INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eco-Drive and is the answer not in the manual?

Questions and answers

Related Manuals for Citizen Eco-Drive

Summary of Contents for Citizen Eco-Drive

  • Page 1 INSTRUCTION MANUAL...
  • Page 2 ENGLISH FRANÇAIS ESPAÑOL DEUTSCH ITALIANO PORTUGUÊS 中文 （繁体字） 中文 （簡体字）...
  • Page 3 Thank you for your purchase of this Citizen watch. Before using the watch, read this instruction manual carefully to ensure correct use. After reading the manual, store it in a safe place for future reference. Visit the Citizen website (https://www.citizenwatch-global.com/) to view visual guides for operation of your watch.
  • Page 4 Safety precautions — IMPORTANT This manual may contain certain safety advisories. Your watch should be used in accordance with these advisories at all times to ensure optimal enjoyment of your watch and to prevent injury to yourself, other persons and/or damage to property. Understand the meaning of the following symbols and read pages from 20 to 29.
  • Page 5 Before using this watch Band adjustment We recommend seeking the assistance of an experienced watch technician for sizing of your watch. If adjustment is not done correctly, the bracelet may unexpectedly become detached leading to loss of your watch or injury. Consult your nearest an authorized service center.

  • Page 6: Table Of Contents

    Table of contents Features ....................Displays and buttons ................Setting the time .................. Setting the calendar ................. Using temperature display function ..........Using the alarm ................Using the chronograph ..............Using the dual time ................
  • Page 7 Low battery warning function............Reset operation ................Water resistance ................Precautionary items and usage limitations ........Specifications ...................

  • Page 8: Features

    Features This watch is a combination quartz watch equipped with time and calendar functions as well as alarm, chronograph and dual time functions. It is also provided with a temperature display function that displays the current temperature at all times. Displays and buttons Analog 1 Analog 2...
  • Page 9 Displays and buttons • The lamp is switched on by pressing button C. • Analog 1: Provides a continuous display of the current time (hour, minute). • Analog 2: Provides “second”, a rough indication of “alarm time” or “local time”. In the chronograph mode, it switches to “measured time (hour)”.

  • Page 10: Setting The Time

    Setting the time <Normal time display> Button M Button B Hour, Minute DU.T ST.W DATE DU.T TIME ST.W Button A TEMP ℃ 1/1000 SEC Chime ON mark Second 1. Press button M repeatedly to change the mode mark to the time mode. 2.
  • Page 11 Setting the time • When correcting the second, pressing button A returns the second display to “00” after which the watch starts running. • When changing the 12/24-hour, the 12/24-hour clock display is switched alternately by pressing button A. • When correcting Analog 1 (“hour” and “minute” are flashing simultaneously), pressing button A corrects the hand.

  • Page 12: Setting The Calendar

    Setting the calendar <Normal calendar display> Button M Button B Date DU.T ST.W DATE DU.T TIME ST.W Button A TEMP ℃ 1/1000 SEC Temperature (Month is displayed when setting the calendar.) 1. Press button M repeatedly to change the mode mark to the calendar mode. 2.
  • Page 13 Setting the calendar • Second is continuously displayed in the Analog 2 in the calendar correction mode. • Year of calendar can be set to 2000-2099. • The day is corrected automatically by correcting the year, month and date. • The date does not have to be corrected on the last day of the month, including leap years. The watch performs this automatically.

  • Page 14: Using Temperature Display Function

    Using temperature display function The temperature display function can be used in the calendar mode. This function automatically measures ambient temperature and display it on the digital display. In addition, the interval at which temperature is measured can be selected either every second or every minute. <Switching of temperature measuring interval>...
  • Page 15 Using temperature display function <Notes> During temperature measurement, the measured temperature will be body temperature when the watch is worn on the wrist. In order to obtain an accurate temperature measurement, remove the watch from the wrist and adapt to the temperature in which temperature is to be measured for at least 20-30 minutes.

  • Page 16: Using The Alarm

    Using the alarm <Normal alarm display (ON)> Button M Button B Set time DU.T ST.W DATE DU.T TIME ST.W Button A TEMP ℃ 1/1000 SEC Alarm ON mark Temperature memo 1. Press button M repeatedly to change the mode mark to the alarm mode. 2.
  • Page 17 Using the alarm • In the alarm correction mode, Analog 2 serves as a rough indicator of the set alarm time. • During the normal alarm display, pressing button A activates/deactivates the alarm alternately. When the alarm is switched on, the alarm ON mark (ALM) is displayed below the mode mark display.

