <Always be Sure to Expose Your Watch to Light Regularly> CAUTION Recharging Precautions • Your watch enjoys regular exposure to light. Wearing in situations that prevent light exposure such as long shirt or coat sleeves will prevent your watch from receiving light sufficient for charging. In • Do not charge your watch at high temperatures (60°C/140°F) as these instances, supplemental charging may be needed.
  • Page 30 Solar-powered watch handling precautions Solar-powered watch handling precautions <Replacement of Rechargeable Cell> WARNING Use Only the Specified Rechargeable Cell • Your watch features a cell that does not need regular replacement. However, after an extended period of time, power consumption may increase due to deterioration • Never install a conventional battery in your watch. Only use the specified rechargeable cell. of lubrication in the movement. This may result in shorter than expected run time. Be sure to have Your watch is designed to operate only with the original type of rechargeable cell.

  • Page 31: Water Resistance

    Water resistance Water resistance WARNING Water Resistance • Refer to the watch dial and the case back for the indication of the water resistance of your watch. Water-related use The following chart provides examples of use for reference to ensure that your watch is used properly. (The unit “1bar” is roughly equal to 1 atmosphere.) • WATER RESIST(ANT) ××bar may also be indicated as W.R.××bar. Minor exposure Operate the crown Indication to water (washing Swimming and...

  • Page 32: Precautions And Usage Limitations

    Precautions and usage limitations Water resistance • Non-water resistant watches cannot be used underwater or in environments in contact with water. CAUTION To Avoid Injury • Water-resistance for daily use (to 3 atmospheres) means that the watch may be worn while washing your face or in the rain, but is not to be immersed in water. • Be particularly careful when wearing your watch while holding a small child, to avoid injury. • Upgraded water-resistance for daily use (to 5 atmospheres) means that the watch may be worn • Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself and while swimming, but is not to worn while skin diving. others. • Upgraded water-resistance for daily use (to 10/20 atmospheres) means that the watch may be worn • DO NOT wear your watch while in a sauna, jacuzzi or other location where it may become while skin diving, but not while scuba or saturated diving using helium gas.

  • Page 33: Static Electricity

    Precautions and usage limitations Precautions and usage limitations • A rubber type strap may become stained by dyes or soils found in clothing and other accessories. CAUTION Precautions Since these stains may become permanent, take caution when wearing your watch with items that may transfer color (articles of clothing, purses, dyed bracelets, etc.). • Always wear your watch with the crown pushed in to the normal position. If your crown is a screw • Solvents, moisture and perspiration may cause the strap to deteriorate. Be sure to replace a strap down type, be sure it is properly screwed down (locked) to the case. that has become dried, brittle, or cracked to prevent loss due to strap failure.
  • Page 34 Precautions and usage limitations Precautions and usage limitations <Strong Shock> • The case and band of the watch come in to direct contact with the skin. This may result in unnoticed accumulations of dirt and foreign matter caused by normal wear. Accumulated matter • Avoid dropping the watch or subjecting it to other strong impact. It may cause malfunctions and/ may cause rust, discoloration, and premature wear. Be sure to regularly clean your watch with or performance deterioration as well as damage to the case and bracelet.

  • Page 35: Maintenance

    • The light emission of the luminous material gradually decreases as time passes. Always ask for genuine Citizen parts upon replacement. • The duration and amount of light emitted will vary depending on the brightness, type of and distance from the light source, exposure time and amount/size of luminous treatment. • When not exposed to a light source, light emission from the luminous treatment will start off bright and gradually diminish over a period of hours.

  • Page 36: Specifications

    Specifications Specifications • Solar power function Model E650 Type Analog solar-powered watch • Power reserve indication Timekeeping • Overcharging prevention function accuracy • Insufficient charge warning function (2-second interval movement) Within ±15 seconds per month when worn at normal operation (without the •...