  • Page 18: Using The Chronograph

    Using the chronograph <Chronograph initial indication> Measured time (hour) Button M Button B Measured time DU.T ST.W (minute, second) DATE DU.T TIME ST.W Button A TEMP ℃ 1/1000 SEC 1000 Measured time (1/1000 second) Reset Measurement STOP * The watch automatically returns to measurement of elapsed time after Split time about 10 seconds.
  • Page 19 Using the chronograph • Press button M repeatedly to change the mode mark to the chronograph mode. Buttons A and B are used for the chronograph operation. • You can switch to other modes by pressing button M even while timing. The timing continues while indicating other modes.

  • Page 20: Using The Dual Time

    Using the dual time <Normal dual time display> Button M Button B Local time DU.T ST.W DATE DU.T TIME ST.W Button A TEMP ℃ 1/1000 SEC Local time mark (L) 1. Press button M repeatedly to change the mode mark to the dual time mode. 2.

  • Page 21: Low Battery Warning Function

    Low battery warning function As the battery approaches the end of its service life, a colon (:) will begin to flash on the digital display. In addition, the Analog 2 display changes to 2-second interval movement (the second hand moves once every 2 second) only when the Analog 2 displays seconds. When this happens, promptly replace the battery.

  • Page 22: Water Resistance

    Water resistance WARNING Water Resistance • Refer to the watch dial and/or the case back for the indication of the water resistance of your watch. The following chart provides examples of use for reference to ensure that your watch is used properly.
  • Page 23 Water resistance Water-related use Minor exposure Swimming and Operate the crown to water (washing general washing Skin diving, Scuba diving using or button when face, rain, etc.) work marine sports an air tank the watch is wet...
  • Page 24 Water resistance • Non-water resistant models are not designed to come into contact with any moisture. Take care not to expose a watch with this rating to any type of moisture. • Water resistance for daily use (to 3 atmospheres) means the watch is water resistant for occasional accidental splashing.

  • Page 25: Precautionary Items And Usage Limitations

    Precautionary items and usage limitations CAUTION To Avoid Injury • Be particularly careful when wearing your watch while holding a small child, to avoid injury. • Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself and others.
  • Page 26 Precautionary items and usage limitations CAUTION Precautions (continued) • Even if your watch has a high level of water resistance, please be careful of the following. • If your watch is immersed in sea water, rinse thoroughly with fresh water and wipe with a dry cloth.
  • Page 27 Precautionary items and usage limitations • It is recommended to take off the watch if it gets wet, even if the watch itself is water-resistant. • Do not wear the band too tightly. Try to leave enough space between the band and your skin to allow adequate ventilation.
  • Page 28 Precautionary items and usage limitations <Magnetism> • Analog quartz watches are powered by a step motor that uses a magnet. Subjecting the watch to strong magnetism from the outside can cause the motor to operate improperly and prevent the watch from keeping time accurately. Do not allow the watch to come into close proximity to magnetic health devices (magnetic necklaces, magnetic elastic bands, etc.) or the magnets used in the latches of refrigerator doors, clasps used in handbags, the speaker of a cell phone, electromagnetic cooking devices and so on.
  • Page 29 Precautionary items and usage limitations <Protective Stickers> • Be sure to remove any protective stickers that may be on your watch (case back, band, clasp, etc.). Otherwise, perspiration or moisture may enter the gaps between the protective stickers and the parts, which may result in a skin rash and/or corrosion of the metal parts.
  • Page 30 Precautionary items and usage limitations Caring for Your Watch • Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth. • For metallic, plastic or synthetic rubber (polyurethane) band, clean it with soap and a soft toothbrush.
  • Page 31 Precautionary items and usage limitations <About Luminous Paint> The paint on the dial and hands helps you with reading the time in a dark place. The luminous paint stores light (daylight or artificial light) and glows in a dark place. It is free from any radioactive substance or any other material harmful to a human body or environment.

  • Page 32: Specifications

    Specifications 8989 Combination (analog and digital) quartz watch Model Type Within ±15 seconds per month on average (when used in a normal Accuracy temperature range of +5°C to +35°C/41°F to 95°F) 0°C to +55°C/32°F to 130°F Operation temperature range Analog 1: Hour, minute Display functions Analog 2: Second, rough indicator of alarm hour, local time hour and chronograph measured time (hour)
  • Page 33 Specifications Battery code: SR1120W Battery Approx. 2 years Battery Life (assuming that the alarm tone is used 20 seconds per day, the chime sounds 24 times per day, and the lamp is used for 3 seconds per day) Chime, lamp, temperature display, low battery warning Additional functions Specifications are subject to change without prior notice.
  • Page 34 European Union directives conformance statement Hereby, CITIZEN WATCH CO.,LTD. declares that this product is in compliance with the essential requirements and other relevant provisions of directive 2014/53/EU and all other relevant EU directives. You can find your product’s Declaration of Conformity at...
  • Page 35 Model No.JG2＊ Cal.8989 CTZ-B8213...
